Figure 4-5 The Initial Message Of Voicefinder Ap2620 Gateway ] - AddPac VoiceFinder AP2620 Installation Manual

PassFinder AP2620 VoIP Gateway , Release 1.00
The system is not configured yet or backup data is invalid.
Please login to system as a "root" and make configuration.
Flash ROM size is too small for IVR system
Voice Module Ready
DSP S/W download (0): .... OK
DSP S/W download (1): .... OK
The System is ready. Please login to system.
VoipGateway::Init1 - No IP address on the VoIP Interface
PS(0) install .... OK
PS(1) install .... OK
login:
login: root
password:
AP2620 - Login : root at Console on Fri May 20 12:31:40 2005
AP2620#
With the log-in message, input the user name "root" and the password
"router". After the log-in process, the prompt "AP2620#" is displayed on
the console terminal.
AddPac Technology Proprietary & Documentation

[ Figure 4-5 The initial message of VoiceFinder AP2620 Gateway ]

47 - 44
