PassFinder AP2620 VoIP Gateway , Release 1.00

VoiceFinder AP2620 Gateway Front Part

On the front panel of AP2620 VoIP Gateway, various LEDs are placed for
easy operation monitoring along with Max. two(2) channels of FXS, FXO,
and E&M Voice interfaces, 2 Ethernet, Console ports making possible
WAN-to-LAN VoIP service and IP routing service
<Table 1-3> The below table describes the front panel LED of AP2620 VoIP
No.
①
②
③
④
⑤
⑥
⑦
⑧
AddPac Technology Proprietary & Documentation
[ Figure 1-3 VoiceFinder AP2620 Front View ]
Part
RESET switch : Resets the system by
RST
hardware
PWR Power LED : Indicates power supply
RUN LED : Indicates proper functioning of
RUN
the equipment
LINK LED : Indicates proper connection of
LAN0 Link
LAN0
LAN0 10M LED : Indicates Ethernet port
LAN0 10M ACT
data input status
LAN0 100M LAN0 100M LED : Indicates Ethernet port
ACT data input status
LINK1 LED : Indicates proper connection of
LAN1 Link
LAN0
LAN1 10M ACT LAN1 10M LED : Indicates Ethernet port
Gateway
Description
(Red)
(ACT Green)
(Yellow)
(ACT Green)
(ACT Green)
(Yellow)
(Green)
47 - 14
