ProCurve 2610 Manual page 416

Configuring and Monitoring Port Security
MAC Lockdown
Internal
Network
PROBLEM: If this link fails,
traffic to Server A will not use
the backup path via Switch 3
Switch 3
Figure 12-10.Connectivity Problems Using MAC Lockdown with Multiple Paths
12-24
Server A is locked down
to Switch 1, Uplink 2
Switch 1
M i x e d U s e r s
The resultant connectivity issues would prevent you from locking down
Server A to Switch 1. And when you remove the MAC Lockdown from Switch
1 (to prevent broadcast storms or other connectivity issues), you then open
the network to security problems. The use of MAC Lockdown as shown in the
above figure would defeat the purpose of using STP or having an alternate
path.
Technologies such as STP are primarily intended for an internal campus
network environment in which all users are trusted. STP does not work well
with MAC Lockdown.
If you deploy MAC Lockdown as shown in the Model Topology in figure 12-9
(page 12-22), you should have no problems with either security or connectiv­
ity.
Switch 4
Switch 2
Server A
External
Network
