ProCurve(config)# show qos port-priority
Port priorities
Port Apply rule
---- ----------- + ------ ----------- ---------------
B1 Priority
B2 No-override |
B3 No-override |
B4 DSCP
B5 No-override |
B6 No-override |
The DSCP in the Apply Rule column and the 001010 in the DSCP column indicate a non-
default CoS (802.1p) priority configured in the switch for packets with a Diffserv codepoint
of 001010 inbound on port B4. The 2 in the Priority column shows the CoS priority most
recently configured for application to packets with that codepoint. The 5 in the Radius
Override column indicates that there is currently at least one authenticated-client session
on port B4, and that the most recent RADIUS-imposed CoS priority for the port is 5, which
overrides the configured DSCP setting. See also the following Note.
Figure 6-2. Example of Displaying Inbound CoS (802.1p) Priority Imposed by a RADIUS Session
Note
| DSCP Priority
| 3
No-override No-override
No-override No-override
| 001010 2
No-override No-override
No-override No-override
Where multiple clients are currently authenticated on a given port where
inbound CoS values have been imposed by a RADIUS server, the port operates
with the inbound CoS priority assigned by RADIUS for the most recently
authenticated client. Any earlier CoS values on the same port for authenticated
client sessions that are still active are overwritten by the most recent RADIUS-
imposed values. For example, if client "X" is authenticated with a CoS of 5 and
client "Y" later becomes authenticated with a CoS of 3 while the session for
client "X" is still active, then the port will operate with a CoS of 3 for both
clients.
Configuring RADIUS Server Support for Switch Services
Configuring the RADIUS Server for CoS Services
Radius Override
No-override
5
Priority in the Apply Rule
column indicates a non-
default CoS (802.1p)
priority configured in the
switch for port B1. The 3 in
the Priority column shows
the actual value
configured. No-override
indicates that there is
currently no RADIUS-
imposed CoS priority
affecting the port.
