You should carefully plan your ACL application before configuring specific
ACLs. For more on this topic, refer to "Planning an ACL Application" on page
9-16.

ACL Configuration Structure

After you enter an ACL command, you may want to inspect the resulting
configuration. This is especially true where you are entering multiple ACEs
into an ACL. Also, it will be helpful to understand the configuration structure
when using later sections in this chapter.
The basic ACL structure includes three elements:
1. ACL type and name: This identifies the ACL as standard or extended and
shows the ACL name.
2. One or more deny/permit list entries (ACEs): One entry per line.
Element
ID Range
Minimum ACEs per ACL
Maximum ACEs Per ACL
Maximum ACEs per
Switch
3. Implicit deny any: Where an ACL is in use, the switch denies any packets
that do not have a match with the ACEs explicitly configured in the ACL.
The implicit deny any does not appear in ACL configuration listings, but
always functions when the switch uses an ACL to filter packets. (You
cannot delete the implicit "deny any", but you can supersede it with a
"permit any" statement.)
Configuring and Assigning an ACL
Stnd Ext Notes
1 - 99 100 - 199 You can also use an alphanumeric name
of up to 64 characters, including spaces.
1
120
1024 In some cases, rule usage by ACLs may
consume available resources to the point
where this limit cannot be reached.
Access Control Lists (ACLs)
9-33
