Access Control Lists (ACLs)
Configuring and Assigning an ACL
Note
9-44

Configuring and Assigning a Numbered, Extended ACL

This section describes how to configure numbered, extended ACLs. To con­
figure other ACL types, refer to the following table.
To Configure:
Standard, numbered ACLs
Named ACLs
While standard ACLs use only source IP addresses for filtering criteria,
extended ACLs allow multiple ACE criteria. This enables you to more closely
define your IP packet-filtering criteria. These criteria include:
■ Source and destination IP addresses (required), in one of the
following options:
• S pecific host IP
• Subnet or group of IP addresses
• Any IP address
IP protocol (IP, TCP, or UDP)
■
Source TCP or UDP port (if the IP protocol is TCP or UDP)
■
■ Destination TCP or UDP port (if the IP protocol is TCP or UDP)
TCP or UDP eq operator (if the IP protocol is TCP or UDP)
■
You can configure extended ACLs with a numeric name in the range of 100 ­
199. You can also configure extended ACLs with alphanumeric names. (Refer
to "Configuring a Named ACL" on page 9-50.)
For a summary of ACL commands, refer to table 9-1, "Comprehensive Com­
mand Summary", on page 9-5.
Refer To:
"Configuring and Assigning a Numbered, Standard ACL" on
page 9-39
"Configuring a Named ACL" on page 9-50
