Operator´s manual
Rider ProFlex 21 II
Please read these instructions carefully and make sure
English
you understand them before using the machine.

Advertisement

Table of Contents
loading

Related Manuals for Husqvarna Rider ProFlex 21 II

Summary of Contents for Husqvarna Rider ProFlex 21 II

  • Page 1 Operator´s manual Rider ProFlex 21 II Please read these instructions carefully and make sure English you understand them before using the machine.
  • Page 2 Svenska –...

  • Page 3: Table Of Contents

    Mowing Tips............22 Electrical and Hydraulic Systems....... 59 Stopping the Engine...........23 Technical Data ............61 Clutch Control ............24 Rider ProFlex 21 II ..........61 Maintenance ............25 Cutting Unit ............62 Maintenance Schedule ........25 EU Declaration of Conformity ......63 Removing the Rider’s Covers ......27 Service journal .............

  • Page 4: For Your Own Safety

    IMPORTANT INFORMATION Read carefully through the Operator’s manual so that you know how to use and maintain the Rider before you use it. For service measures other than those described in this manual, please contact an authorised dealer that provides parts and service. For Your Own Safety Insure your Rider •...

  • Page 5: Introduction

    Introduction Congratulations Thank you for purchasing a Husqvarna Rider. Husqvarna Riders have been designed according to a unique concept with a front mounted cutting unit and patented rear wheel steering. The Rider is built to give maximum efficiency even in small and confined areas. All controls in one place and a hydrostatic transmission regulated by foot pedals also contribute to the machine’s performance.

  • Page 6: Proper Service

    INTRODUCTION Proper Service Husqvarna’s products are sold all over the world and only by specialised retail traders offering complete service. This ensures that you as a customer receive only the best support and service. Before the product is delivered, the machine has, for example, been inspected and adjusted by your retailer, see the certificate in the Service Journal in this operator’s manual.

  • Page 7: Symbols And Decals

    EXPLANATION OF SYMBOLS Symbols and Decals These symbols can be found on the rider and in the operator’s manual. Study them carefully so that you know what they mean. Read the operator’s manual. Reverse Neutral Fast Slow Battery Choke Fuel Engine off Oil level Cutting height...

  • Page 8: Explanation Of Symbols

    EXPLANATION OF SYMBOLS WARNING! Xxxxxxx xxxx xxxxxxxx xxx x Xxxxx xxxxxx xx. xx xxxxxxxx xxxxx xxx xx. Used in this publication to notify the reader of a risk of personal injury, particularly if the reader should neglect to follow instructions given in the manual. IMPORTANT INFORMATION Xxxxxxx xxxx xxxxxxxx xxx xxx xxxx xxxxxx xx.

  • Page 9: Safety Instructions

    SAFETY INSTRUCTIONS Safety Instructions These instructions are for your safety. Read them carefully. WARNING! The inserted symbol means that important safety instructions needed to be observed. It applies to your safety. General Use • Read all instructions in this operator’s manual and on the machine before starting it.
  • Page 10 SAFETY INSTRUCTIONS • Be careful when rounding fixed objects, WARNING! so that the blades do not hit them. Never run the machine over foreign objects. Engine exhaust, some of its constituents and certain vehicle • Only use the machine in daylight or in components contain or emit other well-lit conditions.

  • Page 11: Driving On Slopes

    SAFETY INSTRUCTIONS Driving on Slopes Driving on slopes is one of the operations where the risk of the driver losing control of the machine or of it overturning is the greatest; this can result in serious injury or death. All slopes demand extra care. If you cannot reverse up a slope or if you feel unsure, do not mow it.

  • Page 12: Children

    SAFETY INSTRUCTIONS Children • Serious accidents may occur if you fail to be on guard for children in the vicinity of the machine. Children are often attracted to the machine and mowing. Never assume that children will stay put where you last saw them.
  • Page 13 SAFETY INSTRUCTIONS • If leaks arise in the fuel system, the WARNING! engine must not be started until the The engine, and components of the problem has been resolved. exhaust and hydraulic systems • Store the machine and fuel in such a way become extremely hot during that there is no risk of leaking fuel or fuel operation.

  • Page 14: Transport

    SAFETY INSTRUCTIONS • Never use the machine indoors or in spaces lacking proper ventilation. Exhaust fumes contain carbon monoxide, an odourless, poisonous and highly dangerous gas. • Stop and inspect the equipment if you run over or into anything. If necessary, make repairs before starting.

  • Page 15: Presentation

    This operator’s manual describes the Rider ProFlex 21 II. The Rider ProFlex 21 II is fitted with a Kawasaki four-stroke V-Twin engine developing 21 horse power. Power transmission from the engine is via a hydrostatic gearbox that allows variable speed controlled by the foot pedals.

  • Page 16: Throttle Control

    PRESENTATION Throttle Control The throttle is used to control the speed of the engine and thereby also the rotation speed of the blades. In order to increase or decrease the engine speed, the control is moved forwards or backwards respectively. Avoid idling the engine for long periods, as there is a risk of carbon build-up on the spark plugs.

  • Page 17: Cutting Unit

    Cutting Unit As standard, the Rider ProFlex 21 II is fitted with a Combi 122 cutting unit with a cutting width of 122 cm. The Combi unit functions as a BioClip unit when a BioClip plug is fitted, but can be set to rear ejection by removing the BioClip plug.

  • Page 18: Mechanical Lifting Lever For The Cutting Unit

    PRESENTATION Mechanical Lifting Lever for the Cutting Unit The lever is used as a backup lever to put the cutting unit in either the transport or mowing position when hydraulic pressure is unavailable. It can also be used to mechanically secure the cutting unit in the transport position.

  • Page 19: Cutting Height Adjustment Lever

    PRESENTATION Cutting Height Adjustment Lever Using the cutting height lever, the cutting height can be adjusted between 7 different positions. In order to obtain an equal cutting height, it is important that the air pressure is the same in both front wheels (60 kPa). 8009-327 Parking Brake The parking brake is activated as follows:...

  • Page 20: Differential Lock

    PRESENTATION Differential Lock The differential lock couples the two drive wheels so that one wheel does not spin, thereby improving manoeuvrability. Press the pedal to engage the differential lock. 6020-009 Clutch Control The clutch control is used to move the rider when the engine is not running.

  • Page 21: Driving

    DRIVING Driving Before Starting • Read the sections Safety Instructions on page 7 and Presentation on page 13 before starting the Rider. • Perform the daily maintenance before starting (see Maintenance Schedule on page 25). • Adjust the seat to the desired position. 8009-322 Starting the Engine Raise the cutting unit by pulling the...

  • Page 22: Driving The Rider

    DRIVING When the engine starts, immediately release the ignition key so that it returns to the neutral position. IMPORTANT INFORMATION Do not run the starter motor for more than 5 seconds at a time. If the engine does not start, wait about 15 seconds before trying again.

  • Page 23: Differential Lock

    DRIVING Select the required cutting height (1-7) using the cutting height lever. 8009-327 Depress the lock button on the mechanical lifting lever and move the lever to its most forward position. The cutting unit is lowered and started if the lift hydraulics are in the lower position.

  • Page 24: Mowing Tips

    DRIVING Mowing Tips WARNING! Clear the lawn of stones and other objects that can be thrown out by the blades. • Localise and mark rocks and other fixed objects in order to avoid collisions. • Begin with a high cutting height and reduce it until the desired mowing result is attained.

  • Page 25: Stopping The Engine

    DRIVING Stopping the Engine If the engine has been worked hard, it is preferable to let the engine idle for a minute so it is running at its normal working temperature when it is stopped. Avoid idling the engine for long periods, as there is a risk of carbon build-up on the spark plugs.

  • Page 26: Clutch Control

    DRIVING Clutch Control The clutch control must be pulled out in order for the Rider to be moved when the engine is shut off. 8009-337 English-...

  • Page 27: Maintenance

    MAINTENANCE Maintenance Maintenance Schedule The following is a list of maintenance procedures that must be performed on the Rider. For points marked with footnote number 4, turn to an authorised service representative. Maintenance Page Daily Weekly At least Maintenance interval maintenance main- once a...
  • Page 28 MAINTENANCE Maintenance Page Daily Weekly At least Maintenance interval maintenance main- once a in hours tenance year before after Lubricate the gear controller Lubricate the parking brake cable Lubricate the throttle Lubricate the choke control Lubricate the guide chain in the frame tunnel Check the steering cables in the frame tunnel Clean the engine’s cooling air intake Clean the air cleaner’s pre-filter (Oil-foam)

  • Page 29: Removing The Rider's Covers

    MAINTENANCE Removing the Rider’s Covers The Engine Cover Tilt the seat back. Turn the cover lock on the engine cover exterior counter-clockwise 1/4 turn. Fold up the engine cover. If needed, the engine cover can be lifted off by removing the hinge pins. 8009-338 8009-339 The Nose Cover...

  • Page 30: Checking The Engine's Cooling Air Intake

    MAINTENANCE Left-hand Wing Cover Remove the differential lock pedal knob. Loosen the screws (1 and 2) and remove the wing cover. 6020-008 Transmission Cover Loosen both screws (one on each side) and lift off the transmission cover. 6008-209 Checking the Engine's Cooling Air Intake Open the engine cover.

  • Page 31: Checking And Adjusting The Steering Cables

    MAINTENANCE Checking and Adjusting the Steering Cables The steering is governed by means of cables. After a period of use these can become stretched, which means the steering setting may have changed. Steering is checked and adjusted as follows: Remove the frame plate by loosening the screws (two on the steering servo housing).

  • Page 32: Checking And Adjusting The Throttle Cable

    MAINTENANCE Checking and Adjusting the Throttle Cable Check that the engine responds to throttle increases and that a good engine speed is attained at full throttle. If doubts arise, contact your service representative. If adjustments are necessary, they can be made as follows for the lower cable: Loosen the clamping screw for the 8009-176...

  • Page 33: Adjusting Of The Hydrostatic Transmission Cable

    MAINTENANCE Adjusting of the Hydrostatic Transmission Cable The hydrostatic transmission cable (on the left side) is adjusted in the following manner: Remove the transmission cover. Loosen both screws (one on each side) and lift off the transmission cover. Take apart the lower ball joint, which is locked with a spring lock.

  • Page 34: Adjusting The Brake

    MAINTENANCE Adjusting the Brake The parking brake (on the right side) is adjusted in the following manner: Remove the transmission cover. Loosen both screws (one on each side) and lift off the transmission cover. Unhook the spring (A) from the screw (B). 6008-209 Check that the parking brake is not engaged.

  • Page 35: Replacing The Air Filter

    MAINTENANCE Replacing the Air Filter If the engine seems to lack power or does not run smoothly this may be because the air filter is clogged. If run with a soiled air filter, carbon can build-up on the spark plugs and lead to malfunction.

  • Page 36: Replacing The Fuel Filter

    MAINTENANCE Replacing the Fuel Filter Replace the fuel filter mounted on the supply line after every 100 hours (once per season) or more frequently if it is clogged. Replace the filter as follows: Open the engine cover. Move the hose clamps away from the filter. Use a pair of flat pliers.

  • Page 37: Checking The Battery Acid Level

    MAINTENANCE Checking the Battery Acid Level Check that the acid level in the battery lies between the markings. When refilling, only distilled water may be used to fill the cells. WARNING! What to do in case of contact with battery acid External: Rinse thoroughly with water.

  • Page 38: Main Fuse

    MAINTENANCE Main Fuse The fuse is placed in a detachable holder under the battery case’s lid, in front of the battery. Type: Flat pin, 15 A Do not use any other type of fuse when changing. A blown fuse needs to be replaced. Pull the fuse from the holder when changing.

  • Page 39: The Cutting Unit Components

    MAINTENANCE The Cutting Unit Components In the instructions below, a cutting unit with a rear ejector is shown, but the same principles apply to all cutting units unless otherwise stated. The components mentioned are: • A. Catch. • B. Interior plug •...
  • Page 40 MAINTENANCE Push the unit in so that the interior plugs (B) touch the bottom of the equipment frame’s grooves. 8009-018 Hook in the height adjustment handle’s (E) rear fastener: Move the cutting height lever to the forward position. Loosen the stay by pulling the frame’s forward section up or down.

  • Page 41: Adjusting The Unit's Parallelism And Cutting Height

    MAINTENANCE Adjusting the Unit’s Parallelism and Cutting Height The base machine is adjusted at the factory. When a new cutting unit is attached, you need to adjust the parallelism and cutting height. Starting position: Check the air pressure in the tyres 60 kPa (0.6 bar).

  • Page 42: Checking And Adjusting The Ground Pressure

    MAINTENANCE Checking and Adjusting the Ground Pressure In order to achieve the best mowing result the cutting unit should follow the ground without touching it too heavily. Pressure is adjusted using a screw and spring on each side of the Rider.

  • Page 43: Checking The Blades

    MAINTENANCE Checking the Blades It is important that the blades are undamaged and well-ground to give the best mowing result. Check that the blades are screwed tightly with sufficient torque (45 Nm). IMPORTANT INFORMATION Replacement or sharpening of the blades should be carried out by an authorised service representative.

  • Page 44: Removing The Cutting Unit

    MAINTENANCE Removing the Cutting Unit WARNING! Exercise caution. Risk of crush injuries Place the machine on a flat surface. Lock the brakes by pressing down the pedal and locking with the push-button. 8009-328 Lift the cutting unit with the mechanical lifting lever.
  • Page 45 MAINTENANCE Unhook the height adjustment handle (E) by moving the rear part forward: Loosen the stay if necessary by pulling the frame’s forward section up or down. 8009-169 10. Pull the handle (D) and unit simultaneously. Release the handle when the unit has come out a bit. 8009-170 11.

  • Page 46: Removing The Cutting Unit Frame

    MAINTENANCE Removing the Cutting Unit Frame Starting position for removing the unit frame: • Cutting unit removed. Twist the catch out so that the forward fastener can be lifted from the cutting unit. 8009-184 Move the unit frame backwards so that the tongue of the cutting unit releases its grip on the bar of the unit frame and lift the frame off.

  • Page 47: Attaching The Belt

    MAINTENANCE Attaching the Belt Place the forward part of the belt in place and hang the forward part around the handle of the safety catch. Put the belt on the middle pulley and against the anti-scalp rollers. 8009-009 Press the guide plate down under the anti-scalp rollers and push the belt into place.

  • Page 48: Changing The Cutting Unit's Belt

    MAINTENANCE Changing the Cutting Unit’s Belt WARNING! Protect your hands with gloves when working with the blades. There is a risk of crush injuries when working with the belt. Belt changes on the Combi unit. On these cutting units with ”collision-proof” blades, the blades are driven by one V-belt.

  • Page 49: Lubrication

    LUBRICATION Lubrication Lubrication Schedule When in daily use, the weekly lubrication (1/52) schedule should be carried out twice a week. 8009-344 English-...

  • Page 50: General

    LUBRICATION General Remove the ignition key to prevent unintentional movements during lubrication. When lubricating with an oilcan, it ought to be filled with engine oil. When lubricating with grease, unless otherwise stated, grease 503 98 96-01 or another chassis or ball bearing grease offering good corrosion protection shall be used.
  • Page 51 LUBRICATION 2. Chains in the Frame Tunnel Remove the cover from the frame tunnel, see point 1. Lubricate the chains in the frame tunnel with an oilcan or chain lubricant spray for motorcycles. Lubricate the steering cable pulley axle with grease.
  • Page 52 LUBRICATION Check the oil level in the engine when the Rider stands horizontal. Fold up the engine cover. Remove the dipstick, wipe it clean, and then replace it. The dipstick shall not be screwed into place. Take the dipstick out again and read the oil level.
  • Page 53 LUBRICATION 7. Cutting Unit Remove the nose cover. Lubricate using an oilcan: A. The catch - Joints and bearings Lubricate using grease: B. Interior plug C. Groove for equipment frame 6020-004 8. Three-point Link Lube nipple located behind right front wheel. Lubricate with grease gun until grease appears.
  • Page 54 LUBRICATION 11. Hydraulic Oil Filter, Change Remove the oil filter. If necessary, use a filter remover. Wipe new, clean engine oil onto the seal for the new filter. Mount the filter by hand with + 3/4 turn. Remove the transmission cover and fill the transmission’s oil tank, about 0.3 l oil.
  • Page 55 LUBRICATION 14. Transmission Oil Level Check the oil level in the transmission by looking through the air intake mesh. The oil level shall be between the MIN and MAX markings on the oil container when at +20°C. If the oil needs to be filled, you must first remove the transmission cover.
  • Page 56 LUBRICATION Accessories Lubrication or other maintenance of optional equipment or accessories, see Accessories on page 15, is not described in this manual. This equipment too, naturally, requires maintenance. See the manuals for the respective accessories for instructions. It’s good practice to make a note of maintenance or necessary actions preformed on this page. English-...

  • Page 57: Trouble Shooting Guide

    TROUBLE SHOOTING Trouble Shooting Guide Problem Cause The engine will not start. • Fuel tank empty • Incorrect fuel type • Faulty spark plugs • Faulty spark plug connections • Dirt in the carburettor or fuel line Starter does not turn the engine •...

  • Page 58: Trouble Shooting

    TROUBLE SHOOTING Problem Cause Engine overheating • Engine overloaded • Air intake or cooling fins clogged • Damaged fan • Too little or no oil in the engine • Faulty pre-ignition • Faulty spark plugs Battery does not charge • One or more battery cells faulty •...

  • Page 59: Storage

    STORAGE Storage Winter Storage At the end of the mowing season, the Rider should be readied for storage, likewise if it will not be in use for more than 30 days. Fuel allowed to stand for long periods of time (30 days or more) can leave sticky residues that can clog the carburettor and disrupt engine function.

  • Page 60: Service

    When ordering spare parts, please specify the purchase year, model, type, and serial number of the Rider. Always use genuine Husqvarna spare parts. An annual check-up or trimming at an authorised service representative is a good way to ensure that your Rider performs at its best the following season.

  • Page 61: Electrical And Hydraulic Systems

    ELECTRICAL SYSTEM Electrical and Hydraulic Systems 8009-356 Electrical System: Component Locations 8009-186 Microswitch, hydrostatic transmission Key for colour abbreviations in wiring diagram Microswitch, cutting unit RD = Red Microswitch, seat BL = Blue Ignition lock VT = White Chronometer SV = Black Start relay GL = Yellow Motor connectors...

  • Page 62: Hydraulic System

    HYDRAULIC SYSTEM 8009-357 Hydraulic System: Component Locations Steering servo Pump in hydrostatic transmission Hydraulic oil filter Lift cylinder Pressure limiting valve Control valve for lift cylinder Keep the hydraulic system clean. Remember to: • Thoroughly clean before the top-up cap is opened or any connector loosened. •...

  • Page 63: Technical Data

    TECHNICAL DATA Technical Data Rider ProFlex 21 II Dimensions Length base machine 2,120 mm with towing eye Length with Combi 122 2,550 mm Width base machine 1,100 mm Width with cutting unit 1,330 mm Height 1,100 mm Operating weight base machine...

  • Page 64: Cutting Unit

    TECHNICAL DATA Cutting Unit Combi 122 Cutting width 1,220 mm Cutting heights 7 positions, 40-100 mm Blade length 450 mm Width 1,330 mm Weight with a-frame 68 kg Length machine with unit 2,550 mm In order to introduce improvements the specification and design are subject to alteration without prior notice.

  • Page 65: Eu Declaration Of Conformity

    We, Husqvarna AB, SE-561 82 Huskvarna, Sweden, tel: +46-36-146500, declare under sole responsibility that the Husqvarna ProFlex 21 II Raider, from 2002’s serial numbers and onwards (the year is clearly stated in plain text on the rating plate with subsequent serial number), conforms with the requirements of the COUNCIL’S DIRECTIVE:...
  • Page 66 English-...

  • Page 67: Service Journal

    SERVICE JOURNAL Service journal Action Delivery Service Fill the battery with battery acid and charge for four hours. Fit the steering wheel, seat and, where applicable, other components. Attach the cutting unit. Adjust the cutting unit: Adjust the lifting springs (the weight of the cutting unit should be 12-15 kg) if a brush is to be used, set to maximum spring power).

  • Page 68: 25-Hour Service

    SERVICE JOURNAL Action Date, mileage reading, stamp, signature 25-Hour Service Clean the air cleaner’s pre-filter (Oil-foam element). Notes (shorter intervals for dusty operating conditions) Clean the engine’s cooling air intake and the transmission’s air intake. Clean the fuel pump’s air filter. (for dusty operating conditions) This field is intended for keeping a journal English-...

  • Page 69: 50-Hour Service

    SERVICE JOURNAL Action Date, mileage reading, stamp, signature 50-Hour Service Clean/change the air cleaner’s pre-filter (Oil-foam element). Notes (shorter intervals for dusty operating conditions) Clean the engine’s cooling air intake and the transmission’s air intake. Clean the fuel pump’s air filter. Clean the fuel pump’s air filter.

  • Page 70: 100/200-Hour Service

    SERVICE JOURNAL Action Date, mileage reading, stamp, signature 100/200-Hour Service Change engine oil. Replace the oil filter every 200 hours. Notes Clean/change the air cleaner’s pre-filter (Oil-foam element). Clean the air cleaner’s paper filter. Replace every 200 hours. (shorter intervals for dusty operating conditions) Clean the engine’s cooling air intake and the transmission’s air intake.

  • Page 71: 300-Hour Service

    SERVICE JOURNAL Action Date, mileage reading, stamp, signature 300-Hour Service Inspect the machine. Additional work? Notes Change engine oil. Change the air filter (Oil-foam element). Change the air filter (paper filter). Clean the fuel pump’s air filter. Check/adjust the cutting height. Check/adjust the parking brake.

  • Page 72: At Least Once Each Season

    SERVICE JOURNAL Action Date, mileage reading, stamp, signature At Least Once Each Season Change the engine oil (100 hours). Notes Clean/change the air cleaner’s pre-filter (Oil-foam element) (25 hours). (shorter intervals for dusty operating conditions) Clean/change the air cleaner’s paper filter (100 hours). (shorter intervals for dusty operating conditions).
  • Page 73 SERVICE JOURNAL Action Date, mileage reading, stamp, signature English-...
  • Page 74 ´+H%@¶6L¨...
  • Page 75 Svenska –...
  • Page 76 114 00 53-26 ´+H%@¶6L¨ 2002W10...
