Specifications

VID2VGATV VID2DVIDTV
Video @ 1V p-p, 75 ohm, Y @ 1V p-p, 75ohm
Input Signal Levels
Color @ 0.7V p-p, 75 ohm, YCbCr, RGBH
Output Format YPbPr / HDTV RGBHV
Output Connector HD15 female 29-pin D-Shell
Digital
RGB @ 0.7v p-p, H&V Sync @ 3V p-p,
Output Signal
Y @ 1V p-p, Pb, Pr @ 0.7V p-p, 75 ohm
Weight
8.5 oz. (240 g) 9.5 oz. (270 g)
5.7 x 3.0 x 1.2 in. 6.3 x 3.0 x 1.2 in.
Dimensions
146 x 77 x 30 mm 161 x 77 x 30 mm
Power Source
5VDC, 2A
6
Instruction Manual
