NOTE: The clearances expressed in inches are those approved for installation in the United States.
The clearances in expressed in millimeters are those approved for installations in Canada. Different
test standards for the respective countries may result in differences in the clearance requirements.

The Floor

One of the main necessary precautions when installing a wood stove is to leave sufficient space
between the stove (top, sides, back, front, and under stove pipes) and any other material that can
catch fire.
NOTE: the floor protection need's only to be a standard ember protection.
Floor pad at Parallel Installation
Model Floor protection
Scan 60 USA
Scan 60 Canada
Scan 61 USA
Scan 61 Canada
Parallel installation
A B
16"
457 203
16"
457 203
6
C D
9,5" 8"
317
9,5" 8"
317
E F
43,8" 33,7"
1240 1010
42" 33,7"
1192 1010
