Alcove Installation Requirements:

Whenever the stove is placed in a location where the ceiling height is less than 7' tall, it is
considered an alcove installation. Because of the reduced height, the special requirements listed
below must be met.
Alcove installation:
Model
Scan 60 USA
Scan 60 Canada
Scan 61 USA
Scan 61 Canada
Connector pipe
Double wall
Double wall
Double wall
Double wall
A B C
60 48 21
1525 1210 535
60 48 21
1525 1210 535
10
D E F
12 12.5 15
304 315 381
12 12.5 13
304 315 330
G
33
840
33
840
