A S S E M B LY- A N D I N S T R U C T I O N S M A N U A L
GB
Scan 65-series
Congratulations on your new Scan wood-burning stove
You have purchased a product by one of Europe's leading manufacturers of wood-burning stoves, and we are sure that you will have years of
pleasure with your purchase. To make the best possible use of your stove, it is important that you follow our advice and instructions.
Read through this Assembly and Instruction Manual carefully before you start to assemble your stove.
Product registration number
Please indicate the product registration number at any enquiry
S C A N A / S - D K- 5 4 9 2 V I S S E N B J E R G

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 65-1 and is the answer not in the manual?

Questions and answers

Related Manuals for SCAN 65-1

Summary of Contents for SCAN 65-1

  • Page 1 A S S E M B LY- A N D I N S T R U C T I O N S M A N U A L Scan 65-series Congratulations on your new Scan wood-burning stove You have purchased a product by one of Europe’s leading manufacturers of wood-burning stoves, and we are sure that you will have years of pleasure with your purchase.

  • Page 2: Table Of Contents

    Connecting piece / rear outlet Fitting the natural stones Fresh air intake Closed combustion system Indicator for control of air supply Scan 65 open plinth Accessories ......................20 Heat accumulating stones Fitting the top plate of natural stones Instruction for use ....................21...

  • Page 3: Technical Data

    The same applies to the fitting of accessories or extra Instruction Manual. equipment not supplied by Scan A/S. This could also be the case if parts that are necessary for the operation and safety of the stove are When you install any kind of fireplace or stove, you must inform the dismantled or removed.
  • Page 4 Assembly and Instruction Connecting piece external diameter 148 mm Manual. Approval type Intermittent fuelling* The Declaration of Performance (DoP) is available from www.scan.dk Test in compliance with EN 13240 65-1, 65-3, 65-5, 65-7 & 65-9 Technical data Unit 0,08...

  • Page 5: Dimension Sketch

    T E C H N I C A L D ATA Dimension sketch 65-1, 65-2, 65-3 & 65-4 A-A ( 1 : 10 ) Bund A-A ( 1 : 10 ) Bund Bund Centre rear outlet ** Height to the begin-...
  • Page 6 T E C H N I C A L D ATA Dimension sketch Dimension sketch 65-1 LB & 65-2 LB Centre rear outlet ** Height to the begin- Centre rear outlet ning of the connecting ** Height to the begin-...

  • Page 7: Type Plate

    T E C H N I C A L D ATA Type plate Product registration number All Scan wood-burning stoves are fitted with a type plate that speci- All Scan wood-burning stoves are provided with a product registra- fies the approval standards and the distance to flammable materials.

  • Page 8: Additional Accessories

    T E C H N I C A L D ATA Additional accessories Disposal of packaging Your Scan stove may come supplied with the following packaging: • Small shaped floor plate in glass or steel WOOD PACKAGING: • Large shaped floor plate in glass or steel The wood packaging can be reused and after final use can be inciner- •...

  • Page 9: Assembly

    Brændeovn på palle VÆGT: SIGN: can 64 EMNE: 90064020 TG.NR: AREAL: Krog Iversen & Co A/S 21-08-12 DATO: SIGN: VÆGT: DK-5492 Vissenbjerg© Folder\Designs\Scan 64\90064020.idw AREAL: Krog Iversen & Co A/S DK-5492 Vissenbjerg© rking Folder\Designs\Scan 64\90064020.idw Montage afdækningsknapper 90064027 EMNE: TG.NR:...

  • Page 10: Positioning Your Wood-Burning Stove

    If the stove is to be connected to a steel chimney, the chimney require- ments in terms of safety distances must be met. Distance to flammable materials, shown with insulated flue pipe 65-1, 65-3, 65-5,65-7 & 65-9 65-2, 65-4, 65-6, 65-8 & 65-10 Without side windows)

  • Page 11: Distance To Flammable Materials, Shown With Un-Insulated Flue Pipe

    Distance to flammable materials, shown with un-insulated flue pipe 65-1, 65-3, 65-5,65-7 & 65-9 65-2, 65-4, 65-6, 65-8 & 65-10 (Without side windows) (With side windows) Brændbar + uisoleret røgrør - Scan 64 uden sideglas Scan 64 90064049 AVN: EMNE: TG.NR:...

  • Page 12: Distance To Firewall

    Flammable material Firewall Firewall Opstilling til brandmur, scan 64 med sideglas Scan 64 TG.N NAVN: EMNE: 25-08-11 MATERIALE: VÆGT: DATO: DIMENSION: AREAL: Scan A/ Brandmur og isoleret røgrør - Scan 64 uden sideglas Scan 64 NAVN: EMNE: TG.NR: DK-5492 Visse...

  • Page 13: Height Adjustment Of Stove

    A floor plate can be made of steel or glass, but the stove can also be erected on clinker concrete, natural stone or similar materials. This Scan wood-burning stove has an integrated floor plate at the bot- tom and can thus be erected directly on flammable material without the need for further protection underneath the stove.

  • Page 14: Existing Chimney And Pre-Fabricated Element Chimney

    If you intend to connect your stove to an existing chimney, it makes The connecting piece is placed loosely in the top outlet of the stove. sense to contact an authorised Scan dealer, or a local chimney sweep, for advice. These experts will also let you know if your chimney needs The gasket for the connecting piece and the screws for fastening the renovating.

  • Page 15: Connecting Piece / Rear Outlet

    NAVN: EMNE: TG.NR: 30-08-12 DATO: MATERIALE: VÆGT: SIGN DIMENSION: AREAL: Krog Iversen & Co A/S DK-5492 Vissenbjerg© C:\Working Folder\Designs\Scan 64\90064014.idw STI: Connecting piece Ceramic asket Montage af røgstuds i topafgang 90064014 EMNE: TG.NR: Afmontage topplade + røgstuds Scan 64 NAVN: EMNE: TG.NR...
  • Page 16 Varmeskjold løftes af ovn Scan 64 NAVN: EMNE: 31-08-12 MATERIALE: VÆGT: DATO: DIMENSION: AREAL: Krog Iversen & DK-5492 Visse C:\Working Folder\Designs\Scan 64\90064052.idw STI: Afmontage dækplade for bagafgang can 64 EMNE: 90064012 TG.NR: Fastening points 30-08-12 VÆGT: DATO: SIGN: Afmontage dækplade for bagafgang...
  • Page 17 TG.NR: DIMENSION: AREAL: Krog Iversen & Co A/S 31-08-12 VÆGT: DATO: SIGN: DK-5492 Vissenbjerg© C:\Working Folder\Designs\Scan 64\90064028.idw STI: 4 pcs. M5X10 mm screw AREAL: Krog Iversen & Co A/S DK-5492 Vissenbjerg© older\Designs\Scan 64\90064025.idw Montage af røgstuds i topafgang Scan 64...

  • Page 18: Fitting The Natural Stones

    Each natural stone must be mounted with distance bushings and screws which are already mounted in the stones. 65-3 65-4 Gasket 65-7 65-8 Scan 64-3 og Scan 64-4 m. isoleringsbånd f. fedtsten Scan 64 90064046 NAVN: EMNE: Scan 64-3 og Scan 64-4 m. isoleringsbånd f. fedtsten TG.NR:...

  • Page 19: Fresh Air Intake

    15. DK-5492 Vissenbjerg© Folder\Designs\Scan 64\90064032.idw Montage af fedtstenssider 90064032 EMNE: TG.NR: Connect outside air to the connection piece underneath the com- bustion chamber. 29-08-12 VÆGT: DATO: SIGN: AREAL: Krog Iversen & Co A/S DK-5492 Vissenbjerg© ng Folder\Designs\Scan 64\90064032.idw...

  • Page 20: Accessories

    Heat-storage stones are made from a special material with a high 29-08-12 MATERIALE: VÆGT: DATO: SIGN: heating capacity. The stones are heated up during the firing and Scan 64 med fedtstensplade for topafgang Scan 64 NAVN: EMNE: TG.NR: 90064017 Scan 64 med fedtstenstopplade for bagafgang...

  • Page 21: Instruction For Use

    DATO: MATERIALE: VÆGT: SIGN: DIMENSION: AREAL: Krog Iversen & Co A/S DK-5492 Vissenbjerg© C:\Working Folder\Designs\Scan 64\90064037.idw STI: Handle for riddling grate IMPORTANT! This screw (M5X6) must be placed as shown in the picture,to prevent secondary air control closure beyond the 35mm open position .

  • Page 22: Instructions For Heating

    We recommend the use of fire lighters, or similar products, which quickly as possible on days when the draught in the chimney is poor are available from your Scan dealer. Using fire lighters helps light the due to unfavorable wind and weather conditions. You need to get a wood more quickly and keeps the combustion process clean.

  • Page 23: Handling Fuel

    I N S T R U C T I O N S F O R H E AT I N G Handling fuel Selecting wood/fuel You can use any type of wood as fuel. However harder woods, such as beech or ash, are generally better for heating, as they burn more evenly and create less ash.

  • Page 24: Maintenance

    Clean your wood-burning stove by wiping it down with a dry, lint-free cloth. If the paint finish gets damaged, you can purchase repair paint in spray form from your Scan dealer. As slight differences in color shade are possible, we recommend you spray a larger area to achieve a natural blend.
  • Page 25 Holder for upper TG.NR: baffle plate 29-08-12 DATO: MATERIALE: VÆGT: DIMENSION: AREAL: Krog Iversen & Co DK-5492 Vissenbj C:\Working Folder\Designs\Scan 64\90064033.idw STI: 65-2, 65-4, 65-6, 65-8 & 65-10 65-1, 65-3, 65-5, 65-7 & 65-9 (with side windows) (without side windows)

  • Page 26: Troubleshooting

    Scan dealer with a warranty claim. • Is the chimney the right height for its surroundings? The warranty covers all parts which in the opinion of Scan A/S require • At rear outlet, check that the flue pipe does not obstruct...
  • Page 27 Own comments...
  • Page 28 Version: Scan A/S-DK-5492 Vissenbjerg UK 90065500 01.01.2018...
