- Page 1 KPC-1530/1730 Fanless Industrial Panel PC with Intel® Atom N270 + Intel® 945GSE/ ICH7-M User’s Guide KPC-1530/ 1730 User’s Manual...
- Page 2 © 2009 Quanmax Inc. All rights reserved. The information in this user’s guide is provided for reference only. Quanmax does not assume any liability arising out of the application or use of the information or products described herein. This user’s guide may contain or reference information and products protected by copyrights or patents and does not convey any license under the patent rights of Quanmax, nor the rights of others.
-
Page 3: Table Of Contents
Power Connection ................27 Operating System and Drivers ............28 Chapter 4 Maintenance and Prevention ..............29 Chapter 5 Interface & Jumper Setting ..............30 External Connectors ................30 Jumper Setting ..................32 KPC-1530/ 1730 User’s Manual... -
Page 4: Figures
Figure 1 Mechanical Layout - Front and Side ..........15 Figure 2 Mechanical Layout - I/O Panel ............. 15 Figure 3 Mechanical Dimensions (KPC-1530) ........... 16 Figure 4 Mechanical Dimensions (KPC-1730) ........... 17 Figure 5 Removing the rear cover .............. 18 Figure 6 Mechanical Internal Layout ............ -
Page 5: Tables
Table 8 CN 10, PS/2 KB/MS Connector ............. 32 Table 9 JP4, COM1 Signal / Power Selection ..........32 Table 10 JP5/ 6/ 7, COM2/ 3/ 4 Signal / Power Selection ......32 Table 11 JP3, Clear CMOS Selection ............32 KPC-1530/ 1730 User’s Manual... -
Page 6: Safety Instructions
Use extreme caution when installing or removing components. Refer to the installation instructions in this user’s guide for precautions and procedures. If you have any questions, please contact Quanmax Post-Sales Technical Support. WARNING High voltages are present inside the chassis when the unit’s power cord is plugged into... -
Page 7: Preventing Electrostatic Discharge
Static electricity can harm system boards. Perform service at an ESD workstation and follow proper ESD procedure to reduce the risk of damage to components. Quanmax strongly encourages you to follow proper ESD procedure, which can include wrist straps and smocks, when servicing equipment. -
Page 8: Preface
Remove all items from the box. If any items listed on the purchase order are missing, notify Quanmax customer service immediately. Inspect the product for damage. If there is damage, notify Quanmax customer service immediately. Refer to “Warranty Policy” for the return procedure. -
Page 9: Warranty Policy
Quanmax or its authorized agent; or if the failure is caused by accident, acts of God, or other causes beyond the control of Quanmax or the manufacturer. Neglect, misuse, and abuse shall include any installation, operation, or maintenance of the product other than in accordance with the user’s guide. -
Page 10: Maintaining Your Computer
Quanmax. Limitation of Liability In no event shall Quanmax be liable for any defect in hardware, software, loss, or inadequacy of data of any kind, or for any direct, indirect, incidental, or consequential damages in connection with or arising out of the performance or use of any product furnished hereunder. - Page 11 Line conditioners keep a system’s AC power source voltage at a fairly constant level and, therefore, can handle brownouts. Because of this added protection, line conditioners cost more than surge protectors. However, line conditioners cannot protect against a complete loss of power. KPC-1530/ 1730 User’s Manual...
- Page 12 UPS systems, and the UPS system should be Underwriters Laboratories (UL) safety approved. CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS KPC-1530/ 1730 User’s Manual...
-
Page 13: Chapter 1 Introduction
Check list Take out the KPC-1530/1730 from the carton box, check if the unit is properly secure in the plastic bag. Check the contents of the carton box:... -
Page 14: Product Specifications
410 x 315 x 82 mm (W x H x D) 8.5 kg Weight 6.4 kg Power Input AC 100-240V(Optional DC-12V or DC-24V) Mounting Type VESA, Panel Mount Compliant CE, FCC Class A, IP65 front bezel Table 1 Specifications KPC-1530/ 1730 User’s Manual... -
Page 15: Mechanical Layout
Figure 1 Mechanical Layout - Front and Side WARNING Be sure not to block any air vents on the computer. Blocked air vents can cause thermal problems. I/O Panel Figure 2 Mechanical Layout - I/O Panel KPC-1530/ 1730 User’s Manual... -
Page 16: Figure 3 Mechanical Dimensions (Kpc-1530)
Chapter 1 Mechanical Dimensions Figure 3 Mechanical Dimensions (KPC-1530) KPC-1530/ 1730 User’s Manual... -
Page 17: Figure 4 Mechanical Dimensions (Kpc-1730)
Chapter 1 Figure 4 Mechanical Dimensions (KPC-1730) KPC-1530/ 1730 User’s Manual... -
Page 18: Chapter 2 Assembly/Disassembly
Remove the screws securing the rear panel of the chassis as shown. Figure 5 Removing the rear cover 2) Remove the rear cover. Note the locations of the internal components of the system. KPC-1530/ 1730 User’s Manual... -
Page 19: Memory Module Installation
Figure 7 Align the SO-DIMM Memory Module with the onboard socket Fully insert the module into the socket until a “click” is heard. Press down on the SO-DIMM so that the tabs of the socket lock on both sides of the module KPC-1530/ 1730 User’s Manual... -
Page 20: Installation Pci Card
BIOS configuration. The product provides space for a half-length PCI expansion card. Before installing your card, make sure it meets the following height restrictions. Figure 9 PCI card height restrictions KPC-1530/ 1730 User’s Manual... - Page 21 Remove the PCI raiser card holder (1) and PCI slot cover (2) by loosening the retaining screw as shown. Fully insert the PCI card into the PCI raiser card Replace PCI raiser card holder and secure with the retaining screw. KPC-1530/ 1730 User’s Manual...
-
Page 22: Hdd & Odd Installation
Figure 10 HDD & ODD Installation NOTE Above procedure is for KPC-1730 only. If you want to install HDD & ODD in KPC-1530, you have to secure ODD to the ODD bracket and secure the ODD bracket to the chassis first. -
Page 23: Vesa Mounting
Chapter 2 VESA Mounting The product comes with VESA FDMI 75/100 standard mounting holes as shown below. Use 4 screws with the appropriate length for your mounting bracket. Figure 11 Mounting hole locations KPC-1530/ 1730 User’s Manual... -
Page 24: Wall Mounting
Chapter 2 Wall Mounting Below are the demonstrations of how to use Quanmax wall-mount kits Step1 Secure the VESA kit to the panel PC using the 4 screws. Step2 Install the wall-mount kit to the proper place of the wall by using the 6 screws. -
Page 25: Panel Mounting
The Panel PC can be panel mounted and comes with brackets and screws for this purpose. The required cutout for panel mounting and maximum panel thickness is shown below. Figure 13 Panel Mount Cut-out hole and maximum panel thickness KPC-1530/ 1730 User’s Manual... -
Page 26: Figure 14 Panel Mounting
Covers by firmly inserting a flathead screwdriver and bending them back and forth until they break free from the chassis. “KPC-1530: 9 Bracket Opening Covers” “KPC-1730: 10 Bracket Opening Covers” Step2 Install the Panel Mount Seal on the inside edge of the Panel PC... -
Page 27: Chapter 3 Getting Started
DC 12V (Optional DC 24V) Make sure the power distribution to the DC power feed wires is disconnected. Loosen the screws securing the terminal block to the DC inlet as shown and remove it from the chassis. KPC-1530/ 1730 User’s Manual... -
Page 28: Operating System And Drivers
You can download the drivers for the product from the Quanmax website www.quanmax.com and install as instructed there. For other operating systems, please contact Quanmax. -
Page 29: Chapter 4 Maintenance And Prevention
Chapter 4 Chapter 4 Maintenance and Prevention Your KPC-1530/1730 system requires minimal maintenance and care to keep it operating correctly. Occasionally wipe the system with a soft dry cloth. You should only remove persistent dirt by use of a soft, slightly damp cloth (use only a mild detergent). -
Page 30: Chapter 5 Interface & Jumper Setting
Signal Signal LAN LED Status Status Led Orange / Green Yellow No link 10M link 10M active Blink 100M link Green on 100M active Green on Blink 1000M link Orange on 1000M active Orange on Blink KPC-1530/ 1730 User’s Manual... -
Page 31: Table 5 Com1 Rs-232/422/485 Connector (Db9)
RTS, Request to send CTS, Clear to send +5V / +12V / RI, Ring indicator Note：Selected by JP5-7 Table 7 VGA Connector (DB15) Signal Name Pin Signal Name Green Blue DDC2B data HSYNC VSYNC DDC2B clock KPC-1530/ 1730 User’s Manual... -
Page 32: Jumper Setting
6-8 Short Pin 9 of COM2/ 3/ 4 = +5V 8-10 Short Pin 9 of COM2/ 3/ 4 = RI (Default) Table 11 JP3, Clear CMOS Selection Jumper Status Open Normal Operation (Default) Short Clear CMOS KPC-1530/ 1730 User’s Manual... -
Page 33: Figure 15 Jumper And Connector Locations
Chapter 5 Figure 15 Jumper and Connector Locations KPC-1530/ 1730 User’s Manual...
