- Page 1 HPC-1050/1051 10.1" Fanless Panel PC w/ Intel® BayTrail Processors User’s Guide HPC-1050/1051 User’s Manual...
-
Page 2: Table Of Contents
Chapter 3 AMI BIOS Setup..................23 Overview..................... 23 Main Menu ..................24 Advanced Menu.................. 25 Power Menu..................33 Security Menu..................34 Boot Menu ..................35 Save & Exit Menu ................36 Chapter 4 Driver Installation .................. 38 HPC-1050/1051 User’s Manual... -
Page 3: Figures & Tables
Figure 8 VESA Mounting Hole Locations ........... 19 Figure 9 Wall Mounting Demonstrations ............ 20 Figure 10 Install Desktop Stand ..............21 Table 1 HPC-1050 product specifications ..........11 Table 2 BIOS Main Menu ................24 Table 3 Advanced Menu................25 Table 4 Advanced Menu –... -
Page 4: Safety Instructions
Turning off the system power switch does not remove power to components. When Working Inside a Computer Before taking covers off a computer, perform the following steps: Turn off the computer and any peripherals. HPC-1050/1051 User’s Manual... -
Page 5: Preventing Electrostatic Discharge
ESD workstation or grounded. This will discharge any static electricity that may have built up in your body. When transporting a sensitive component, first place it in an antistatic container or packaging. HPC-1050/1051 User’s Manual... -
Page 6: Instructions For Lithium Battery
Do not dispose of lithium batteries in domestic waste. Dispose of the battery according to the local regulations dealing with the disposal of these special materials (e.g. to the collecting points for disposal of batteries) HPC-1050/1051 User’s Manual... -
Page 7: Preface
Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. HPC-1050/1051 User’s Manual... -
Page 8: Maintaining Your Computer
Buildings in which climate is controlled usually maintain an acceptable level of humidity for system equipment. However, if a system is located in an unusually humid location, a dehumidifier can be used to maintain the humidity within an HPC-1050/1051 User’s Manual... - Page 9 Surge protectors should be used with all UPS systems, and the UPS system should be Underwriters Laboratories (UL) safety approved. HPC-1050/1051 User’s Manual...
-
Page 10: Chapter 1 Introduction
Introduction Overview The HPC-1050 Series 10.1" Panel PC is combining the Intel® BayTrail Processors for a wide range of industrial applications. Storage includes a 2.5" SATA hard drive or a solid-state drive (SSD). Supported interfaces include 2x GbE LAN, 2x COM port, 1x USB .3.0, 4x USB 2.0 ports, 1x HDMI, 1x VGA thus easily meeting a broad range... -
Page 11: Product Specifications
Operating Temperature: With Industrial SSD: -10 ~ 50° C (Ambient with air flow) With 2.5" HDD: 0 ~ 40° C (Ambient with air flow) Storage Temperature: -20°C to 80°C, 0%-90%, non-condensing Certification CE, FCC Class A Table 1 HPC-1050 product specifications HPC-1050/1051 User’s Manual... -
Page 12: System Tour
The supplied power adapter converts AC power to DC for use with this jack. Power supplied through this jack supplies power to the PC. To prevent damage to the PC, always use the supplied power adapter. HDMI HDMI connector for display output HPC-1050/1051 User’s Manual... - Page 13 Chapter 1 D-Sub 9 pin connector for RS-232/422/485 connection D-Sub 15 pin VGA connector for display output HPC-1050/1051 User’s Manual...
-
Page 14: Mechanical Dimensions
Chapter 1 Mechanical Dimensions 262 x 200 x 61 mm ( W x D x H ) Figure 2 Mechanical Dimensions HPC-1050/1051 User’s Manual... -
Page 15: Chapter 2 Getting Started
Chapter 2 Chapter 2 Getting Started Setting up your PC Connecting the monitor Connect the HDMI / VGA cable from your display to the HDMI / VGA port. HDMI Figure 3 VGA / HDMI HPC-1050/1051 User’s Manual... -
Page 16: Figure 4 Connect Usb Mouse & Keyboard
Chapter 2 Connecting USB mouse & keyboard Your HPC-1050 does not come with a keyboard and mouse, but you can use any USB keyboard or mouse with your computer. Figure 4 Connect USB mouse & keyboard NOTE Using a third-party USB mouse or keyboard may require software drivers. -
Page 17: Figure 6 Com Port
Chapter 2 COM ports COM ports with the pin definitions. COM1~COM2 RS-232 / 422 / 485 Port DB-9 Half Duplex Full Duplex RS-232 RS-422 RS-485 RS-485 DATA- DATA+ Figure 6 COM port HPC-1050/1051 User’s Manual... -
Page 18: Figure 7 Turning On The System
Chapter 2 Turning on the system Connect the power adapter cable to the DC jack (DC IN) of the HPC-1050 Connect the power cable to the power adapter Connect the power cable to a power outlet Press the power switch on the front panel to turn on the system... -
Page 19: Vesa Mounting
The product comes with VESA FDMI 75 standard mounting holes as shown below. Use 4 screws with the appropriate length for your mounting bracket. Figure 8 VESA Mounting Hole Locations NOTE To fasten the metal shelf, your monitor must comply with VESA75 standard. The VESA mounting kit is optional. HPC-1050/1051 User’s Manual... -
Page 20: Wall Mount Kit
6 screws. Step3 Attach the panel PC to the wall-mount kit which has been well fixed on the wall. Step4 Secure the wall-mount kit and panel PC with screw by using Phillips Screwdriver Figure 9 Wall Mounting Demonstrations HPC-1050/1051 User’s Manual... -
Page 21: Desktop Stand
Step2 Secure the VESA kit to the desktop stand using the 4 screws. (M4x5L round head) Step3 Secure the panel PC to the desktop stand using the 4 screws. (M4x5L flat head) Figure 10 Install Desktop Stand HPC-1050/1051 User’s Manual... -
Page 22: Operating System And Drivers
2. If your system goes into suspend mode, please push the power button for 2 seconds to wake up the system. Maintenance and Prevention Your HPC-1050 system requires minimal maintenance and care to keep it operating correctly. Occasionally wipe the system with a soft dry cloth. -
Page 23: Chapter 3 Ami Bios Setup
It is possible for the CMOS battery to fail, which will cause data loss in the CMOS only. If this happens you will need to reconfigure your BIOS settings. HPC-1050/1051 User’s Manual... -
Page 24: Main Menu
+- Change Opt. Frequency 1333 MHz F1: General Help System date [Sun 02/15/2015] F2: Previous Values System time [13:23:12] F3: Optimized Defaults Access Level Administrator F4 Save & Exit ESC Exit Version 2.16.1242. Copyright (C) 2013, American Megatrends, Inc. HPC-1050/1051 User’s Manual... -
Page 25: Advanced Menu
Version 2.16.1242. Copyright (C) 2013, American Megatrends, Inc. Onboard LAN 1 Controller Options: Disabled, Enabled Onboard LAN 1 Boot Options: Disabled, Enabled Onboard LAN 2 Controller Options: Disabled, Enabled Onboard LAN 2 Boot Options: Disabled, Enabled Audio Controller Options: Disabled, Enabled HPC-1050/1051 User’s Manual... -
Page 26: Table 4 Advanced Menu – Display Configuration
LVDS Panel Type Options: 1024x600 18Bit 1CH LVDS Backlight Control Mode Options: Valtage LVDS Backlight Control -Voltage Options: 0.0V ; 0.5V ; 1.0V ; 1.5V ; 2.0V ; 2.5V ; 3.0V ; 3.5V ; 4.0V ; 4.5V ; 5.0V HPC-1050/1051 User’s Manual... -
Page 27: Table 5 Advanced Menu –Super Io Configuration
IO=2F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; IO=3E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; IO=2E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; Serial Port Type Options: RS232, RS422, RS485 HPC-1050/1051 User’s Manual... -
Page 28: Table 7 Advanced Menu – Super Io Configuration – Serial Port
IO=2F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; IO=3E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; IO=2E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; Serial Port Type Options: RS232, RS422, RS485 HPC-1050/1051 User’s Manual... -
Page 29: Table 8 Advanced Menu –Cpu Chipset Configuration
ESC Exit Version 2.16.1242. Copyright (C) 2013, American Megatrends, Inc. EIST Options: Disabled, Enabled Turbo Mode Options: Disabled, Enabled Limit CPUID Maximum Options: Disabled, Enabled Execute Disable Bit Options: Disabled, Enabled Intel Virtualization Technology Options: Disabled, Enabled HPC-1050/1051 User’s Manual... -
Page 30: Table 9 Advanced Menu –Sata Configuration
Version 2.16.1242. Copyright (C) 2013, American Megatrends, Inc. SATA Options: Disabled, Enabled SATA Mode Options: IDE Mode, AHCI Mode Serial ATA Port 1 Empty Port 1 Options: Enabled, Disabled mSATA Port 1 Empty Port 1 Options: Enabled, Disabled HPC-1050/1051 User’s Manual... -
Page 31: Table 10 Advanced Menu –Usb Configuration
Legacy USB Support Options: Enabled, Disabled, Auto XHCI Legacy Support Options: Enabled, Disabled XHCI Hand-off Options: Enabled, Disabled EHCI Hand-off Options: Disabled, Enabled USB Mass Storage Device Support Options: Disabled, Enabled XHCI Mode Options: Enabled, Smart Auto HPC-1050/1051 User’s Manual... -
Page 32: Table 11 Advanced Menu –H/W Monitor
: +5.066 V +VMEN : +1.349 V F3: Optimized Defaults F4 Save & Exit ESC Exit Version 2.16.1242. Copyright (C) 2013, American Megatrends, Inc. CPU Warning Temperature Options: Disabled, 80 C, 85 C, 90 C, 95 C HPC-1050/1051 User’s Manual... -
Page 33: Power Menu
Resume from S3 By PS/2 Mouse Options: Disabled, Enabled Resume By PCIE Device Options: Disabled, Enabled Resume By Ring Device Options: Disabled, Enabled Resume By RTC Alarm Options: Disabled, Enabled WatchDog Timer Configuration WDT Function Options: Disabled, Enabled HPC-1050/1051 User’s Manual... -
Page 34: Security Menu
The password length must be in the following range: +- Change Opt. Minimum Length F1: General Help Maximum length F2: Previous Values F3: Optimized Defaults Administrator Password F4 Save & Exit User Password ESC Exit Version 2.16.1242. Copyright (C) 2013, American Megatrends, Inc. HPC-1050/1051 User’s Manual... -
Page 35: Boot Menu
Version 2.16.1242. Copyright (C) 2013, American Megatrends, Inc. Full Screen LOGO Display Options: Disabled, Enabled Bootup Numlock State Options: On, Off Keyboard Detect Warning Options: Enabled, Disabled CSM Support Options: Enabled, Disabled Boot Option Filter Options: UEFI and Legacy, Legacy only, UEFI only HPC-1050/1051 User’s Manual... -
Page 36: Save & Exit Menu
Load Optimal Default values for all the setup values. This option allows you to load optimal default values for each of the parameters on the Setup menus, which will provide the best performance settings for your system. The F9 key can be used for HPC-1050/1051 User’s Manual... - Page 37 Load Optimal Default values for all the setup values. This option allows you to load failsafe default values for each of the parameters on the Setup menus, which will provide the most stable performance settings. The F8 key can be used for this operation. HPC-1050/1051 User’s Manual...
-
Page 38: Chapter 4 Driver Installation
You can download the drivers for the HPC-1050 from our website and install as instructed there. For other operating systems, please contact us.
