- Page 1 KPC-1200 12.1 Home Automation Panel PC with Intel® Atom N450 User’s Guide KPC-1200 User’s Manual...
- Page 2 © 2010 Quanmax Inc. All rights reserved. The information in this user’s guide is provided for reference only. Quanmax does not assume any liability arising out of the application or use of the information or products described herein. This user’s guide may contain or reference information and products protected by copyrights or patents and does not convey any license under the patent rights of Quanmax, nor the rights of others.
-
Page 3: Table Of Contents
Advanced Menu ................27 Boot Menu ..................30 Chipset Menu ................... 31 Power Menu ..................33 Security Menu .................. 34 Exit Menu ..................35 Chapter 4 Driver Installation .................. 37 KPC-1200 User’s Manual... -
Page 4: Figures
Figure 9 Panel Mount Cut-Out Hole and Maximum Panel Thickness ...... 22 Figure 10 Panel Mounting ..................23 Tables Table 1 KPC-1200 product specifications ..............14 Table 2 BIOS Main Menu ..................25 Table 3 IDE Device Setting Menu ................25 Table 4 System Information .................. -
Page 5: Safety Instructions
Use extreme caution when installing or removing components. Refer to the installation instructions in this user’s guide for precautions and procedures. If you have any questions, please contact Quanmax Post-Sales Technical Support. Access can only be gained by service persons or by users who have been instructed about the reasons for the restrictions applied to the location and about any precautions that shall be taken;... -
Page 6: When Working Inside A Computer
Static electricity can harm system boards. Perform service at an ESD workstation and follow proper ESD procedure to reduce the risk of damage to components. Quanmax strongly encourages you to follow proper ESD procedure, which can include wrist straps and smocks, when servicing equipment. -
Page 7: Instructions For Lithium Battery
(e.g. to the collecting points for disposal of batteries) Voltage Ratings The external power adaptor of the KPC-1200 has the following voltage ratings: Input: 100-240 VAC, 50-60 Hz Output: +12Vdc, 5 Amp, 60 Watts... -
Page 8: Preface
Remove all items from the box. If any items listed on the purchase order are missing, notify Quanmax customer service immediately. Inspect the product for damage. If there is damage, notify Quanmax customer service immediately. Refer to “Warranty Policy” for the return procedure. -
Page 9: Warranty Policy
Quanmax or its authorized agent; or if the failure is caused by accident, acts of God, or other causes beyond the control of Quanmax or the manufacturer. Neglect, misuse, and abuse shall include any installation, operation, or maintenance of the product other than in accordance with the user’s guide. -
Page 10: Limitation Of Liability
Quanmax. Limitation of Liability In no event shall Quanmax be liable for any defect in hardware, software, loss, or inadequacy of data of any kind, or for any direct, indirect, incidental, or consequential damages in connection with or arising out of the performance or use of any product furnished hereunder. - Page 11 20 percent below the normal AC line voltage level. Line Conditioner Line conditioners go beyond the overvoltage protection of surge protectors. KPC-1200 User’s Manual...
- Page 12 Surge protectors should be used with all UPS systems, and the UPS system should be Underwriters Laboratories (UL) safety approved. KPC-1200 User’s Manual...
-
Page 13: Chapter 1 Introduction
Chapter 1 Introduction Overview The KPC-1200 is a Fanless Industrial Panel PC with 12.1” TFT LCD touch screen display. Specifically designed for low power, cost effective applications, the KPC-1200 features an ultra-slim design for limited space environments and is equipped with an Intel® Atom N450 processor at 1.66 GHz with 512 KB L2 cache, 2.5”... -
Page 14: Table 1 Kpc-1200 Product Specifications
Input: 100-240 VAC, 50-60 Hz Power Unit Output: +12Vdc Operating: 0°C to 40°C, 0%-90%, non-condensing Temperature / Storage: -20°C to 80°C, 0%-90%, non-condensing Humidity Desktop Bracket, VESA-mount (optional) Mounting CE, FCC Class A Certifications Table 1 KPC-1200 product specifications KPC-1200 User’s Manual... -
Page 15: System Tour
The stereo headphone jack is used to connect the system’s audio out signal to amplified speakers or headphones. MIC-IN The microphone jack is designed to connect the microphone used for video conferencing, voice narrations, or simple audio recordings. KPC-1200 User’s Manual... -
Page 16: Figure 2 Side View
The supplied power adapter converts AC power to DC for use with this jack. Power supplied through this jack supplies power to the PC. To prevent damage to the PC, always use the supplied power adapter. Side View Figure 2 Side View KPC-1200 User’s Manual... -
Page 17: Mechanical Dimensions
USB allows many devices to run simultaneously on a single computer, with some peripheral acting as additional plug-in sites or hubs. Mechanical Dimensions Dimension: 343 x 269 x 29 mm (W x H x D) Figure 3 Mechanical Dimensions KPC-1200 User’s Manual... -
Page 18: Chapter 2 Getting Started
Figure 4 Connecting the VGA cable NOTE When the system reboots without connecting the VGA, there might be no image on screen when you insert the VGA cable. Please pressing <Ctrl>+<Alt>+<F4> simultaneously to show the image on screen. KPC-1200 User’s Manual... -
Page 19: Figure 5 Connecting Usb Mouse & Keyboard
Chapter 2 Connecting USB mouse & keyboard Your KPC-1200 does not come with a keyboard and mouse connector, but you can use any USB keyboard or mouse with your computer. Figure 5 Connecting USB mouse & keyboard NOTE Using a third-party USB mouse or keyboard may require software drivers. -
Page 20: Turning On The System
Chapter 2 Turning on the system Connect the power adapter cable to the DC jack (DC IN) of the KPC-1200 Connect the power cable to the power adapter Connect the power cable to a power outlet Press the power switch on the front panel to turn on the system Figure 7 Turing on the system KPC-1200 User’s Manual... -
Page 21: Vesa Mounting
Chapter 2 VESA Mounting The product comes with VESA FDMI 75/100 standard mounting holes as shown below. Use 4 screws with the appropriate length for your mounting bracket. Figure 8 VESA Mounting Hole Locations KPC-1200 User’s Manual... -
Page 22: Panel Mounting
The Panel PC can be panel mounted and comes with brackets and screws for this purpose. The required cutout for panel mounting and maximum panel thickness is shown below. Figure 9 Panel Mount Cut-out hole and maximum panel thickness KPC-1200 User’s Manual... -
Page 23: Figure 10 Panel Mounting
Chapter 2 Below are the demonstrations of how to do panel mounting. Step1 Tightening the screws as shown right. Step2 Side view of the screws on the KPC-1200. Step3 Done Figure 10 Panel Mounting KPC-1200 User’s Manual... -
Page 24: Chapter 3 Ami Bios Setup
This chapter provides a description of the AMI BIOS. The BIOS setup menus and available selections may vary from those of your product. For specific information on the BIOS for your product, please contact Quanmax. NOTE: The BIOS menus and selections for your product may vary from those in this chapter. -
Page 25: Main Menu
LBA Mode disabled. LBA/ Large Mode [Auto] Select Screen DMA Mode [Auto] ↑↓ Select Item S.M.A.R.T [Auto] +- Change Field Tab Select Field F1 General Help F10 Save and Exit ESC Exit V02.68 (C)Copyright 1985-2009, American Megatrends, Inc. KPC-1200 User’s Manual... -
Page 26: Table 4 System Information
Select Screen Intel® ATOM ™ CPU N450 @ 1.66GHz ↑↓ Select Item Speed :1666MHz F1 General Help F10 Save and Exit Physical Memory ESC Exit Size : 1024MB Sped ; 667MHz V02.68 (C)Copyright 1985-2009, American Megatrends, Inc. KPC-1200 User’s Manual... -
Page 27: Advanced Menu
Audio Controller [Auto] ↑↓ Select Item Onboard LAN Controller [Enabled] +- Change Field Onboard LAN OPTROM [Disabled] Tab Select Field >OnboardATA Devices F1 General Help F10 Save and Exit ESC Exit V02.61 (C)Copyright 1985-2006, American Megatrends, Inc. KPC-1200 User’s Manual... -
Page 28: Table 7 Onboard Ata Configurations
A d v a n c e d OnBoard ATA Configuration Options SATA Controller [Enabled] Configure SATA as [IDE] AHCI Disabled Select Screen ↑↓ Select Item +- Change Option F1 General Help F10 Save and Exit ESC Exit V02.68 (C)Copyright 1985-2009, American Megatrends, Inc. KPC-1200 User’s Manual... -
Page 29: Table 8 Hardware Health Configuration
:3.408 V +- Change Option :5.130 V F1 General Help Input :11.868 V F10 Save and Exit ESC Exit V02.68 (C)Copyright 1985-2009, American Megatrends, Inc. CPU Shutdown Temperature Options: Disabled, 80°C/ 176°F, 85°C/ 185°F, 90°C/ 194°F, 95°C/ 203°F KPC-1200 User’s Manual... -
Page 30: Boot Menu
When set to Enabled, the system waits for F1 key to be pressed when error occurs. Options: Disabled, Enabled Hit ‘DEL’ Message Display [Enabled] When set to Enabled, the system displays the message ‘Press DEL to run Setup’ during POST Options: Disabled, Enabled KPC-1200 User’s Manual... -
Page 31: Chipset Menu
Select the amount of system memory used by the Internal graphics device. Options: Enabled 1MB, Enabled 8M Hyper Threading Technology Options: Disabled, Enabled Panel Backlight Voltage Options: 0.0, 0.5, 1.0, 1.5, 2.0, 2.5, 3.0, 3.5, 4.0, 4.5, 5.0 KPC-1200 User’s Manual... -
Page 32: Table 11 Video Function Configurtion
F10 Save and Exit ESC Exit V02.68 (C)Copyright 1985-2009, American Megatrends, Inc. DVMT Mode Select Options: Fixed Mode, DVMT Mode DVMT/FIXED Memory Options: 128MB, 256MB, Maximum DVMT Boot Display Device Options: VGA+LVDS Flat Panel Type Options: 1024x768 18Bit 1C KPC-1200 User’s Manual... -
Page 33: Power Menu
Options: No, Yes Restore on AC Power Loss Options: Power OFF, Power ON, Last State Resume From S3 By USB Device Options: Disabled, Enabled Resume By PCI-E Device Options: Disabled, Enabled Resume On RTC Alarm Options: Disabled, Enabled KPC-1200 User’s Manual... -
Page 34: Security Menu
Change User Password Select this item to set or change the user password. The User Password item on top of the screen displays the default Not Installed. After you have set a password, this item displays Installed. KPC-1200 User’s Manual... -
Page 35: Exit Menu
After selecting this option, a confirmation appears. Select [Yes] to discard any changes and load the previously saved values. Load Optimal Defaults Load Optimal Default values for all the setup values. This option allows you to load KPC-1200 User’s Manual... - Page 36 Load Optimal Default values for all the setup values. This option allows you to load failsafe default values for each of the parameters on the Setup menus, which will provide the most stable performance settings. The F8 key can be used for this operation. KPC-1200 User’s Manual...
-
Page 37: Chapter 4 Driver Installation
Chapter 4 Driver Installation If your KPC-1200 does not come with an operating system pre-installed, you will need to install an operating system and the necessary drivers to operate it. After you have finished assembling your system and connected the appropriate power source, power it up using the power supply and install the desired operating system.
