Peak 602VL User's Guide

1-1 Specifications

Specification
System Architecture
Half size SBC with ISA Golden finger
Intel Socket 370 Celeron/Pentium III with 66/100/133MHz FSB
CPU Support
Intel Brand New Socket 370 FC-PGA Celeron / Pentium III CPU with 128/256K cache on die,
Processor Max. speed up to 1GHZ
Support streaming SIMD instruction
Main Memory
Support SDRAM up to 256MB (Max.)
168 pin DIMM socket ×1
Support 100/133MHz SDRAM interface
BIOS
Award System BIOS
Plug & Play support
Advanced Power Management support
Advanced Configuration & Power Interface support
Jumper less for CPU FSB
4M bits flash ROM
Chip Set
Intel 815E chipsets
82815 × 1 Graphics and Memory Controller Hub (GMCH)
82801 × 1 I/O Controller Hub (ICH2)
82802 × 1 Firmware Hub (FWH)
On Board VGA
Intel 82815 (GMCH) chipset integrated with Graphics controller
Hardware motion compensation assist for software MPEG/DVD decode
15 pin CRT connector ×1
On Board LAN
Signal Channel Ethernet support
Intel 82801 (ICH2) chipset integrated LAN controller
Intel 82562EM (PLC) Platform LAN Connect
Introduction
+
by running at 66/100/133MHz FSB
Rev. B0 Dec. 2000
1-2
