Peak 602VL User's Guide
JP11: SUSPEND LED CONNECTOR
PIN 1
PIN 2
JP12: TEMPERATURE CONNECTOR
PIN 1
PIN 2
JP15: LAN ISOLATOR
ON
OFF
JP17: LAN SPEED LED CONNECTOR
PIN 1
PIN 2
JP18: LAN LINK/ACT LED CONNECTOR
PIN 1
PIN 2
AT/ATX Power Select Jumper:
1-2
2-3
JP3: ATX Power Connector: ( 3 Pin signals connect to Backplane )
PIN 1
PIN 2
PIN 3
IR:
PIN 1
PIN 2
PIN 3
PIN 4
PIN 5
Jumpers Switch and Connectors
Rev. B0
GND
SUSLED
RESISTOR INPUT
RESISTOR INPUT
LAN ISOLATOR
NORMAL
3.3V Power
LAN Speed Signal
LINK Signal
Active Signal
AT POWER
ATX POWER
5VSB
GND
Wake Up Signal
VCC
CIRR
IRRX
GND
IRTX
Dec. 2000
2-4
