Peak 602VL User's Guide
2-2 Jumpers / Switches / Connectors
JP1: RTC RESET
1-2 Short
2-3 Short
JP2: NEXCOM PCI PERIPHERAL CONNECTOR
PIN No.
Description
1
+5V
3
AD1
5
AD3
7
AD5
9
AD7
11
+5V
13
AD9
15
AD11
17
AD13
19
AD15
21
+5V
23
AD17
25
AD19
27
AD21
29
AD23
31
+5V
33
AD25
35
AD27
37
AD29
39
AD31
41
+5V
43
BE#1
45
BE#3
47
Frame#
49
IRDY#
51
+5V
53
DEVSEL#
55
SERR#
Jumpers Switch and Connectors
Rev. B0
NORMAL
RTC RESET
PIN No.
Description
2
AD0
4
AD2
6
AD4
8
AD6
10
Ground
12
AD8
14
AD10
16
AD12
18
AD14
20
Ground
22
AD16
24
AD18
26
AD20
28
AD22
30
Ground
32
AD24
34
AD26
36
AD28
38
AD30
40
Ground
42
BE#0
44
BE#2
46
PAR
48
TRDY#
50
Ground
52
STOP#
54
N/C
56
REQ#2
Dec. 2000
2-2
