Hardware Pack - Master Chef T440 Assembly Manual

H E A V Y A R T I C L E N E E D S 2 T O L I F T
THIS MANUAL MUST REMAIN WITH THE PRODUCT AT ALL TIMES
To ORDER non-warranty replacement parts or accessories, or to register your warranty,
please visit us on the web at
www.masterchefbbqs.com
CAUTION
Sharp edges. Wear gloves when assembling
your grill.
CAUTION
Read and follow all safety statements,
assembly instructions, use and care
directions before attempting to assemble
and cook.
INSTALLER OR ASSEMBLER/CONSUMER
This manual should be kept with the BBQ at
all times.
WARNING
Failure to follow all of the Manufacturer's
instructions could result in hazardous fires,
explosions, property damage, or serious
personal injury or even death.
Follow all leak check procedures carefully
prior to operation of barbecue, even if grill
was dealer assembled. Do not try to light
this barbecue without reading the Lighting
Instructions section of this manual.
T H I S B A R B E C U E I S F O R O U T D O O R U S E O N L Y
CO NTAC T C AL L C E N T R E IF A NY PA RTS A RE M I S S I N G
1 - 8 7 7 - 7 0 7 - 5 4 6 3
DANGER
1. If you smell Gas:
a. Shut off gas to the appliance
b. Extinguish any open flame
c. Open lid
d. If odor continues, keep away from
the appliance and immediately
call your gas supplier or your
fire department
2. Requires two people to complete the
assembly process.
3. Beware of sharp edges.
WARNING
1. Do not store or use gasoline or other
flammable liquids or vapours in the
vicinity of this or any other appliance.
2. An LP cylinder not connected for use shall
not be stored in the vicinity of this or any
other appliance.

HARDWARE PACK

TOOLS NEEDED FOR ASSEMBLY
• #2 Phillips screwdriver (long and short)
• ¼" Slotted screwdriver (long and short)
• Adjustable wrench
• Pliers
Before assembling the barbecue, read these
instructions carefully.
Assemble the barbecue on a flat, clean surface.
Grill is heavy. You should have at least two people
assemble the barbecue together.
Notes: Do not fully tighten all the nuts during
this initial stage.
Caution:
Sheet metal can cause injury. Wear gloves when installing the grill.
1
¼" x 13mm Screw
X 10
4
#8X3/8" Self Tapping Screw
X 14
7
Wheel Spacer
X 2
10
Washer (Wheel)
X 1
KEY # DESCRIPTION PART NUMBER
1 1/4" x 13mm Screw 20120-13013-036
2 Wing Screw G306-0025-9084
3 1/4"-20UNC Nut 31220-13000-036
4 #8X3/8" Self Tapping Screw 22500-42010-136
5 Ø7Flat Washer 40300-07000-036
6 Ø7 Fiber Washer G431-0018-9000
7 Wheel Spacer G305-0024-9088
8 Hitch Pin G306-0005-9088
9 Ø7Lock Washer 41400-07000-206
10 Washer (Wheel) 40300-08000-036
11 1/4" - 20UNCX18 Screw 20102-13018-036
2 3
Wing Screw ¼" - 20UNC Nut
X 1
5
6
Ø7 Fiber Washer
Ø7Flat Washer
X 6
8
9
Hitch Pin Ø7Lock Washer
X 1
11
1/4" - 20UNCX18 Screw
X 4
1
QUANTITY
10
1
8
14
6
10
2
1
6
1
4
X 8
X 10
