T620 Barbeque
Assembly Manual
85-3008-4 (G65001) Propane
85-3009-2 (G65002) Natural Gas
1 YEAR LIMITED WARRANTY
READ AND SAVE MANUAL FOR FUTURE REFERENCE.
If pre-assembled, leave this manual with unit for
consumer's future reference.
For product inquiries, parts, warranty and
troubleshooting support, please call 1-877-707-5463.
Manual Revision #: 01022009 SA
Advertisement
Related Manuals for Master Chef T620 Barbeque
Summary of Contents for Master Chef T620 Barbeque
- Page 1 T620 Barbeque Assembly Manual 85-3008-4 (G65001) Propane 85-3009-2 (G65002) Natural Gas 1 YEAR LIMITED WARRANTY READ AND SAVE MANUAL FOR FUTURE REFERENCE. If pre-assembled, leave this manual with unit for consumer’s future reference. For product inquiries, parts, warranty and troubleshooting support, please call 1-877-707-5463.
-
Page 2: Hardware Pack
HARDWARE PACK TOOLS NEEDED FOR ASSEMBLY KEY # DESCRIPTION PART NUMBER QUANTITY 1/4”-20UNC x 38 Screw 20120-13038-036 • #2 Phillips screwdriver (long and short) #8X3/8” Self Tapping Screw 22500-42010-136 1/4”-20UNC x 13 Screw 20120-13013-036 • ¼” Slotted screwdriver (long and short) 1/4”-20UNC Nut 31220-13000-036 •... - Page 3 PARTS LIST (PROPANE) FOR 85-3008-4 (G65001) EXPLODED DIAGRAM (PROPANE) FOR 85-3008-4 (G65001) KEY # QUANTITY DESCRIPTION PART NO. Top lid assembly G650-0100-01 Thermometer G430-0022-01 Logo plate G451-0001-01 Top lid handle G650-0001-01 Lid bumpers-back G303-0038-01 Lid bumpers-front G508-0063-01 Screws for lid G430-0024-02 Burner box assembly G650-0300-01...
- Page 4 PARTS LIST (NATURAL GAS) FOR 85-3009-2 (G65002) EXPLODED DIAGRAM (NATURAL GAS) FOR 85-3009-2 (G65002) KEY # QUANTITY DESCRIPTION PART NO. Top lid assembly G650-0100-01 Thermometer G430-0022-01 Logo plate G451-0001-01 Top lid handle G650-0001-01 Lid bumpers-back G303-0038-01 Lid bumpers-front G508-0063-01 Screws for lid G430-0024-02 Burner box assembly G650-0300-01...
-
Page 5: Cart Assembly
ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS c. Assemble the back brace (DC) to the back of CART ASSEMBLY the BBQ cart assembly (C), as shown. TIP: Two People required in this step. Propane model only: To begin, position the bottom shelf (DI) in front of you, with the tank opening positioned on the left side. - Page 6 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS TIP: Turn Cart assembly upside down. Locate a. Assemble the left and right door assembly the large holes on the bottom of the left cart (DG) and (DF) to the cart side panels by side panel legs (DB), for assembling the wheel inserting the fi xed pin-bottom door support axle (DN).
- Page 7 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS LEFT SIDE SHELF ASSEMBLY RIGHT SIDE SHELF ASSEMBLY TIP: To position the left side shelf assembly (EC TIP: To position the right side shelf assembly (EA and ED), insert the two hooks on the side shelf and EB), insert the two hooks on the side shelf assembly into the two hooks, located on the left assembly into the two hooks located on the...
- Page 8 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS d. Using the wing nut (#12) provided, assemble TWO PEOPLE REQUIRED IN THIS the side burner (EF) to the side burner drip pan STEP. (EE), as shown. a. Insert the side burner valve stem (CD) through the back of the left side shelf fascia (ED).
- Page 9 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS Place the fl ame tamers (BG) into the burner box To assemble the warming rack (BE), insert the assembly (BA), as shown. stationary wire into the holes on the sides of the Stationary wire lid. Insert warming rack pivot legs into the holes on the inside of the burner box assembly (BA), as shown.
- Page 10 ASSEMBLY INSTRUCTIONS NATURAL GAS MODELS ONLY Attach the natural gas hose (CE) to the side burner valve fi tting (CD), as shown. ATTENTION: In order to complete installation of your natural gas BBQ a 1/2” or 3/8” adapter may be required to connect your BBQ’s natural gas hose to your home gas supply.
