S E R I A L # :
Traveling Chef Propane Barbecue
This instruction manual contains important information necessary for the proper assembly and safe use of this appliance.
O N E
Y E A R
L I M I T E D
8 5 - 1 6 9 9 - 0
Attention: Read and follow all instructions
before assembling and using the appliance.
For product inquires, parts, warranty and
troubleshooting support, please call 1-877-707-5463.
S A F E U S E , C A R E A N D A S S E M B L Y M A N U A L
W A R R A N T Y
G 2 0 9 0 1
D A N G E R
If you smell Gas
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your
gas supplier or your fire department.
W A R N I N G
1. Do not store or use gasoline or other
flammable vapours and liquids in the
vicinity of this or any other appliance.
2. An LP cylinder not connected for use
shall not be stored in the vicinity of this
or any other appliance.
W A R N I N G
Failure to follow all of the Manufacturer's
instructions could result in hazardous
fires, explosions, property damage, or
serious personal injury or even death.
W A R N I N G
Follow all leak check procedures carefully
prior to operation of barbecue, even if
grill was dealer assembled. Do not try to
light this barbecue without reading the
Lighting Instructions section of this manual.
T H I S B A R B E C U E I S F O R
O U T D O O R U S E O N L Y
Advertisement
Related Manuals for Master Chef 76 cm (30?)
Summary of Contents for Master Chef 76 cm (30?)
- Page 1 S E R I A L # : Traveling Chef Propane Barbecue S A F E U S E , C A R E A N D A S S E M B L Y M A N U A L This instruction manual contains important information necessary for the proper assembly and safe use of this appliance.
- Page 2 W A R R A N T Y 1 Year Limited Warranty This Masterchef ® Barbecue carries a 1 year limited warranty against defects in manufacturing workmanship. This Limited Warranty is nontransferable and becomes void if used for commercial or rental purposes. This warranty applies only when grill is used in Canada.
- Page 3 I N F O R M A T I O N The installation of this appliance must be in accordance with all local codes, or in the absence of local codes: I N S T A L L A T I O N Canadian installation must conform to the current national standards, which at •...
- Page 4 The Cylinder must also be equipped with: A shut-off valve with a correct cylinder valve outlet as specified in current standards. • Canada: CAN/ CGA 1.6g-M97 Outdoor Gas Grills. • U.S.A: ANSI Z21.58a-2006/CSA 1.6a-2006 Outdoor Cooking Appliances. • a) Constructed and marked in accordance with the Specifications for LP-Gas Cylinders of the U.S.
- Page 5 F I L L I N G T H E For safety reasons the LP gas cylinder, if supplied with your barbecue, has been shipped empty. The cylinder must be filled prior to use and must have the air L . P . C Y L I N D E R purged.
- Page 6 Attention: Improperly lighting the barbecue can activate the flow control fea- ture, resulting in lower heat output. If this occurs, the re-flow feature must be reset by turning off all the burner controls and the cylinder valve. Wait at least 30 seconds before slowly turning on the cylinder valve, and then after another 5 seconds turn the burner valve on and light the barbecue.
- Page 7 P R I O R T O U S I N G Do not use your barbecue until you have carefully read and fully understand all the information in this manual. Please ensure the following: Your barbecue is properly assembled. •...
- Page 8 L I G H T I N G Prior to lighting your barbeque, visually check all hoses before each use, for nicks, cracking, abrasions or cuts. If the hose is found to be damaged in any way, do not T H E B A R B E C U E use your barbeque.
- Page 9 Match-Lighting Do not lean over grill while lighting. 1. Open lid. Turn on gas at LP cylinder. 2. Push in and turn main burner knob to HI. Be sure burner lights and stays lit. 3. Place lit match into match holder, then into lighting hole on left side of grill. Match Lighting Procedure Lighting the other side of the dual burner: Once one side of the dual burner has been lit, push in and turn the other control knob to ‘HIGH’.
- Page 10 T I P S O N U S I N G First time use: Before cooking, turn on the barbecue and operate on “High” for about 10–15 minutes with the lid open. Close the lid and continue to run the bar- Y O U R B A R B E C U E becue on “High”...
- Page 11 C L E A N I N G To get many years of service out of your barbecue, perform the following mainte- nance procedures. A N D M A I N T E N A N C E Cooking Grate: Do not use steel brushes, as they can scratch the coating, allow- ing moisture to settle and cause rusting.
-
Page 12: Troubleshooting Guide
T R O U B L E S H O O T I N G G U I D E Problem Possible Causes Corrective Action Burner will not light Blocked venturi tubes Clean out blockage • • (match or igniter) Cylinder or gas supply valve turned off Open cylinder or gas supply valve •... - Page 14 P A R T S L I S T Item No. Quantity Description Part No. Top Lid G209-0001-01 8 5 - 1 6 9 9 - 0 ( G 2 0 9 0 1 ) Upper Hinge G206-0002-01 Handle tube G202-0002-01 Handle end G202-0003-01...
- Page 15 Manual Hardware Pack...
- Page 16 A S S E M B L Y I N S T R U C T I O N S Hardware Pack List Key No. Description Part Number Quantity Tools needed for assembly are shown below. 1/4"-20UNC Flange Nut 31220-13000-036 1/4-20UNC x 75 Screw 20120-13075-036 Before assembling the barbecue, please ensure...
- Page 17 Assemble the handle (AF) to the lid (AA) by using hardware #10 (x2), #2 (x2), #3 (x2), #4 (x2) as shown in the drawing. Assemble the control panel (CA) from the inside of the burner box (igniter, valve and knob are a ready pre-assembled) by using #7 (x4), #8 (x4), #9 (x4) as shown in the drawing.
- Page 18 Press the cart leg, locking pins (DC) into the shorter legs. Attach the cart legs (DA) as shown in the drawing. Place the hook (CB) into the hole which is located on the control panel as shown. Then use the hook (CB) to hang the regulator hose (CG) as shown.
- Page 19 D I S T R I B U T O R Trileaf Distribution Trifeuil Toronto, Canada M4S 2B8...
