T360 Propane Barbecue
O N E
Y E A R
L I M I T E D
8 5 - 1 6 3 0 - 2
Read and save this manual for future reference.
If pre-assembled, leave this manual
with unit for consumer's future reference.
For product inquires, parts, and warranty and
troubleshooting support, please call 1-877-707-5463.
S A F E U S E , C A R E A N D A S S E M B L Y M A N U A L
W A R R A N T Y
G 3 0 5 0 5
D A N G E R
If you smell Gas
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your
gas supplier or your fire department.
W A R N I N G
1. Do not store or use gasoline or other
flammable vapours and liquids in the
vicinity of this or any other appliance.
2. An LP cylinder not connected for use
shall not be stored in the vicinity of this
or any other appliance.
W A R N I N G
Failure to follow all of the Manufacturer's
instructions could result in hazardous
fires, explosions, property damage, or
serious personal injury or even death.
W A R N I N G
Follow all leak check procedures carefully
prior to operation of barbecue, even if
grill was dealer assembled. Do not try to
light this barbecue without reading the
Lighting Instructions section of this manual.
T H I S B A R B E C U E I S F O R
O U T D O O R U S E O N L Y
