t480 Barbeque
Assembly Manual
85-3100-2 (G43205) Propane
85-3101-0 (G43206) Natural Gas
1 YeAr liMited WArrAntY
reAd And sAve MAnuAl for future reference.
if pre-assembled, leave this manual with unit for
consumer's future reference.
for product inquiries, parts, warranty and
troubleshooting support, please call 1-877-707-5463.
Manual Revision #: 14082009 PD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T480 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Master Chef T480

  • Page 1 Barbeque Assembly Manual 85-3100-2 (G43205) Propane 85-3101-0 (G43206) Natural Gas 1 YeAr liMited WArrAntY reAd And sAve MAnuAl for future reference. if pre-assembled, leave this manual with unit for consumer’s future reference. for product inquiries, parts, warranty and troubleshooting support, please call 1-877-707-5463.
  • Page 2: Fire Department

    HARDWARE PACK tools needed for AsseMBlY KeY # descriPtion PArt nuMBer QuAntitY #8X3/8” Self Tapping Screw 22500-42010-136 • #2 Phillips screwdriver (long and short) 1/4”-20UNC x13 Screw 20120-13013-036 1/4”-20UNC Nut 31220-13000-036 • ¼” Slotted screwdriver (long and short) NO.8-32UNC x10 Screw 20132-08010-250 •...
  • Page 3 PARts List (PRoPANE) foR 85-3100-2 (G43205) EXPLoDED DiAGRAM (PRoPANE) foR 85-3100-2 (G43205) KeY # QuAntitY descriPtion PArt no. Top lid assembly G432-3700-01 Thermometer G451-0008-01 Logo plate G451-0001-01 Top lid handle G413-0001-01 Lid bumpers-back G303-0038-01 Lid bumpers-front G430-00B8-01 Screws for Lid G430-0024-01 Burner box assembly G432-1900-01...
  • Page 4 PARts List (NAtuRAL GAs) foR 85-3101-0 (G43206) EXPLoDED DiAGRAM (NAtuRAL GAs) foR 85-3101-0 (G43206) KeY # QuAntitY descriPtion PArt no. Top lid assembly G432-3700-01 Thermometer G451-0008-01 Logo plate G451-0001-01 Top lid handle G413-0001-01 Lid bumpers-back G303-0038-01 Lid bumpers-front G430-00B8-01 Screws for Lid G430-0024-01 Burner box assembly G432-1900-01...
  • Page 5: You Will Need

    AssEMBLY iNstRuCtioNs AssEMBLY iNstRuCtioNs Separate the 2 different types of castors, 2 x Attach the upper rail (DC) to the front of the right caster with lock (DK) and 2 x casters (DL). Attach and left cart side panels (DA and DB). the caster with lock (DK) to the back of the tiP: one person should align the upper bottom shelf (DI), and the casters (DL) to the...
  • Page 6 AssEMBLY iNstRuCtioNs AssEMBLY iNstRuCtioNs Assemble the left door hinge (DG) to the left cart Assemble the side panel support brackets (DJ) to side panel (DB). both the right and left cart side panels (DA and DB) and the bottom shelf (DI). tiP: one person should align the left door, note: sMAller Hole on while the second person assembles the...
  • Page 7 AssEMBLY iNstRuCtioNs AssEMBLY iNstRuCtioNs tHis steP reQuires 2 or More riGHt side sHelf AsseMBlY PeoPle. do not AtteMPt Alone. tiP: to position the right side shelf assembly (EA eXtreMelY HeAvY. and EB), insert the two hooks on the side shelf assembly into the two hooks located on the a.
  • Page 8 AssEMBLY iNstRuCtioNs AssEMBLY iNstRuCtioNs left side sHelf AsseMBlY b. two people required in this step. Insert the side burner valve stem (CD) through the back tiP: to position the left side shelf assembly (EC of the left side shelf fascia (ED). Position the and ED), insert the two hooks on the side shelf bezel (#14) on the front of the left side shelf assembly into the two hooks located on the left...
  • Page 9 AssEMBLY iNstRuCtioNs AssEMBLY iNstRuCtioNs e. Use the side burner Venturi clip (#10) to Place the flame tamers (BE) into the burner box connect the side burner to the side burner assembly (BA), as shown. valve. YOU WILL NEED: f. Using the wing nut provided, assemble the side burner (EF) to the side burner drip pan (EE), as shown.
  • Page 10 AssEMBLY iNstRuCtioNs AssEMBLY iNstRuCtioNs nAturAl GAs Models onlY To assemble the warming rack (BG), insert the stationary wire into the holes on the sides of the Stationary Wire Attach the natural gas hose (CE) to the side lid. Insert warming rack pivot legs into the holes Pivot Legs burner valve fitting (CD), as shown.
