BudgeTone-200/201 SIP Phone

User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BudgeTone-200 and is the answer not in the manual?

Questions and answers

Related Manuals for Grandstream Networks BudgeTone-200

Summary of Contents for Grandstream Networks BudgeTone-200

  • Page 1: User Manual

    Artikel 401102 aus Shop: http://www.netzwerk-online.de BudgeTone-200/201 SIP Phone User Manual...

  • Page 2: Table Of Contents

    Table 3: BT Comparison Guide ...................... 7 Table 4: BT Key Features in a Glance.................... 7 Table 5: Hardware Specifications ....................8 Table 6: BT Technical Specifications....................8 Grandstream Networks, Inc. GXP User Manual Page 2 of 33 Firmware 1.2.2.19...
  • Page 3 4. S CREENSHOT OF DVANCED ONFIGURATION 5. S SIP A CREENSHOT OF CCOUNT ONFIGURATION 6. S CREENSHOT OF AVED ONFIGURATION HANGES 7. S CREENSHOT OF EBOOT Grandstream Networks, Inc. GXP User Manual Page 3 of 33 Firmware 1.2.2.19 Last Updated: 12/2009...

  • Page 4: Welcome

    Artikel 401102 aus Shop: http://www.netzwerk-online.de Welcome Thank you for purchasing Grandstream BudgeTone-200/201 IP Phone. You made an excellent choice and we hope you will enjoy all its capabilities. Grandstream's BT SIP IP phone is the innovative IP telephone that offers a rich set of functionality and superb sound quality.

  • Page 5: Installation

    10/100 Switch LAN port for connecting to Ethernet. 10/100Mbps RJ-45 ports for PC (downlink) connection. Power Jack 5V DC power port; UL Certified 2.5mm Headset port HEADSET Grandstream Networks, Inc. GXP User Manual Page 5 of 33 Firmware 1.2.2.19 Last Updated: 12/2009...

  • Page 6: Safety Compliances

    AFETY OMPLIANCES The BudgeTone-200/201 phone is compliant with various safety standards including FCC/CE. Its power adaptor is compliant with UL standard. The phone should only be operated with the universal power adaptor provided with the package. Damages to the phone caused by using other unsupported power adaptors are not covered by the manufacturer’s warranty.

  • Page 7: Product Overview

    Support SIP 2.0, TCP/UDP/IP, PPPoE, RTP/RTCP/SRTP, HTTP, ARP/RARP, ICMP, DNS, DHCP, NTP, TFTP. Superb Audio Quality Advanced Digital Signal Processing (DSP), Silence suppression, VAD, CNG, AGC. Grandstream Networks, Inc. BT200/201 User Manual Page 7 of 33 Firmware 1.2.2.19 Last Updated: 12/2009...

  • Page 8: Table 5: Hardware Specifications

    Silence Suppression, VAD (voice activity detection), CNG (comfort noise generation), ANG (automatic gain control) Acoustic Echo Cancellation (AEC) with Acoustic Gain Control (AGC) for speakerphone mode, Support side tone Grandstream Networks, Inc. BT200/201 User Manual Page 8 of 33 Firmware 1.2.2.19...
  • Page 9 Message waiting indication, support DNS SRV Look up and SIP Server Fail Over Server Features Security DIGEST authentication and encryption using MD5 and MD5-sess, SRTP, SIP over TLS (pending) Grandstream Networks, Inc. BT200/201 User Manual Page 9 of 33 Firmware 1.2.2.19 Last Updated: 12/2009...

  • Page 10: Using The Gxp Sip Enterprise Phone

    OFF when the speakerphone is off ON when the speakerphone is on Handset and Speakerphone/Headset Volume Icons: 0-7 scales to adjust handset / speakerphone volume Grandstream Networks, Inc. BT200/201 User Manual Page 10 of 33 Firmware 1.2.2.19 Last Updated: 12/2009...
  • Page 11 * = J # = K A, b, C, c, d, E, F, G, g, H, h, I, L, n, O, o, P, q, r, S, t, U, u, Y Grandstream Networks, Inc. BT200/201 User Manual Page 11 of 33 Firmware 1.2.2.19...

  • Page 12: Getting Familiar With Keypad

    Artikel 401102 aus Shop: http://www.netzwerk-online.de ETTING AMILIAR WITH EYPAD Up/Down Keys Message Waiting Indicator Menu Button Called Message Callers Hold Transfer Conference Flash Standard Keypad Speaker Send Mute/Delete Grandstream Networks, Inc. BT200/201 User Manual Page 12 of 33 Firmware 1.2.2.19 Last Updated: 12/2009...

  • Page 13: Table 8: Bt Keypad Buttons

    2) Increase ring tone volume when phone in IDLE and off hook to confirm the changed ring tone volume 3) Next menu item browsing when phone is in IDLE mode after MENU key pressed, off hook to interrupt and exit Grandstream Networks, Inc. BT200/201 User Manual Page 13 of 33 Firmware 1.2.2.19...

  • Page 14: Making Phone Calls

    When this option is set to YES, and #XXX is dialed, where X is 0-9 and XXX <=255, phone will make direct IP call to aaa.bbb.ccc.XXX where aaa.bbb.ccc comes from the local IP address REGARDLESS of subnet mask. Grandstream Networks, Inc. BT200/201 User Manual Page 14 of 33 Firmware 1.2.2.19...
  • Page 15 NOTE: If you have a SIP Server configured, a Direct IP-IP still works. If you are using STUN, the Direct IP-IP call will also use STUN. Configure the “Use Random Port” to “NO” when completing Direct IP calls. Grandstream Networks, Inc. BT200/201 User Manual Page 15 of 33 Firmware 1.2.2.19...

  • Page 16: Answer An Incoming Call

    User presses the “FLASH” button and hears a dial tone, then dial the third party’s phone number followed by pressing “SEND” button. If the call is answered, press “TRANSFER” to complete the Grandstream Networks, Inc. BT200/201 User Manual Page 16 of 33 Firmware 1.2.2.19...

  • Page 17: Conference Call

    However, if A the conference initiator hangs up, all calls will be terminated. Checking Message and Message Waiting Indication When BudgeTone-200 is on-hook, pressing the MESSAGE button will trigger the phone to call the VM Server (VMS) configured for the Account.

  • Page 18: Call Features

    BT series phone supports a list of call features: Caller ID Block (or Anonymous Call), Disable/Enable Call Waiting, Call Forward on Busy, Delay, or Unconditional, etc. Following table shows the call features of BudgeTone-200 series phone. Table 9: BT Call Features...

  • Page 19: Configuration Guide

    Press Menu to display the code releases Press ‘;’ or ’9’ to browse Display “[9] Phy Addr” Press MENU to display the physical / MAC address. Display “[10] ring 0” Grandstream Networks, Inc. BT200/201 User Manual Page 19 of 33 Firmware 1.2.2.19 Last Updated: 12/2009...

  • Page 20: Configuration Via Web Browser

    Reboot the phone to have the changes take effect. If, after having submitted some changes, more settings have to be changed, press the menu option needed. Definitions Grandstream Networks, Inc. BT200/201 User Manual Page 20 of 33 Firmware 1.2.2.19...

  • Page 21: Table 11: Device Configuration - Status

    2. Static IP mode: configure all of the following fields: IP address, Subnet Mask, Default Router IP address, DNS Server 1 (primary), DNS Server 2 (secondary). These fields are set to zero by default. Grandstream Networks, Inc. BT200/201 User Manual Page 21 of 33 Firmware 1.2.2.19...

  • Page 22: Table 13: Advanced Settings

    Administrator password. Only the administrator can access the “Advanced Settings” and Password “Account Settings” page. Password field is purposely blank for security reasons after clicking update and saved. The maximum password length is 25 characters. Grandstream Networks, Inc. BT200/201 User Manual Page 22 of 33 Firmware 1.2.2.19...
  • Page 23 “Yes”, the “#” key will immediately send the call. In this case, this key is essentially equivalent to the “Dial” key. If set to “No”, the “#” key is included as part of the dial string. Grandstream Networks, Inc. BT200/201 User Manual Page 23 of 33 Firmware 1.2.2.19...
  • Page 24 Authenticate Default is “No”. If set to “Yes”, configuration file would be authenticated before Conf File acceptance. End user should use default setting. Grandstream Networks, Inc. BT200/201 User Manual Page 24 of 33 Firmware 1.2.2.19 Last Updated: 12/2009...
  • Page 25 System ring tone. Default is North American standard. System Ring Tone Adjust system ring tone frequencies and cadences based on local telecom standard. Grandstream Networks, Inc. BT200/201 User Manual Page 25 of 33 Firmware 1.2.2.19 Last Updated: 12/2009...

  • Page 26: Table 14: Sip Account Settings

    Transmission gain. Its a headset setting to control the voice intensity gain(dB) Receive gain. It’s a headset setting to control the voice intensity. Headset RX gain (dB) Table 14: SIP Account Settings Grandstream Networks, Inc. BT200/201 User Manual Page 26 of 33 Firmware 1.2.2.19 Last Updated: 12/2009...
  • Page 27 This option allows a SIP client to request that the server send the response back Symmetric Routing to the source IP address and port from which the request originated. Grandstream Networks, Inc. BT200/201 User Manual Page 27 of 33 Firmware 1.2.2.19...
  • Page 28 Callee Request Timer If selecting “Yes”, the phone will use session timer when it receives inbound calls with session timer request. Grandstream Networks, Inc. BT200/201 User Manual Page 28 of 33 Firmware 1.2.2.19 Last Updated: 12/2009...
  • Page 29 Default is NO. If set to YES, then for Attended Transfer, the “Refer-To” header Contact uses the transferred target’s Contact header information. Disable Multiple Media Default is No. Attribute in SDP Grandstream Networks, Inc. BT200/201 User Manual Page 29 of 33 Firmware 1.2.2.19 Last Updated: 12/2009...

  • Page 30: Saving The Configuration Changes

    Press the “Reboot” button at the bottom of the configuration menu to reboot the phone remotely. The web browser will then display a message window to confirm that reboot is underway. Wait 30 seconds to log in again. Grandstream Networks, Inc. BT200/201 User Manual Page 30 of 33 Firmware 1.2.2.19...

  • Page 31: Software Upgrade & Customization

    Alternatively, download and install a free TFTP or HTTP server to the LAN to perform firmware upgrades. A free Windows version TFTP server is available: http://support.solarwinds.net/updates/New- customerFree.cfm. Grandstream Networks, Inc. BT200/201 User Manual Page 31 of 33 Firmware 1.2.2.19 Last Updated: 12/2009...

  • Page 32: Configuration File Download

    60 minutes) to have the devices periodically check for upgrades at pre- scheduled time intervals. By defining different intervals in P193 for different devices, a Server Provider can manage and reduce the Firmware or Provisioning Server load at any given time. Grandstream Networks, Inc. BT200/201 User Manual Page 32 of 33 Firmware 1.2.2.19...

  • Page 33: Restore Factory Default Setting

    4 seconds to continue to key in another “2”. Step 3: Press the MENU button again. If the MAC address is correct, the phone will reboot. Wait for phone reboot and the LCD backlight finish flashing. Grandstream Networks, Inc. BT200/201 User Manual Page 33 of 33 Firmware 1.2.2.19...
