  • Page 1 User Manual BudgeTone-100 Series IP Phone Version 1.0.6.2 Grandstream Networks, Inc. www.grandstream.com...

  • Page 2: Table Of Contents

    BudgeTone-100 User Manual Grandstream Networks, Inc. Table of Contents 1 WELCOME - 3 - 2 INSTALLATION - 4 - 2.1 W - 5 - HAT IS NCLUDED IN THE ACKAGE 2.2 S - 5 - AFETY OMPLIANCES 3 PRODUCT OVERVIEW - 6 - 3.1 K...

  • Page 3: Welcome

    Congratulations on becoming an owner of BudgeTone-100 IP telephone! You made an excellent choice and we hope you will enjoy all its capabilities. Grandstream's award-wining BudgeTone-100 series of SIP phones are innovative IP telephones that offer a rich set of functionality and superb sound quality at ultra- affordable price.

  • Page 4: Installation

    BudgeTone-100 User Manual Grandstream Networks, Inc. Installation BudgeTone-100 series IP phones are designed to look and feel like standard telephones. The following photo illustrates the appearance of a BudgeTone IP phone and the use of its key buttons. Menu Volume & Menu...

  • Page 5: What Is Included In The Package

    BudgeTone-100 User Manual Grandstream Networks, Inc. 2.1 What is Included in the Package The BudgeTone-100 phone package contains: 1) One BudgeTone-100 phone 2) One universal power adaptor 3) One Ethernet cable 2.2 Safety Compliances The BudgeTone-100 phone is compliant with various safety standards including FCC/CE.

  • Page 6: Product Overview

    Grandstream Networks, Inc. Product Overview Grandstream IP Phone is a next generation IP network telephone based on industry open standard SIP (Session Initiation Protocol). Built on innovative technology, Grandstream IP Phone features market leading superb sound quality and rich functionalities at mass- affordable price.

  • Page 7: Hardware Specification

    BudgeTone-100 User Manual Grandstream Networks, Inc. 3.2 Hardware Specification There are two models in the BudgeTone-100 family, namely: BudgeTone-101 BudgeTone-102 The table below describes the difference among these models. Model BudgeTone-101 BudgeTone-102 LAN interface 1xRJ45 10Base-T 2xRJ45 10Base-T Phone Case...

  • Page 8: Basic Operations

    BudgeTone-100 User Manual Grandstream Networks, Inc. Basic Operations 4.1 Get Familiar with LCD BudgeTone-100 phone has a numeric LCD of 64mmx24mm size and a backlight. Here is the display when all segments illuminate: 上午 下午 The LCD is equipped with a backlight. When the phone is in the normal idle state, the backlight is off.

  • Page 9: Get Familiar With Keypad

    BudgeTone-100 User Manual Grandstream Networks, Inc. Handset and Speakerphone Volume Icons: 0-7 scales to adjust handset / speakerphone volume Real-time Clock: Synchronized to Internet time server Time zone configurable via web browser Call Logs: 01-99 for CALLED history (dialed number)

  • Page 10: Make Phone Calls

    BudgeTone-100 User Manual Grandstream Networks, Inc. Display the phone numbers called CALLED Display the caller IDs CALLERS MESSAGE Enter to retrieve voice mails or other messages HOLD Temporarily hold the active call TRANSFER Transfer the active call to another party...

  • Page 11: Make Calls Using Ip Address

    BudgeTone-100 User Manual Grandstream Networks, Inc. Examples: To dial another extension on the same proxy, such as 1008, simply pick up handset or press speaker phone, dial 1008 and then press the “SEND/(Re)Dial” button. To dial a PSTN number such as 6266667890, you might need to enter in some prefix number followed by the phone number.

  • Page 12: Handset Mode And Speakerphone Mode

    BudgeTone-100 User Manual Grandstream Networks, Inc. 4.3.4 Handset Mode and Speakerphone Mode Handset mode and Speakerphone mode cannot be enabled at the same time. Pressing the hook-switch or Speakerphone button would toggle the phone between these two modes. 4.3.5 Call Hold While in conversation, pressing the “Hold”...

  • Page 13: Call Features

    BudgeTone-100 User Manual Grandstream Networks, Inc. 4.3.7.2 Attended Transfer The user can transfer an active call to a third party with announcement. The user presses the “flash” button and hears a dial tone, then dial the 3 party’s phone number followed by pressing send button. If the call is answered, press “flash”...
  • Page 14 BudgeTone-100 User Manual Grandstream Networks, Inc. To use this feature, dial “*92” and get the dial tone. Then dial the forward number followed by pressing “send” button and hear dial tone again, then hang up. Cancel Delayed Call Forward To cancel this Forward, dial “*93” and get the dial tone, then...

  • Page 15: Configuration Guide

    BudgeTone-100 User Manual Grandstream Networks, Inc. Configuration Guide 5.1 Configuration with Keypad When the phone is on-hook, press the MENU button to enter MENU state. When the phone goes off-hook or a call comes in, the phone automatically exits the MENU state and prepare for the call.
  • Page 16 BudgeTone-100 User Manual Grandstream Networks, Inc. Menu Item Menu Functions Display “[5] dnS ” Press Menu to display the DNS address Enter new DNS address if DHCP is OFF Press ‘↓’ or ’↑’ to exit Press Menu to (save and) exit Must recycle power to take effective!!! Display “[6] tFtP...
  • Page 17 BudgeTone-100 User Manual Grandstream Networks, Inc. Menu Item Menu Functions Display “[9] codE rEL” Press Menu to display the code releases Press ‘↓’ or ’↑’ to browse line 1 “b 2004-10-11” – date: boot code 2 “ 1. 0. 0.21” – version: boot code 3 “P 2005-03-14”...

  • Page 18: Configuration With Web Browser

    5.2 Configuration with Web Browser BudgeTone-100 series IP phone has an embedded Web server that will respond to HTTP GET/POST requests. It also has embedded HTML pages that allow a user to configure the IP phone through a Web browser such as Microsoft’s IE.

  • Page 19: Configuration Menu

    BudgeTone-100 User Manual Grandstream Networks, Inc. The password is case sensitive and the factory default password is lower case ‘admin’. 5.2.2 Configuration Menu After the correct password is entered in the login screen, the embedded Web server inside the IP phone will respond with the Configuration Menu screen, which is explained in details below.
  • Page 20 BudgeTone-100 User Manual Grandstream Networks, Inc. Status Page: The device ID, in HEX format. This is very important ID for ISP MAC Address troubleshooting. This field shows WAN port IP address. WAN IP Address This field contains the product model info, like HT487 is HT486 Product Model Rev:2.0...
  • Page 21 BudgeTone-100 User Manual Grandstream Networks, Inc. Program: This is the main software release. Software Version Bootloader: This indicates bootloader version. This indicates the web interface version, normally not HTML: changed unless there is new parameter introduced in. This indicates the coder program version, normally not VOC: changed.
  • Page 22 BudgeTone-100 User Manual Grandstream Networks, Inc. Basic settings page: This contains the password for end user to access the Web End user Configuration Menu. This field is case sensitive and maximum Password length is 16 characters. - 22 -...

  • Page 23: Connection

    BudgeTone-100 User Manual Grandstream Networks, Inc. IP Address There are 2 modes under which the IP phone can operate: - If DHCP mode is enabled, then all the field values for the Static IP mode are not used (even though they are still saved in the Flash memory) and the IP phone will acquire its IP address from the first DHCP server it discovers on the LAN it attaches to.
  • Page 24 BudgeTone-100 User Manual Grandstream Networks, Inc. Advanced settings: - 24 -...
  • Page 25 BudgeTone-100 User Manual Grandstream Networks, Inc. - 25 -...
  • Page 26 BudgeTone-100 User Manual Grandstream Networks, Inc. This contains the password for administrator to access the Web Admin Configuration Menu. This field is case sensitive and maximum password length is 16 characters. This field contains the URI string or the IP address (and port, if different from 5060) of the SIP proxy server.
  • Page 27 BudgeTone-100 User Manual Grandstream Networks, Inc. SIP User ID This field contains the login ID used for SIP registration. Typically, this is the account number on an SIP server for this IP phone. This field contains the ID used for authentication purpose. Typically, this is provided by VoIP service provider along with the SIP user ID.
  • Page 28 BudgeTone-100 User Manual Grandstream Networks, Inc. This field contains the number of voice frames to be transmitted in a Voice Frames single packet. When setting this value, the user should be aware of per TX the requested packet time (used in SDP message) because of configuring this parameter.
  • Page 29 BudgeTone-100 User Manual Grandstream Networks, Inc. This parameter allows the user to specify the time frequency (in Register minutes) the BudgeTone phone will refresh its registration with the expiration specified registrar. The default interval is 60 minutes (or 1 hour).
  • Page 30 BudgeTone-100 User Manual Grandstream Networks, Inc. NAT Traversal This parameter defines whether the phone NAT traversal mechanism will be activated or not. This parameter is recommended to be set to YES ALWAYS. If activated (by choosing “Yes”) and a STUN server is also specified, then the phone will behave according to the STUN client specification.
  • Page 31 BudgeTone-100 User Manual Grandstream Networks, Inc. Firmware upgrade can be done via TFTP or HTTP. Firmware Via TFTP: upgrade The IP of TFTP server needs to be configured. If it is non-zero or not blank, the IP phone will attempt to retrieve new configuration file or new code image from the specified tftp server at boot time.
  • Page 32 BudgeTone-100 User Manual Grandstream Networks, Inc. Default is No. Disable call waiting Send DTMF This parameter controls the way DTMF events are transmitted. There are 3 ways: in audio which means DTMF is combined in audio signal (not very reliable with low-bit-rate codec), via RTP (RFC2833), or via SIP INFO.

  • Page 33: Saving The Configuration Changes

    BudgeTone-100 User Manual Grandstream Networks, Inc. 5.2.3 Saving the Configuration Changes Once a change is made, the user should press the “Update” button in the Configuration Menu. The IP phone will then display the following screen to confirm that the changes have been saved.

  • Page 34: Configuration Through A Central Server

    BudgeTone phone for firmware upgrade, remote reboot, configuration changes, etc. Grandstream provides a licensed provisioning system called GAPSLite that can be used to support automated configuration of BudgeTone phone. To enable this feature on the BudgeTone phone, a user just needs to enter the IP address of the GAPS server in the...
  • Page 35 TFTP server field of the configuration screen, or enter the HTTP provisioning Server URL in the HTTP Upgrade Server field. Then reboot the BudgeTone phone. For details on how GAPS works, please contact Grandstream and refer to the documentation of GAPS product provided.

  • Page 36: Software Upgrade

    Here, firmware.mycompany.com is the FQDN of the HTTP server, “:6688” is the TCP port the HTTP server listening to, “/Grandstream/1.0.6.0” is the RELATIVE directory to the root dir in HTTP web server. Thus, you can put different firmware into different directory as well.
  • Page 37 Grandstream provides a NAT-friendly TFTP server on the public Internet for users to download the latest firmware upgrade automatically. Please check the Service or Support section of Grandstream’s Web site to obtain this TFTP server IP address. - 37 -...

  • Page 38: Connection Diagram

    BudgeTone-100 User Manual Grandstream Networks, Inc. Connection Diagram Network connection diagrams for Grandstream series products. Internet SIP SVR / IP PBX BT 101 HT 286 Switch/Hub xDSL Modem Cable Modem Computer Switch/Hub Home Router HT 286 BT 100 HT 486...

  • Page 39: Restore Factory Default Setting

    BudgeTone-100 User Manual Grandstream Networks, Inc. Restore Factory Default Setting Warning : Restore the Factory Default Setting will delete all configuration information of the device. Step one: Find the Mac Address of the device. The Mac address of the device is located on the bottom of the device.
