- Page 1 Grandstream Networks, Inc. BT–Series BT–200 Dual Ethernet Port SIP Phone BT–200 User Manual www.grandstream.com support@grandstream.com Firmware Version 1.1.1.14...
-
Page 2: Table Of Contents
FIRMWARE UPGRADE ... 29 HTTP... 29 PGRADE THROUGH TFTP ... 30 PGRADE THROUGH RESTORE FACTORY DEFAULT SETTING... 31 GLOSSARY OF TERMS ... 32 Grandstream Networks, Inc. TABLE OF CONTENTS BT–200 USER MANUAL IP N ... 5 ETWORK ... 11 ... 12 EADSET ... - Page 3 SIP A CREENSHOT OF CCOUNT 7. S CREENSHOT OF AVED ONFIGURATION 8. S CREENSHOT OF EBOOT Grandstream Networks, Inc. TABLE OF FIGURES BT–200 USER MANUAL ... 9 ... 11 ... 21 CREENSHOT ... 28 CREENSHOT TABLE OF TABLES BT–200 USER MANUAL ...
-
Page 4: Bt-200 User Manual
@: • Reproduction or transmittal of the entire or any part, in any form or by any means, electronic or print, for any purpose without the express written permission of Grandstream Networks, Inc. is not permitted. Grandstream Networks, Inc. -
Page 5: Connecting Your Phone
6. Login as administrator (password on default: admin) a. Type your SIP ID numbers b. Type your NAME used for Member Login c. Type your PASSWORD used for Member Login 7. REBOOT the BT–200 phone Grandstream Networks, Inc. Power IP N ETWORK BT-200 User Manual Firmware 1.1.1.14... -
Page 6: Safety Compliances
Grandstream reserves the right to remedy warranty policy without prior notification. Warning: Please do not use a different power adaptor with the BT-200 as it may cause damage to the products and void the manufacturer warranty. Grandstream Networks, Inc. BT-200 User Manual Firmware 1.1.1.14 Page 6 of 35... -
Page 7: Product Overview
Standard voice features and functionality • Advanced functionality • Voicemail indicator with light Lines Ethernet Ports 1 Line / 1 SIP 2 RJ45 (LAN) account (switched/routed) Grandstream Networks, Inc. Voice Mail DHCP Security Indicator SRTP, Client/ Server (pending) BT-200 User Manual Firmware 1.1.1.14 party SIP providers. -
Page 8: Table 2: Technical Software Features
Features Server redundancy – support for fail-over SIP server and DNS server Security DIGEST authentication and encryption using MD5 and MD5-sess SRTP and TLS (pending) Grandstream Networks, Inc. EATURES BT-200 User Manual Firmware 1.1.1.14 Page 8 of 35 Last Updated: 12/2006... -
Page 9: Hardware Features
The LCD turns on with an incoming call. If voicemail is configured, there is also a RED LED message indicator. 2: BT–200 LCD I IGURE LLUSTRATION Grandstream Networks, Inc. PECIFICATIONS HONE BT-200 User Manual Firmware 1.1.1.14... -
Page 10: Table 4: Lcd Icon Definitions
01-10 for CALLED history (dialed number) 01-10 for CALLERS history (Incoming caller ID) Numbers and Characters: 0 – 9, “* key” = └, “# key“= ┘ Grandstream Networks, Inc. BT-200 User Manual Firmware 1.1.1.14 Page 10 of 35 Last Updated: 12/2006... -
Page 11: Getting Familiar With Keypad
SEND key can make call using that displayed number Enter to retrieve (video) voice mails or other messages HOLD Place ACTIVE call on hold TRNF TRANSFER key: Transfer an ACTIVE call to another number Grandstream Networks, Inc. Message Navigation Button & LED Keys Menu and... -
Page 12: Making And Answering Phone Calls
LAN/VPN using private or public IP addresses, or • both phone/VoIP device can be connected through a router using public or private IP addresses (with necessary port forwarding or DMZ) Grandstream Networks, Inc. HONE ALLS EADSET... -
Page 13: Placing A Direct Ip-Ip Call
If call waiting feature is enabled, a call waiting tone (stutter tone) will alert the caller to an incoming call. Press the FLASH button to place the current party on hold and switch to the incoming call. Press the flash button to toggle between two active calls. Grandstream Networks, Inc. BT-200 User Manual Firmware 1.1.1.14... -
Page 14: Blind And Attended Call Transfer
The blinking red MWI (Message Waiting Indicator) indicates a message is waiting. Press the MSG button to retrieve the message. An IVR will prompt the user through the message retrieval menu. Mute/Delete 1. To enable/disable mute during a call, press MUTE/DEL button. Grandstream Networks, Inc. BT-200 User Manual Firmware 1.1.1.14 Page 14 of 35... -
Page 15: Call Features
Wait for a dial tone. Hang up. LCD will display “Call FWD Activated”. Cancel Delayed Call Forward Dial “*93” for a dial tone, then hang up. Grandstream Networks, Inc. dial “*73” and get the dial BT-200 User Manual Firmware 1.1.1.14... -
Page 16: Configuration Guide
Enter new Router/Gateway address if DHCP is OFF Press ‘↓’ or ’↑’ to exit Press MENU to (save and) exit Must recycle power for changes to take effect. Grandstream Networks, Inc. BT-200 User Manual Firmware 1.1.1.14 Page 16 of 35... - Page 17 8 “ 1. 0. 0. 0” – version: ring tone 9 “3r 0000-00-00” – date: 3rd ring tone 10 “ 1. 0. 0. 0” – version: (all zeroes means unavailable or unsupported) Press MENU to exit. Grandstream Networks, Inc. ” ” ring tone BT-200 User Manual Firmware 1.1.1.14...
-
Page 18: Configuration With Web Browser
25 characters. The factory default password for the End User is “123”. After login, the embedded Web server will display the Configuration page, explained in detail in Table 8. Grandstream Networks, Inc. BT-200 User Manual Firmware 1.1.1.14... -
Page 19: Table 8: Keypad Button Definitions
This means the daylight saving time starts from the first Sunday of April at 2AM and ends the last Sunday of October at 2AM. The saving is 60 minutes (1hour). Grandstream Networks, Inc. BT-200 User Manual Firmware 1.1.1.14 Page 19 of 35... - Page 20 PC and BT200 through the “PC” port to do the configuration. On the other hand, it exposes the BT200 to others, and may cause some security issues for users. Default is No. Reply to ICMP on If set to “Yes”, The BT200 will respond to the PING command from other computers...
-
Page 21: Advanced User Configuration
Web server will display the Advanced Configuration page, explained in detail in Table 10: Advanced Configuration Page Definitions. 4: A IGURE DVANCED ONFIGURATION Grandstream Device Configuration Password All Rights Reserved Grandstream Networks, Inc. 2005-2006 Grandstream Networks, Inc. CREENSHOT Login BT-200 User Manual Firmware 1.1.1.14 End User After login, the... -
Page 22: Table 10: Advanced Configuration
It is the base RTP port for channel 0. When configured, channel 0 will use this port _value for RTP and the port_value+1 for its RTCP; channel 1 will use port_value+2 for RTP and port_value+3 for its RTCP. The default value is 5004. Grandstream Networks, Inc. EFINITIONS BT-200 User Manual Firmware 1.1.1.14... - Page 23 “Always skip firmware check.” Authenticate If set to Yes, cfg file will be authenticated before acceptance. Useful to protect Conf File against unauthorized changes to the device configuration. Grandstream Networks, Inc. BT-200 User Manual Firmware 1.1.1.14 Page 23 of 35 Last Updated: 12/2006...
- Page 24 DHCP Option 42 specifies a list of IP addresses for Network Time Protocol (NTP) Allow DHCP Option 42 to servers available to the client. If you choose yes, BT200 will use the NTP servers override NTP resolved from DHCP, instead of the one you specified in the "NTP Server" option server above.
-
Page 25: Table 11: Individual Settings Definitions
SIP service subscriber’s name which will be used for Caller ID display. Use DNS SRV: Default is No. If set to Yes the client will use DNS SRV to look up server. Grandstream Networks, Inc. BT-200 User Manual Firmware 1.1.1.14... - Page 26 User ID is Phone If the BT–200 has an assigned PSTN telephone number, this field should be Number set to “Yes”. Otherwise, set it to “No”. If “Yes” is set, a “user=phone” parameter will be attached to the “From” header in SIP request SIP Registration This parameter controls whether the BT–200 needs to send REGISTER...
- Page 27 Caller ID from displaying. Auto Answer When set to “Yes”, BT–200 will automatically switch to speaker when there is an incoming call. Grandstream Networks, Inc. BT-200 User Manual Firmware 1.1.1.14 Page 27 of 35 Last Updated: 12/2006...
-
Page 28: Saving The Configuration Changes
Enabled and forced: All calls using this account must use SRTP. If the other party doesn’t support SRTP, BT200 will decline the call. If we invite others, and receive a “200 Ok” message without crypto suite, we will send a “BYE”... -
Page 29: Provisioning Server
NOTE: If the “Auto Upgrade” field in the Advanced Configuration page is set to “No”, HTTP upgrade will be performed only once during boot-up. If it is set to “Yes”, the BT–200 will check the HTTP server in the interval defined in “Check for new firmware every” field. Grandstream Networks, Inc. EMOTE ROVISIONING... -
Page 30: Upgrade Through Tftp
The TFTP process may take up to 2 minutes over the Internet, or 20+ seconds if it is performed on a LAN. Grandstream recommends conducting firmware upgrades in a controlled LAN environment if possible. Grandstream Networks, Inc. Table 7: Configuration Menu to enter the configuration screen. BT-200 User Manual Firmware 1.1.1.14... -
Page 31: Restore Factory Default Setting
4. Enter the MAC address with alphabets and numbers. 5. Press the MENU button again The BT–200 will reboot automatically and restore to factory default setting. The reset is finished when the LCD stops flashing. Grandstream Networks, Inc. EFAULT ETTING BT-200 User Manual Firmware 1.1.1.14... -
Page 32: Glossary Of Terms
OSI network and OSI link layer. It is used when IPv4 is used over Ethernet ATA Analogue Telephone Adapter. Covert analogue telephone to be used in data network for VoIP, like Grandstream HT series products. CODEC Abbreviation for Coder-Decoder. - Page 33 FXS Foreign eXchange Office. An FXS device can be an analog phone, answering machine, fax, or anything that handles a call from the telephone company like AT&T. They should also operate the same way when connected to an FXS interface.
- Page 34 PPPoE Point-to-Point Protocol over Ethernet is a network protocol for encapsulating PPP frames in Ethernet frames. It is used mainly with cable modem and DSL services. PSTN Public Switched Telephone Network. The phone service we use for every ordinary phone call, or called POT (Plain Old Telephone), or circuit switched network.
- Page 35 VoIP Voice over the Internet. VoIP encompasses many protocols. All the protocols do some form of signaling of call capabilities and transport of voice data from one point to another. e.g.: SIP, H.323, etc. Grandstream Networks, Inc. BT-200 User Manual...
