  • Page 1 User Manual BudgeTone-100 Series IP Phone Version 1.00 Grandstream Network, Inc. www.grandstream.com...

  • Page 2: Table Of Contents

    BudgeTone-100 User Manual Grandstream Networks, Inc. Table of Contents 1 WELCOME ........................3 2 INSTALLATION .......................4 2.1 W ..............5 HAT IS NCLUDED IN THE ACKAGE 2.2 S ....................5 AFETY OMPLIANCES 3 PRODUCT OVERVIEW...................6 3.1 K ......................6 EATURES 3.2 H ..................7 ARDWARE PECIFICATION 4 BASIC OPERATIONS ....................8...

  • Page 3: Welcome

    Congratulations on becoming an owner of BudgeTone-100 IP telephone! You made an excellent choice and we hope you will enjoy all its capabilities. Grandstream's award-wining BudgeTone-100 series of SIP phones are innovative IP telephones that offer a rich set of functionality and superb sound quality at ultra- affordable price.

  • Page 4: Installation

    BudgeTone-100 User Manual Grandstream Networks, Inc. 2 Installation BudgeTone-100 series IP phones are designed to look and feel like standard telephones. The following photo illustrates the appearance of a BudgeTone IP phone and the use of its key buttons. Menu Volume &...

  • Page 5: What Is Included In The Package

    BudgeTone-100 User Manual Grandstream Networks, Inc. 2.1 What is Included in the Package The BudgeTone-100 phone package contains: 1) One BudgeTone-100 phone 2) One universal power adaptor 3) One Ethernet cable 4) Quick Guide (a simplified version of this User Manual) 2.2 Safety Compliances...

  • Page 6: Product Overview

    Grandstream Networks, Inc. 3 Product Overview Grandstream IP Phone is a next generation IP network telephone based on industry open standard SIP (Session Initiation Protocol). Built on innovative technology, Grandstream IP Phone features market leading superb sound quality and rich functionalities at mass- affordable price.

  • Page 7: Hardware Specification

    BudgeTone-100 User Manual Grandstream Networks, Inc. 3.2 Hardware Specification There are three models in the BudgeTone-100 family, namely: BudgeTone-101 BudgeTone-102 BudgeTone-102D The table below describes the difference among these models. Model BudgeTone-101 BudgeTone-102 BudgeTone-102D LAN interface 1xRJ45 10Base-T 2xRJ45 10Base-T...

  • Page 8: Basic Operations

    BudgeTone-100 User Manual Grandstream Networks, Inc. 4 Basic Operations 4.1 Get Familiar with LCD BudgeTone-100 phone has a numeric LCD of 64mmx24mm size and a backlight. Here is the display when all segments illuminate: 上午 下午 The LCD is equipped with a backlight. When the phone is configured properly and in the normal idle state, the backlight is off.

  • Page 9: Get Familiar With Keypad

    BudgeTone-100 User Manual Grandstream Networks, Inc. Alarm Clock Status Icon: OFF when the alarm clock is not set ON when the alarm clock is set Lock Status Icon: OFF when the lock is set ON when the lock is not set...

  • Page 10: Make Phone Calls

    BudgeTone-100 User Manual Grandstream Networks, Inc. Key Button Key Button Definitions Digit, star and pound keys are usually used to make phone 0 - 9, *, # calls Next menu item when phone is in IDLE mode ↓ Or reduce handset/speakerphone volume Previous menu item when phone is in IDLE mode ↑...

  • Page 11: Make Calls Using Ip Address

    BudgeTone-100 User Manual Grandstream Networks, Inc. 1. Pick up handset or press SPEAKERPHONE button, and then enter the phone numbers 2. Press the SEND/REDIAL button directly to redial the number just called. Once pressed, the last dialed number will be displayed on the LCD as the corresponding DTMF tones are played out and an outgoing call is sent.
  • Page 12 BudgeTone-100 User Manual Grandstream Networks, Inc. and then followed by the 12-digit target IP address. Destination ports can also be specified using *4 (encoding for “:”) followed by the encoded port number. The follow is a table of the encoding scheme for the most commonly used characters: .

  • Page 13: Answer An Incoming Call

    BudgeTone-100 User Manual Grandstream Networks, Inc. The rule of thumb to remember these encoding is: “a” is the first letter on button “1” so its encoding is “11”. “b” is the 2 letter on button “1” and its encoding is “12”. “c” is the 3 letter on button “1”...

  • Page 14: Handset Mode And Speakerphone Mode

    BudgeTone-100 User Manual Grandstream Networks, Inc. 4.3.4 Handset Mode and Speakerphone Mode Handset mode and Speakerphone mode cannot be enabled at the same time. Pressing the hook-switch or Speakerphone button would toggle the phone between these two modes. 4.3.5 Call Hold While in conversation, pressing the “Hold”...
  • Page 15 BudgeTone-100 User Manual Grandstream Networks, Inc. Call Flow Diagram For Blind Call Transfer Transferee Transferor Recipient INVITE 100/180/200 RTP Media REFER NOTIFY INVITE 100/180/200 RTP Media...
  • Page 16 BudgeTone-100 User Manual Grandstream Networks, Inc. The SIP message flow based on BYE/Also: method looks something like this: Transferee Transferor Recipient INVITE 100/180/200 RTP Media REFER 501 Not Implemented BYE with “Also:” INVITE 100/180/200 RTP Media...

  • Page 17: Configuration Guide

    BudgeTone-100 User Manual Grandstream Networks, Inc. 5 Configuration Guide 5.1 Configuration with Keypad When the phone is on-hook, press the MENU button to enter MENU state. When the phone goes off-hook or a call comes in, the phone automatically exits the MENU state and prepare for the call.
  • Page 18 BudgeTone-100 User Manual Grandstream Networks, Inc. Menu Item Menu Functions Display “[5] dnS ” Press Menu to display the DNS address Enter new DNS address if DHCP is OFF Press ‘↓’ or ’↑’ to exit Press Menu to (save and) exit Must recycle power to take effective!!! Display “[6] tFtP...

  • Page 19: Configuration With Web Browser

    BudgeTone-100 User Manual Grandstream Networks, Inc. Menu Item Menu Functions Display “[9] codE reL” Press Menu to display the code releases Press ‘↓’ or ’↑’ to browse line 1 “b 2003-02-15” – date: boot code 2 “ 1. 0. 0. 2” – version: boot code 3 “P 2003-02-16”...

  • Page 20: Configuration Menu

    Grandstream Networks, Inc. Once this request is entered and sent from a Web browser, the IP phone will respond with the following login screen: Welcome to Grandstream IP Phone Password Login The password is case sensitive and the factory default password is lower case ‘admin’.
  • Page 21 ID, depending on whether a separate account ID is used for authentication. SIP Password This field contains the password used for SIP authentication. It is used together with the above SIP Login ID Grandstream IP Phone Configuration MAC Address: 00.0B.82.00.00.01 Software Version: Program--1.0.3.78 Bootloader--1.0.0.7 HTML--1.0.0.17 Admin Password:...
  • Page 22 BudgeTone-100 User Manual Grandstream Networks, Inc. Default Router: DNS Server 1: DNS Server 2: sipserver.com SIP Server: (e.g., sip.mycompany.com, or IP address) Outbound Proxy: (e.g., proxy.myprovider.com, or IP address, if any) 1000 SIP User ID: (the user part of an SIP address)
  • Page 23 BudgeTone-100 User Manual Grandstream Networks, Inc. 5060 local SIP port: (default 5060) 5004 local RTP port: (1024-65535, default 5004) Use random port: NAT Traversal: Yes, STUN server is: (URI or IP:port) TFTP Server: (for remote software upgrade and configuration) Voice Mail UserID:...
  • Page 24 BudgeTone-100 User Manual Grandstream Networks, Inc. This controls the silence suppression/VAD feature of G723 and Silence G729. If set to “Yes”, when a silence is detected, small quantity of Suppression VAD packets (instead of audio packets) will be sent during the period of no talking.
  • Page 25 BudgeTone-100 User Manual Grandstream Networks, Inc. Early Dial This parameter controls whether the phone will attempt to send an early INVITE each time a key is pressed when a user dials a number. If set to “Yes”, an INVITE is sent using the dial-number collected thus far;...
  • Page 26 BudgeTone-100 User Manual Grandstream Networks, Inc. NAT Traversal This parameter defines whether the phone NAT traversal mechanism will be activated or not. If activated (by choosing “Yes”) and a STUN server is also specified, then the phone will behave according to the STUN client specification.

  • Page 27: Saving The Configuration Changes

    Once a change is made, the user should press the “Update” button in the Configuration Menu. The IP phone will then display the following screen to confirm that the changes have been saved. Grandstream IP Phone Configuration Update Status Your configuration changes have been saved. They will take effect on next reboot.

  • Page 28: Configuration Through A Central Server

    At this point, the user can relogin to the phone after waiting for about 30 seconds. 5.3 Configuration through a Central Server Grandstream IP phones can be automatically configured via a central provisioning system called Grandstream Automated Provisioning System (GAPS).
  • Page 29 BudgeTone-100 User Manual Grandstream Networks, Inc. For details on how GAPS works, please refer to the documentation of GAPS product.

  • Page 30: Software Upgrade

    BudgeTone-100 User Manual Grandstream Networks, Inc. 6 Software Upgrade 6.1 Upgrade with TFTP To upgrade software, BudgeTone-100 phone can be configured with a TFTP server where the new code image is located. The TFTP upgrade can work in either static IP or DHCP mode using private or public IP address.
  • Page 31 Grandstream Networks, Inc. controlled LAN environment if possible. For users who do not have local TFTP server, Grandstream provides a NAT-friendly TFTP server on the public Internet for users to download the latest firmware upgrade automatically. Please check the Service or...
