MOUNTING ON ELECTRICAL JUNCTION BOX*
Designed for both flush mount or surface mount applications, pre-drilled mounting holes
on EasyView dome accommodate various electrical junction boxes, making installation
easy and less time consuming.
When mounting the flush mount base, surface mount plate, or both together, use the
pre-drilled holes marked with the symbol for proper installation.
NO IR
NOTE : Screws required for electrical junction boxes are not supplied.These
screws are readily available at well-stocked electrical supply store.
8
4S
IR
Screws UNC 8-32 x 0.75
NPT 3/4" Pipe
4S
