ADJUSTING 3-AXIS GIMBAL*
The Gimbal mechanism yields maximum rotation and placement ad show below.
NO IR IR NO IR IR
Rotation 360 Panning 360
1 3
NO IR IR
Tilting 82
Tilting 90
4
2
