- Page 1 CONDOR B-12/BX-12/EM English version - MI-0057 EDITION - 10/2006 MÁQUINAS AGRÍCOLAS JACTO S.A. Rua Dr. Luiz Miranda, 1650 CODE - 668822 17580-000 - Pompéia - SP - Brasil Tel.: +55 14 3405-2100 Fax: +55 14 3452-1916 E-mail: export@jacto.com.br Operator’s Manual...
- Page 3 The agrochemicals application has become a largely used pratice by farmers in order to achieve higher and economical production. As it is a work that can bring risks to the human being, environment and crops as well, Jacto has always been concerned with the proper use of its spraying machineries in an efficient and safe way.
-
Page 4: Table Of Contents
TABLE OF CONTENTS SAFETY INSTRUCTIONS Handling agricultural sprayers ..................05 Handling chemicals ......................06 Safety decals ........................07 Safety measures......................09 SPRAYER PRESENTATION CONDOR M-12/75 ......................10 CONDOR S-12/75 ......................11 CONDOR EM/75 ......................12 CONDOR BX 12/75 ....................... 13 MAIN COMPONENTS OF SPRAYER Suction filter ........................ -
Page 5: Safety Instructions
- Keep away children, aged people and animals while operating, servicing this sprayer and even when the sprayer is stored. - In the delivery of your sprayer, have your Jacto dealer instruct you on the assembly, operation, maintenance and warranty in detail. -
Page 6: Handling Chemicals
SAFETY INSTRUCTIONS HANDLING CHEMICALS Chemical products are classified in four categories of toxicity. According to their toxicity level, there is a special recommendation of appropriate protective equipment. As your safety concerns first, we list below all the protective equipment recommended for handling chemical products of the category 1 which includes high toxicity level chemicals. -
Page 7: Safety Decals
SAFETY INSTRUCTIONS DECALS Safety decals are placed on the equipment to reduce the risk of damages or accidents to the operator or to the equipment during the use. Before operating the equipment, identify and understand the mean of all decals, through this page. - Page 8 SAFETY INSTRUCTIONS ATTENTION: Risk ATTENTION: Risk serious injuries. Do not serious injuries. Keep all maneuver the sprayer close protection devices in its to electricity supply cables. places. P/N: 378992 P/N: 379065 ATTENTION: Risk of serious injuries. Do not make any ATTENTION: Obligatory operation on the PTO shaft if use of protective mask.
-
Page 9: Safety Measures
SAFETY INSTRUCTIONS ATTENTION: THIS SAFETY ALERT SYMBOL IDENTIFIES IMPORTANT SAFETY MESSAGES. WHEN YOU SEE IT, BE ALERT TO ANY POSSIBILITY OF PERSONAL INJURY OR DEATH. SAFETY MEASURES - Keep all the protectors on their proper places. - Remove the controls installed on the tractor before disconnecting the sprayer. - Do not operate the pump without liquid. -
Page 10: Sprayer Presentation
SPRAYER PRESENTATION CONDOR boom M-12/75 frame winch control valve clean water tank tank level indicator lateral footboard suction filter PTO shaft pump CONDOR M-12 SPECIFICATIONS Length (m) ................1.35 Width (m) ................1.55 Height (m) ................3.35 Weight (kg) ................Tank - Capacity (liters).............. -
Page 11: Condor S-12/75
SPRAYER PRESENTATION CONDOR boom S-12/75 frame winch control valve clean water tank tank level indicator lateral footboard suction filter PTO shaft pump SPECIFICATIONS CONDOR S-12 Length (m) ................1.35 Width (m) ................. 1.55 Height (m) ................3.35 Weight (kg) ................Tank - Capacity (liters) .............. -
Page 12: Condor Em/75
SPRAYER PRESENTATION CONDOR EM/75 spray lance clean water tank control hose valve reel tank lateral footboard level indicator PTO shaft suction filter pump CONDOR EM SPECIFICATIONS Length (m) ................1.45 Width (m) ................. 1.27 Height (m) ................1.50 Weight (kg) ................Tank - Capacity (liters) .............. -
Page 13: Condor Bx 12/75
SPRAYER PRESENTATION CONDOR BX-12/75 frame booms clean water tank control valve tank level indicator lateral footboard suction filter PTO shaft pump SPECIFICATION CONDOR BX-12/75 Length (m) ................1.55 Width (m) ................. 2.50 Height (m) ................. 2.15 Weight (kg) ................Tank - Capacity (liters).............. -
Page 14: Main Components Of Sprayer
This valve must always remain open while the sprayer is running. If it remains closed, you will hear an unusual noise in the the pump. FVS-100 valve PUMP The pumps mounted to Jacto sprayers have capacity ranging from 38 to 300 liters per minute. CAPACITY MAXIMUM WORKING PRESSURE PUMP (L/min) kgf/cm²... -
Page 15: Pressure Regulator (V.a.r. And Masterflow)
MAIN COMPONENTS OF SPRAYER Your sprayer may be equipped with Jacto VAR or Masterflow control valve. Identify it in the drawings below and proceed as directed. V.A.R. CONTROL VALVE (CONDOR: M-12/75 / S-12/75 / EM/75 / S-EM/75 / 800 B-12/75 / BX- 12-75) This is a two-stage pressure regulator that provides greater sensibility in the calibrations. -
Page 16: Nozzles
MAIN COMPONENTS OF SPRAYER AGS SINGLE NOZZLE HOLDER CONDOR: M-12/75 / S-12/75 / 800 B-12/75 / BX-12/75 / BX-12/75 MF The AGS single nozzle holder AGS is mounted with a ceramic cone nozzle (M-12/75 / S-12/75 / 800 B-12/75) or stainless steel cone nozzle (BX-12/75 / BX-12/75 MF). It has a nondrip valve which shuts the flow off when the pressure drops to 10 psi, thus preventing it from dripping. -
Page 17: Mastermark Foam Marker
MAIN OF COMPONENTS OF SPRAYER FOAM MARKER (OPTIONAL) This accessory is specifically designed to mark off the application band width with foam so as to prevent overlaps and skips when spraying back. The ideal conditions for using the foam marker are the same for spraying, that is: - Cool weather;... -
Page 18: Line Filter
MAIN COMPONENTS OF SPRAYER LINE FILTER (OPTIONAL) JACTO also offers line filters for the spray circuit of boom sprayer. For each boom section there is a filter to be assembled on the pressure line. This filter has 80-mesh screen and optimize the filtration to the nozzles. -
Page 19: Tank Filling Device
MAIN COMPONENTS OF SPRAYER FILLING WITH FILLING DEVICE (MODEL EJ-250) Put 50 liters of water into the tank. Remove the plastic cap of the primary valve (2) and set the lever to the filling position. Connect the filling device hose (1) to the primary valve (2). Place the filling device (3) in the water source and the end of its hose in the tank filling opening. -
Page 20: Operational Procedures
OPERATIONAL PROCEDURES Sprayer type Stage Procedure Trailer 3 point Use individual protective clothing ........Do not work at high speeds ..........Spraying Do not spray against the wind ......... Do not travel with booms lifted or unlocked ..... Take care with electricity supply cables ......Do not eat, drink or smoke while spraying ....... -
Page 21: Choosing Tractor
CHOOSING THE IDEAL TRACTOR CHOOSING THE TRACTOR CONSIDERING THE HYDRAULIC SYSTEM LIFT CAPACITY The tractor should have lift capacity above the sum of the sprayer net weight (sprayer with empty tank) plus the weight equivalent to the tank capacity. CONDOR M-12/75 / S-12/75 / BX/75 & EM/75 (600 liters) Sprayer net weight ...... -
Page 22: Setting Up Tractor
SETTING UP TRACTOR ADJUSTING PARTS TO HITCH TO THE TRACTOR'S THREE-POINT SUSPENSION ATTENTION: The instruction below is an example of what should be done for properly hitching the sprayer to the tractor's three-point suspension. To exemplify we have used the Ford 4600 tractor; so proceed as directed in the operator's manual of your tractor. - Page 23 SETTING UP TRACTOR - ADJUSTING PARTS TO HITCH TO THE TRACTOR'S THREE-POINT SUSPENSION THIRD POINT FRAME The third point frame has two positions (1 and 2) to install the third arm and two positions to install the frame lower pin. Thus there are four different positions for this assembly.
-
Page 24: Connecting The Pto
CONNECTING THE SPRAYER - Remove or set aside the tractor drawbar. drawbar - Mount the sprayer to the tractor three- point suspension and level it as shown in the figure beside. - Adjust the tractor hydraulic lift lever so that the sprayer is not raised too high. -
Page 25: Assembling Booms
ASSEMBLING THE BOOMS ASSEMBLING THE BOOMS (CONDOR: M-12/75 / S-12/75 / 800 B-12/75) Assemble the booms on the sprayer (detail C). Install the stabilizing rope and level the booms through the chain to be fastened to the frame (detail A). Tighten the lifting rope on the frame (detail A). - Page 26 ASSEMBLING THE BOOMS INSTALLING THE ROPE - CONDOR: M-12/75 / S-12/75 / 800 B-12/75 Install the lifting rope of the sliding frame as shown in the figure. ASSEMBLING THE BOOMS (CONDOR BX-12/75 / BX 12/75 MF / PJ-600 BX-10 MF) Assemble the booms as shown in the detail.
-
Page 27: Operation And Adjustments
OPERATION AND ADJUSTMENTS SPRAY APPLICATION TECHNOLOGY A successful spray application does not depend only on a good sprayer or correct use of the chemicals but also on factors to be determined in the field under specialized orientation. Among these factors, some concepts should be part of a criterion of evaluation so that positive results may be attained within the pest control program. -
Page 28: Pressure Regulator
OPERATIONS AND ADJUSTMENTS V.A.R. CONTROL VALVE CONDOR: M-12/75 / S-12/75 / 800 B-12/75 / EM/75 / S-EM/75 / BX-12/75 This is a two-stage pressure regulator which provides great sensitiveness in the calibrations. The first stage is for calibration from 0.7 to 4.2 kg/cm² (10 to 60 psi), normally used for spraying herbicides. - Page 29 OPERATION AND ADJUSTMENTS PRESSURE REGULATOR MASTERLOW CONTROL VALVE (CONDOR BX-12/75 MF / PJ-600 BX-10 MF) This pressure regulator provides great sensitiviness and precision to the calibrations. It has two basic functional characteristics in relation to the conventional control valves. 1. FLOW RATE PROPORTIONAL TO TRAVEL The spray volume per area sprayed remains constant even if the tractor speed fluctuates in a same gear.
- Page 30 OPERATION AND ADJUSTMENTS MASTERFLOW CONTROL VALVE To calibrate each boom section, proceed as follows: 01.Run the sprayer and open the flow to all boom sections. 02.Set the relief lever (1) to the P (pressure) position. 03.Set the levers (2), (3), (4) and (5) to point downward. 04.Check the pressure indicated by the pressure gauge.
-
Page 31: Chemical Container Rinse
Metal, plastic and glass containers must be rinsed for decontamination. To facilitate this important operation , Jacto has installed on its trailed sprayers a suitable device that rinses internally the containers with pressurized water, eliminating most of the residues. -
Page 32: Container Rinse
OPERATION AND ADJUSTMENTS - Hold the chemical container over the rinse nozzle and pull the directional valve lever to wash inside the container. NOTE: With the chemical container over the rinse nozzle, make circular movements to reach all internal walls of the chemical container with the water jet for around 30 seconds. -
Page 33: Nozzles
OPERATION AND ADJUSTMENTS HOLLOW CONE NOZZLE HIGH QUALITY CERAMIC SERIES JA TECHNICAL CHARACTERISTICS SPRAY PATTERN ..........HOLLOW CONE SPRAY ANGLE ..........75 TO 80 DEGREES @ 150 PSI MATERIAL DE FABRICAÇÃO ......SINTERED ALUMINA FLOW RATE IDENTIFICATION ......NOZZLE COLOR AND DESCRIPTION Series JA hollow cone nozzles are produced by processes developed for exacting markets of mechanical engineering, space and aerospace industries. - Page 34 OPERATION AND ADJUSTMENTS TABLE 02 - SPRAYING VOLUME WITH NOZZLE SPACING AT 50 CM TRACTOR SPEED (km/h) FLOW NOZZLE PRESSURE RATE PER NOZZLE (psi) MODEL COLOR (L/min) SPRAYING VOLUME (L/ha) 0.32 0.38 JA-1 BLUE 0.50 0.55 0.43 0.52 JA-1.5 BROWN 0.66 0.77 0.64...
- Page 35 OPERATION AND ADJUSTMENTS KEMATAL NOZZLES - SERIES 110 UF EVEN FAN SPRAY (UNIVERSAL USE) TECHNICAL CHARACTERISTICS SPRAY PATTERN ..........EVEN FAN SPRAY ANGLE ..........110 DEGREES AT 15 PSI 115 DEGREES AT 30 PSI 120 DEGREES AT 45 PSI MATERIAL ............KEMATAL FLOW RATE IDENTIFICATION ......
- Page 36 OPERATION AND ADJUSTMENTS TABLE 1 - FLOW RATE Pressure (psi)* Nozzle Color Model Flow rate (l/min) 0.26 0.32 0.37 0.38 0.39 0.47 Orange 110-UF-01 - F110/04/3 0.36 0.61 0.38 0.42 0.51 0.55 0.59 Green 110-UF-015 - F110/06/3 0.46 0.47 0.56 0.68 0.73 0.77...
- Page 37 OPERATION AND ADJUSTMENTS STAINLESS STEEL CONE NOZZLES SERIES JD-10A & JD-12P The Series JD hollow cone nozzles, made in stainless steel, are recommended for low pressure applications as well as for use on manual knapsack sprayers due to little requirement as to the chemical mixture solution.
-
Page 38: Calibrating The Sprayer
OPERATION AND ADJUSTMENTS SPRAYER CALIBRATION The safety of people, animals and environment depends on correct spray appications. Therefore, we list below important operational procedures. WHEN HANDLING CHEMICALS WHEN OPERATING SPRAYER - Check for the proper working conditions of the - Follow strictly the instructions on the labels. sprayer. - Page 39 OPERATION AND ADJUSTMENTS SPRAYER CALIBRATION WITH THE CALIBRATOR BOTTLE BEFORE CALIBRATING THE SPRAYER CHECK THE FOLLOWING: - Suction filter: dirts - Hoses: twisted or bored; - Pressure regulator components (valve seat, valve and spring): wear or dirts; - Pump: proper lubrication (oil level and grease) and leakages; - Nozzles: same model, wear, flow rate, strainers.
- Page 40 OPERATION AND ADJUSTMENTS CALIBRATING THE SPRAYER THROUGH A PRACTICAL METHOD (Condor 600 EM-1/EM-2 e Condor 600 EM-1 P/EM-2 P) BEFORE CALIBRATING THE SPRAYER EQUIPPED WITH GUN OR LANCE CHECK THE FOLLOWING: - Suction filter: dirts; - Hoses: twisted or bored; - Pressure regulator components (valve seat, valve and spring): wear or dirts;...
- Page 41 OPERATION AND ADJUSTMENTS 10- Repeat this operation twice and take the average, adding time 1 and time 2 and dividing by two (e.g.: time 1 = 29s; time 2 = 31s; 29 + 31 = 60s; 60 ÷ 2 = 30s average, that is the time it takes to spray the distance previously obtained in "item 4", which is 50m).
-
Page 42: Diluting Chemicals
OPERATION AND ADJUSTMENTS DILUTING THE CHEMICALS ATTENTION NEVER run the sprayer for with less than 50 liters of water in the tank to avoid damage to the pump. Always use the following individual protective impermeable clothing when handling chemicals: goggles wide-brimmed - Impermeable wide-brimmeed hat mask... -
Page 43: Maintenance
MAINTENANCE GUIDELINES - Daily, after finishing the spray application, put clear water in the tank, remove the nozzles and run the sprayer till empty. - Clean and reinstall the nozzles and strainers. - Clean the main filter. - Wash the outside and inside of the sprayer. This procedure will avoid future problems caused by filter, nozzle and tube obstructions, and prolong the sprayer useful life. - Page 44 MAINTENANCE AGS SINGLE ANTIDRIP NOZZLE BODY CONDOR: M-12/75 / S-12/75 / 800 B-12/75 / BX-12/75 / BX-12/75 MF) Clean the nozzles and strainers daily or whenever necessary. CONE NOZZLE antidrip valve filtering element nozzle body cone nozzle lock nozzle strainer FLAT FAN NOZZLE filtering nozzle...
-
Page 45: Lubrication Table
MAINTENANCE LUBRICATION TABLE RECOMMENDED FREQUENCY SPECIFICATIONS PRODUCT LOCATION QTY. PRODUCTS PUMP JP-75 1.5 L 1ST CHANGE: AFTER 30 HOURS API-SB ALL INTERNAL COMBUSTION PUMP JP-100 2.0 L ENGINES WITHIN THIS LUBRICATING FURTHER SUPERIOR SPECIFICATION PUMP JP-150 2.5 L CHANGES: SAE-30 EVERY 100 PUMP JP-42 0.9 L... - Page 46 MAINTENANCE LIFT Lubricate every 100 hours. LIFT III CONDOR: M-12/75 / S-12/75 / 800 B-12/75 MECHANICAL AGITATOR HOSE REELS (CONDOR: S-12/75 / S-EM/75) (CONDOR: EM/75 / S-EM/75) Lubricate every 100 hours. Lubricate daily. BELT TIGHTENING AGITATOR (CONDOR: S-12/75 / S-EM/75) (CONDOR: S-12/75 / S-EM/75) Loosen the nut (1).
-
Page 47: Pto Shaft
MAINTENANCE CONVENTIONAL PTO SHAFT ATTENTION: ALWAYS STOP THE SPRAYER AND TURN OFF THE TRACTOR ENGINE BEFORE SERVICING THE PTO SHAFT. ALL KIND OF MAINTENANCE ON THE PTO SHAFT MUST BE DONE WITH THE USE OF APPROPRIATE PROTECTIVE CLOTHING, SUCH AS: GLOVES, BOOTS, GOGGLES, ETC. ATTENTION 01- CONNECTING ONLY OPERATE WITH PTO SHAFT... -
Page 48: Winter Storage
MAINTENANCE WINTER STORAGE In areas where temperatures drop to 0º or less, the water accumulated in the pump can freeze and cause serious damage. control valve tank pressure hose plastic cap (1) primary valve (2) main filter pump filling position filter valve working position ring... -
Page 49: Trouble-Shooting
PROBLEMS - CAUSES - CORRECTIONS Whenever Jacto sprayers equipped with piston pumps present problems, try to classifiy them in one of the following four groups. a) LACK OF SUCTION AND PUMPING CAPACITY No liquid flow through the nozzles. - Page 50 MAINTENANCE TROUBLE-SHOOTING a - LACK OF SUCTION AND PUMPING CAPACITY PROBABLE CAUSES CORRECTIONS The sprayer should be run with 540 rpm at PTO. Check visually 1- PTO not turning. whether the pump is being run. To run the hydraulic system, it is necessary to contain a minimum 2- Lack of water in tank.
- Page 51 MAINTENANCE TROUBLE-SHOOTING c - PRESSURE OSCILATION CORRECTIONS PROBABLE CAUSES 1- Loose belts. Check belt tension and tighten if necessary. Check for damaged hoses, filter packing rings, etc., and repair 2- Air in the intake system. if necessary. Check the regulator components and clean or replace if necessary. 3- Pressure regulator.
-
Page 52: General Care
GENERAL CARE SAFETY GUIDELINES WHEN USING THE EQUIPMENT AND CHEMICALS We warn the owners and users that the UNREASONABLE USE of this equipment and the chemicals applied may cause damage to people, properties, animals and environment. Read carefully and understand thoroughly this manual and the recommendations of the chemicals manufacturers. -
Page 53: Warranty Statement
- One (1) year from the purchase date by the original retail purchaser. WARRANTY APPLICATION: Jacto or its authorized representative shall honor this warranty, if any part or component shows confirmed defect in workmanship. IT SHALL BE UNDERSTOOD THAT THE REPLACEMENT OF ASSEMBLIES SUCH AS PUMPS,... - Page 54 PRODUCT REGISTRATION CARD INVOICE NUMBER: DATE: RETAILING DEALER: PHONE: CITY: STATE: SPRAYER: MODEL: SERIES: SPRAYER No.: PUMP No.: ORIGINAL RETAIL PURCHASER: ADDRESS: PHONE: CITY: STATE: PURCHASE DATE BY THE ORIGINAL RETAIL PURCHASER: THE WARRANTY IS IN FORCE AS OF THIS DATE: RETAIL PURCHASER SIGNATURE: Original retail purchaser's copy PRODUCT REGISTRATION CARD...
