Digital locking system 3060
Hide thumbs Also See for 3060:
Table of Contents

Advertisement

Page 6
1.4

Opening and locking from the outside

The external and internal knobs rotate freely when deactivated. The door cannot be
opened or locked. Hold the transponder approximately 10 to 40 cm from the digital
locking cylinder and briefly press the transponder button. If you are using an authorised
transponder the locking cylinder will emit a short double signal tone and subsequently
engage. Turn the internal or external knob in the direction of opening or locking. You
have approximately five seconds for this operation. (The engaging time can be
extended to 10 seconds using the software. This will not shorten battery life.) The
locking cylinder will emit a single signal tone and the internal or external knob will again
rotate freely. Make sure the internal or external knob rotates freely again after the
engaging process.
If you are using a transponder that is momentarily blocked due to a time zone
plan you will hear a single signal tone; however, the cylinder will not engage so
that the internal or external knob remains freely rotatable and the door firmly
locked.
1.5

Opening and locking from the inside

The door can only be opened or locked from the inside using the transponder. The
exception to this rule is the locking cylinder type .TS (keypad control) which can be
engaged mechanically from the inside. This model allows the door to be opened and
locked from the inside without the use of an authorised transponder. Doors with this
model are not entered into the access list.
2.

Versions

The digital locking cylinder 3061 is available in the following versions:
2.1

Standard version

The standard version is a locking cylinder that is freely rotatable on both sides with
Yes/No authorisation. The cylinder can differentiate between a maximum of 8,187
different transponder IDs (TIDs). The cylinder complies with IP Class 54 when fitted,
but its actuator must be protected against contact with water.
Manual – Digital locking cylinder 3061
