15.14 WaveNet router node as WLAN/RS485 converter

Order number
Description
Dimensions (L*W*H)
Frequency band
Power supply
Output
(for all routers)

15.15 WaveNet router node as WLAN/868 MHz converter

Order number
Description
Dimensions (L*W*H)
Frequency band
Power supply
Output
(for all routers)
WAVENET RADIO NETWORK 3065
WN.RN.WC
WaveNet router node as converter between WLAN interface
(TCP/IP) and RS 485 interface for using router node as
backbone, incl. connecting terminals for external plug-in power
supply
100 x 65 x 40 mm or
100 x 65 x 130 mm (with antenna)
868 MHz
9V ... 48V DC regulated plug-in power supply
Min. 3 VA (250 mA with continuous load*)
* - Peak current with termination of both ends in backbone
WN.RN.WR
WaveNet router node as converter between WLAN interface
(TCP/IP) and 868 MHz interface. Incl. connecting terminals for
external plug-in power supply and external transmission and
receiver antenna
100 x 65 x 40 mm or
100 x 65 x 130 mm (with 2x antenna)
868 MHz
9V ... 48 V DC regulated plug-in power supply
Min. 3 VA (250 mA with continuous load*)
* - Peak current with termination of both ends in backbone
