11. Data sheet

Knobs
Profile cylinder
Batteries
Ambient conditions
Manual – Digital Half Cylinder 3061
Material
Colours
Diameter
Length
Basic length
Type
Manufacturer
Quantity
Voltage
Lifetime
Operating
temperature
Storage
temperature
Protection
Class
Stainless steel
Satin stainless steel
30 mm
37 mm (from profile face)
External 30 mm, internal 10 mm
Design lengths in increments of 5 mm
(no kits) up to 100 mm overall length,
whereby the external side of the cylinder
can be up to a maximum of 90 mm in
length. Longer lengths are available on re-
quest.
CR 2450
Varta, (Panasonic, Sony)
2 pieces
3 Volt
approx. 150,000 operations
or approx. 6-7 years on stand-by
-20°C to +50°C
-30°C to +60°C
IP 54 (when installed)
Variant .WP: IP 65 (knob)
