7.1 Access control
Only possible for SREL.ZK and SREL.ADV
The last 1024 transponder activation's are saved with the date and time.
7.2 Time zone control
Only possible for SREL.ZK and SREL.ADV
You can load a time zone plan and the transponders are then approved or blocked,
according to their time zone group.
7.3 Overlay
Replacement transponders can overwrite the transponders that they replace. After
the first operation with a replacement transponder, the system blocks the original
transponder.
7.4 Flip Flop
Pulse mode (default setting) is switched off, and the pulse width does not matter any
more. When flip flop mode is switched on, the Smart Relay changes its state from ON
to OFF or back again, each time the transponder is activated. We recommend this
mode for switching lights or machines, etc.
With an installation of this kind, it may be necessary to make sure that the
power supplies and door openers are suitable for continuous current operation.
7.5 Repeater
The Smart Relay receives a transponder signal and then sends it again, amplified.
You can use the Smart Relay in this function in order to link a way through larger
radio paths. The distance to another Smart Relay can be up to 2.0 m (6.5 ft).
7.6 Time switching
Only for SREL.ZK and SREL.ADV
If time switching is activated, you must load a time zone plan, which allows a general
release of the Smart Relay during the marked times (in Group 5). This means that a
door can be freely accessible during the day but only opened by transponder at night.
With an installation of this kind, you must make sure that the power supplies
and door openers are suitable for continuous current operation.
If you select time switching, the "Time-controlled relay switching" field has the
following option's (you may select more than one):
Smart Relay: SREL, SREL.ZK, SREL.ADV
