1.0

Introduction

The PalmCD2 is a programming device that was developed especially for operation
on a PC/Laptop or in combination with a Palm m5xx or Palm Tungsten W, or T3
Organiser. It makes it very easy to program and read out all digital components of the
3060 system. You can also use the Palm to match up your personal data (addresses,
calendar, etc.)
2.0

Commissioning

Insert the two batteries into the battery compartment. Make sure that the polarity is
correct. Do not use storage batteries.
ATTENTION:
The battery fitted in the cylinder can, in the case of inappropriate treatment, represent
a fire or bums hazard! Do not recharge, open, heat to more than 100°C or incinerate!
Replace battery only with type AAA 1.5 V. Use of a different type battery can present
a fire and explosion risk!
Install the PalmLDB on the Palm m5xx or Palm Tungsten W, or T3 Organiser and
transmit the locking plan data from the PC to the Palm (see the PalmLDB operating
instructions). Insert your Palm Organiser onto the PalmCD2 at an angle and carefully
let it snap into place. Start the PalmLDB and test the PalmCD2 (Config-Device
Test).
The PalmCD2 is now ready for operation. To remove the Palm Organiser from the
PalmCD2 again, you must press the slide on the back of the PalmCD2 in the direction
of the arrow. Then carefully click out the Palm and slide it up.
The PalmCD2 does not have a low battery warning with firmware versions 9.1
or earlier. If it stops answering or if there are problems with the radio link,
check the batteries or replace them. Dispose of used batteries immediately,
keep them out of reach of children, do not open them and do not throw them
into a fire.
For firmware version 9.3 and later and PalmLDB 1.26, a battery warning has
been implemented. When a battery warning is issued, please change the
batteries as soon as possible.
Avoid direct exposure to the sun and keep the PalmCD2 away from sources of
magnetic interference.
3.0

Programming with the PC or Laptop

You can use the cable enclosed with the PalmCD2 to connect it directly to a free
COM interface on a PC or laptop. If no COM interface is available, you can optionally
acquire a special serial USB converter cable from SimonsVoss. (Only this cable has
PalmCD2 Programming Device
