3. TECHNICAL SPECIFICATIONS
Specification
Nominal thermal output
Total weight
Boiler water content
Max. operating pressure
Max. operating temperature
Boiler connections
Flue gas temperature (avg.)
Chimney draught
Diameter of flue outlet
Max. length of the wood piece
Wood storage volume
Boiler Dimensions in mm
DIMENSIONS
H1
Outer dimensions
L1
B1
H
Flow pipe connection
L2
H2
Return pipe connection
H3
Flue gas outlet
B
Chamber width
L
Chamber length
Inlet and outlet
Filling and draining
1245
1200
720
1300
660
80
960
540
685
Page 5
Bio-Tec 35
Unit
35
kW
515
Kg
96
Litre
2.5
Bar
90
ºC
1 ½ "
Inch
½ "
Inch
190
ºC
18
Pa
150
mm
550
mm
132
Litre
