Appendix B: Battery Calculations (Selection Guide)

Appendix B: Battery Calculations (Selection Guide)
Use the form below to determine the required batteries.
The main AC branch circuit connection for the Fire Alarm Control Unit must provide a dedicated
continuous power without provision of any disconnect devices. Use #12 AWG wire with 600-volt
insulation and proper over-current circuit protection that complies with the local codes.
Model Number Description
Fire Alarm, 2 Det, 1
FA-102T
Sig
Remote Trouble
RTI-1
Indicator
2-Wire Smoke Detectors
4-Wire Smoke Detectors
Signal Load (bells, horns, strobes, and
etc.)
Total currents (Add above currents)
Total Current Requirement
ALARM (B)______ Amps.
Battery Capacity Requirement
(
[STANDBY (A) ______ ] X [(24 or 60 Hours) ________ ]
Battery Selection
Multiply (C) by 1.20 to derate battery.
Note: Batteries BA-104 (4.0AH) and BA-1065(6.5AH) fit into the backboxes; all larger
batteries such as BA-110(10AH) and the BA-117(17AH) require an external battery
box.
*
Assuming three Initiating Circuits in alarm.
♣
Use 0.084 for five minutes of alarm or 0.5 for thirty minutes of alarm as a multiplier figure.
♦
Using the MIR-525/U 2-wire smoke detector. See Appendix "A", for other available smoke detectors .
Applicable Standards: ULC S-524, ULC-527-99, wiring is in accordance with Canadian Electrical Code, C22.1, Part 1,
Section 32
