- Page 1 END USER INSTRUCTIONS Receiver: R21-RS02 safe smart strong R 2 1 ED-PM-RX103-EN-v03 Language: English (original)
- Page 2 IMPORTANT! This product is built on base model R21-02. ©Tele Radio AB Datavägen 21 SE-436 32 Askim Sweden Phone: +46 (0)31 748 54 60, Email: info@tele-radio.com...
-
Page 3: Table Of Contents
End user instructions│ R21│ CHAPTER 1: INTRODUCTION 1.1 About this document 1.2 About this system CHAPTER 2: SAFETY 2.1 Warnings & restrictions CHAPTER 3: TECHNICAL DATA 3.1 System specifications 3.2 Receiver specifications CHAPTER 4: PRODUCT GENERAL DESCRIPTION 4.1 Receiver description 4.2 Mounting dimensions CHAPTER 5: STATUS AND ERROR INDICATIONS 5.1 Receiver's status and error codes 5.2 CANopen (DLEDs ) run status 5.3 CANopen (DLEDs) error status... -
Page 4: Chapter 1: Introduction
READ ALL INSTRUCTIONS AND WARNINGS CAREFULLY BEFORE OPERATING THE PRODUCTS. These End user instructions have been published by Tele Radio AB and are not subject to any guarantees. The End user instructions may be withdrawn or revised by Tele Radio AB at any time and without further notice. Corrections and updates will be added to the latest version of the manual. - Page 5 End user instructions│ R21│ Chapter 1: Introduction Tele Radio AB products are covered by a warranty against material, construction, or manufacturing faults. See "Chapter 8: Warranty, service, repairs, and maintenance". ED-PM-RX103-EN-v03...
-
Page 6: About This Document
Before installing or operating the product, read the corresponding documentation carefully. Tele Radio AB's product range is composed of transmitters, receivers, and accessories intended for use together as a system. R21 systems are mainly intended for the hydraulic and mobile equipment markets. -
Page 7: About This System
1 . 2 A b o u t t h i s s y s t e m Tele Radio AB's remote control systems are suitable for a wide variety of applications for e.g. stationary or mobile equipments, hydraulic machines, construction, forestry or agriculture equipments and more. -
Page 8: Chapter 2: Safety
The following information is intended for use as a complement to applicable local regulations and standards. IMPORTANT! Tele Radio AB remote controls are often built into wider applications. These systems should be equipped with: •... - Page 9 End user instructions│ R21│ Chapter 2: Safety Always follow operating and maintenance instructions as well as all applicable safety procedures and requirements. Do not open the receiver encapsulation unless you are qualified. You must satisfy the age requirements in your country for operating the equipment.
- Page 10 End user instructions│ R21│ Chapter 2: Safety Wipe off dust using a clean, slightly damp cloth. Never use cleaning solutions. Check the encapsulation, foils and cable for damages every day. If you use the product although the encapsulation or foil is damaged, moisture can cause serious damage to the electronics.
-
Page 11: Chapter 3: Technical Data
End user instructions│ R21│ Chapter 3: Technical data CHAPTER 3: TECHNICAL DATA NOTE: The information below may differ in customized systems, please refer to the corresponding technical documentation provided with each system. 3 . 1 S y s t e m s p e c i f i c a t i o n s Radio frequency band 2405 –... - Page 12 End user instructions│ R21│ Chapter 3: Technical data optional: RS485 (Modbus RTU) Secondary CAN (J1939 or CANopen). NOTE: The two CAN ports can be used for both CANopen and J1939 but only one CAN port at a time can be used for CANopen, whereas J1939 can be run in parallel on both ports.
-
Page 13: Chapter 4: Product General Description
End user instructions│ R21│ Chapter 4: Product general description CHAPTER 4: PRODUCT GENERAL DESCRIPTION NOTE: The pictures shown in this chapter are for illustrative purposes only. Depending on the configuration, the actual product appearance may differ from the basic model used for reference. 4 . -
Page 14: Mounting Dimensions
End user instructions│ R21│ Chapter 4: Product general description 4 . 2 M o u n t i n g d i m e n s i o n s NOTE: For mounting on a wall or equipment, use 4 M5x30 mm screws or equivalent fastening method. -
Page 15: Chapter 5: Status And Error Indications
End user instructions│ R21│ Chapter 5: Status and error indications CHAPTER 5: STATUS AND ERROR INDICATIONS LEDs 1–5 indicate errors and status for the receiver, DLEDs 1–2 indicate errors and status for CANopen. 5 . 1 R e c e i v e r ' s s t a t u s a n d e r r o r c o d e s LED Color Flashing Indicates ●... -
Page 16: Canopen (Dleds) Error Status
End user instructions│ R21│ Chapter 5: Status and error indications CANopen Description communication state Operational State for process data transmission. LSS services in progress. Stopped Except for node guarding or heartbeat messages, a node cannot transmit or receive any other messages in this state. -
Page 17: Chapter 6: Operation
End user instructions│ R21│ Chapter 6: Operation CHAPTER 6: OPERATION 6 . 1 G e n e r a l i n f o r m a t i o n To control a receiver, the transmitter must be registered and logged in to the receiver. - Page 18 End user instructions│ R21│ Chapter 6: Operation On the Receiver On the Transmitter 4. Make sure that the Stop button is pressed. 5. Turn the key switch to the 'On' position (horizontal). 6. Twist and release the Stop button. The initial start-up logo is displayed.Battery indicator(s) light 1.
-
Page 19: Log All Transmitters Out With The Receiver
End user instructions│ R21│ Chapter 6: Operation The transmitter is now registered. On the Receiver On the Transmitter LED 1 is flashing (slow). The transmitter turns off. If not successfully completed: On the Receiver On the Transmitter The receiver exits registration mode. The display shows: [Registration LED 1 is flashing (red). -
Page 20: Chapter 7: Battery
End user instructions│ R21│ Chapter 7: Battery CHAPTER 7: BATTERY 7 . 1 B a t t e r y p r e c a u t i o n s Carefully read the following safety instructions and warnings before using or disposing of the batteries. -
Page 21: Battery Information
End user instructions│ R21│ Chapter 7: Battery 7 . 1 . 2 D I S P O S A L When discarding batteries, insulate the + and - terminals of batteries with insulating/ masking tape. Do not place multiple batteries in the same plastic bag. Do not incinerate or dispose of batteries in fire. -
Page 22: Chapter 8: Warranty, Service, Repairs, And Maintenance
Tele Radio AB products are covered by a warranty against material, construction and manufacturing faults. During the warranty period, Tele Radio AB may replace the product or faulty parts. Work under warranty must be performed by Tele Radio AB or by an authorized service center specified by Tele Radio AB. -
Page 23: Chapter 9: Regulatory Information
For proper treatment, recovery and recycling, please take this product to a designated collection point. Tele Radio AB strives to minimize the use of hazardous materials, promotes reuse and recycling, and reduces emissions to air, soil and water. When a commercially viable alternative is available, Tele Radio AB strives to restrict or eliminate substances and materials that pose an environmental, health or safety risk. - Page 24 End user instructions│ R21│ Chapter 9: Regulatory information (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
- Page 25 End user instructions│ R21│ Chapter 9: Regulatory information 2) l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. This radio transmitter has been approved by Industry Canada to operate with the antenna types listed below with the maximum permissible gain and required antenna impedance for each antenna type indicated.
-
Page 26: Eac
9 . 3 E A C Applies to: R21-01, R21-02, R21-RS02 9 . 3 . 1 E A C S T A T E M E N T ( Д Е К Л А Р А Ц И Я Е А С ) This product is declared as compliant within Eurasian Economic Union (EAC). -
Page 27: Annex A: Index
End user instructions│ R21│ Annex A: Index ANNEX A: INDEX About R21 receivers Antenna Battery Battery precautions Handling Storage Bus system CE marking Compatibility Data format Disposal EAC Statement EIRP Error indications CANopen J1939 FCC statement FCC/IC labels Frequency management ED-PM-RX103-EN-v03... - Page 28 End user instructions│ R21│ Annex A: Index IC Statement IP code LED indicators Log out Logical digital inputs Logical digital outputs Logout Maintenance Mounting dimensions Receiver Number of channels Operating temperature Power supply Radio communication Radio frequency band Radio frequency output power Radio module Range Register...
- Page 29 End user instructions│ R21│ Annex A: Index Safe inputs/outputs Safety standards Specifications Receiver System Status and error code messages Status indications CANopen J1939 Receiver Storage temperature System address Warnings & restrictions Maintenance Operation WEEE directive ED-PM-RX103-EN-v03...
- Page 30 End user instructions│ R21│ This page intentionally left blank. ED-PM-RX103-EN-v03...
- Page 31 safe smart strong These End user instructions are subject to change without prior notice. Download the latest instructions from www.tele-radio.com .
