2. YOUR PANEL DETAILS

The Matrix control panel is supplied with the factory default configuration. However, the panel configuration is

flexible and can be changed to meet your requirements.

Ask your engineer to fill in the following tables, noting any changes he might have made to the default

settings.

Zone

Guarded area

NOTE: Zones 7-16 are only available on the Matrix 816.

RINS545-7

Programmed Zone Type

Arm Mode A Arm Mode B Arm Mode C Arm Mode D

Matrix 6/816 User Manual

Default

Zone Type

Entry/Exit

Access

Immediate

Page 5
