Si04-703A
2.1.5 Removal of the Sound Blanket
Procedure
Step
1
Remove the sound
blanket (back).
2
Remove the
sound
blanket
(outer).
Remove the sound
3
blanket (top-upper).
Removal Procedure
Warning
Be sure to wait 10 minutes or more after turning off all power supplies
before disassembling work.
Procedure
Outdoor Unit
Points
Since the piping ports on the
sound blanket (outer) are
torn easily, remove the
blanket carefully.
173
