WL Cube Flow Diagram
Cold, Hot & Ambient
IN (Water)
SOLENOID
VALVE
SOLENOID
VALVE
SOLENOID
VALVE
CONDENSER
SOLENOID
VALVE
FILTER
DRYER
COMPRESSOR
The Cube Technical Manual - Version 1, May 2014
HOT WATER OUT
AIR VENT
SOLENOID
VALVE
COLD WATER OUT
COLD
SENSOR
COLD
TANK
HOT
TANK
AMBIENT WATER OUT
8
Pre Delivery
Inspection Procedures (PDI)
CAUTION:
Only competent trained technicians should work on Waterlogic products.
Waterlogic units may weigh over 25KG. We recommend caution when lifting.
Packing materials could present a trip hazard. Keep them off the floor.
Take care not to allow the power lead to get wet. If the lead gets wet it must not
be used.
