Read and follow all safety information carefully. The signal words used in this manual are selected as
shown below and based on an assessment of the degree of potential injury or damage (severe or
minor) and the occurrence of injury (definitely occurs or has the potential to occur) when the
warning is ignored:
DANGER!
Indicates a situation which, when not avoided, results in death or severe injury.
WARNING!
Indicates a situation which, when not avoided, has the potential to result in death or severe
injury; and/or severe property damage.
CAUTION!
Indicates a situation which, when not avoided, results or has the potential to result in minor
injury; and/or minor property damage.
Basic safety precautions should be followed, including the following:
Ensure all local, state, and federal laws and codes including health and safety guidelines are met
when installing Waterlogic Equipment. Only qualified service technicians should attempt
installation and service of Waterlogic Equipment. Always read the entire operating instructions
before using the appliance and save these instructions for future use.
DANGER!
ELECTRICAL SHOCK HAZARD. Always use a dedicated and properly grounded outlet.
Unit should be protected by ground-fault circuit interrupter (GFCI) or residual current device (RCD)
having a rated residual operating current not exceeding 30mA. Use only Waterlogic supplied
power cord. Never use extension cords or power strips to connect unit. Do not use if the power
supply cord is damaged. Always unplug from power supply prior to servicing.
WARNING!
AUTHORIZED USE ONLY. This appliance is to be used for its intended purpose as
described in this manual and untrained individuals who use this manual assume the risk of any
resulting property damage or personal injury. This appliance can't be used by children and persons
with reduced physical, sensory or mental capabilities or lack of experience.
WARNING!
DO NOT OPERATE IF DAMAGED. Unplug if abnormal case occurs. Contact Waterlogic
or authorized dealer for repair, service, and installation to avoid hazards.
WARNING!
HOT WATER. Unit produces Hot Water in excess of 87°C (188°F). Water above 52°C
(125°F) can cause severe burns or scalding. Keep unauthorized people and children away from the
unit to avoid accidental dispensing of hot water.
WL290 Manual
SAFETY ALERT SYMBOLS
SAFETY PRECAUTIONS
Page 4 Revision: 10-21-21
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for WaterLogic WL290
Summary of Contents for WaterLogic WL290
- Page 1 Unit should be protected by ground-fault circuit interrupter (GFCI) or residual current device (RCD) having a rated residual operating current not exceeding 30mA. Use only Waterlogic supplied power cord. Never use extension cords or power strips to connect unit. Do not use if the power supply cord is damaged.
- Page 2 TIP HAZARD. Dispenser could tip or fall causing serious injury. Always install unit on a firm, flat, and level surface and secure the WL290 Water Treatment System to the base cabinet with the screw provided to lock the components together. Secure unit to cabinet, wall, or floor if needed.
- Page 3 High Volume Storage and Water Capacity The WL290 Water Treatment System unit has 4 liters (1 Gallon) in Cold Tank and 11.2 Liters (3 Gallons) in the Cold-Water Reservoir (total of 15 Liters of Ice Cold Water) and 1.6 Liters (.42 Gallons) of Hot Water Capacity.
- Page 4 Standard for Drinking Water Coolers. CSA C22.2 No. 120 CSA Standard for Refrigeration. BPA Free - Waterlogic tests for BPA and declares that all of its products are Bisphenol- A FREE and contain no harmful BPA plastics. NSF/ANSI-61 – Certified Drinking Water System Components NSF / ANSI 372 –...
- Page 5 MODEL/PART DESIGNATIONS MODEL BRAND NAME DESCRIPTION PART NUMBER Waterlogic WL290 – Cold and Hot WL290 F-1010-FS-HC-UT-CS-WLU GF Max Serial Number Prefix - 19 SPECIFICATIONS ITEM Water Connection ¼” Quick Connect Cold Water Temperature – Factory Set Point 5°C (41°F) Cold Water Temperature (Programmable) 3°...
- Page 6 15.4” ELECTRICAL SPECIFICATIONS ELECTRICAL SUPPLY 120V/60Hz, 1PH 15 Amp Service COMPONENT POWER (approximate) AMP DRAW (approximate) Heater 4.2 Amps Compressor 1.75 Amps UV Lamp System 0.07 Amps Pump 0.004 Amps WL290 TOTAL 6.03 Amps WL290 Manual Page 9 Revision: 10-21-21...
- Page 7 OPERATING INSTRUCTIONS The above picture shows the Front Water Dispense Buttons for the Waterlogic WL290 Water Treatment System. Place appropriate receptacle under the Hot or Cold areas for dispensing water. For Hot Water: 1. Press and hold down the Red-Hot Safety Button (LEFT hand side) 2.
- Page 8 Waterlogic will, at its sole discretion, determine whether to correct the defect or replace the unit, free of charge to you. If Waterlogic determines that the unit should be returned for warranty service, Waterlogic will approve of return in writing and will issue a Return Authorization which you must obtain prior to shipping the product.
