INSTALLING AND CONNECTING
Installing and connecting the convection box
Flue collar 90° straight upwards or 45° backwards
If the builders opening is too tight above when the flue collar adapter
plate is turned for installation 45° backwards, then remove and fasten
the flue collar adapter on the flue. Install the convection box and finally
fasten the flue adapter on the convection box, see "Flue collar 45°
backwards and tight builders opening" on side 92.
Straight upwards
45° backwards
1a
1b
180°
2
