1T-C2-511 A
1T-C2-520 O
M
ND
PERATION
ANUAL
1T-C2-511
&
1T-C2-520
Operation Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1T-C2-511 and is the answer not in the manual?

Questions and answers

Related Manuals for TV One 1T-C2-511

Summary of Contents for TV One 1T-C2-511

  • Page 1 1T-C2-511 A 1T-C2-520 O PERATION ANUAL 1T-C2-511 & 1T-C2-520 Operation Manual...
  • Page 2 1T-C2-511 A 1T-C2-520 O PERATION ANUAL...

  • Page 3: Table Of Contents

    Your unit does not power up................23 There is no picture on the output of your unit............. 23 There is no audio on the output of your 1T-C2-511..........23 The controls are not responding................ 23 The ERROR LED remains illuminated on the 1T-C2-520........24 The picture on the video display is green............
  • Page 4 11.1 DVI-I connector ....................28 11.2 RS232 / D9 socket..................... 28 12 SPECIFICATIONS ..................29 12.1 1T-C2-511 SD/HD-SDI to DVI-I Converter and Audio De-Embedder ....29 12.2 1T-C2-520 DVI-I to SD/HD-SDI Converter............29 12.3 Warranty......................30 12.4 Regulatory Compliance ..................30 12.5...

  • Page 5: Disclaimer

    1T-C2-511 A 1T-C2-520 O PERATION ANUAL 1 DISCLAIMER This product is intended for professional and/or home use. This product is not intended for use in a medical environment and does not have the required certifications for such use. Similarly, use aboard any aircraft or spacecraft while in...

  • Page 6: Manual Version Information

    Release Date: November, 2010 1.4 Manual Copyright Notice This Operation Manual is the intellectual property of TV One, ©2009, 2010. No portion of this manual may be copied or reproduced in any manner or by any means, including, but not limited to electronic and electro-mechanical, without the express...

  • Page 7: Important Safety Instruction

    1T-C2-511 A 1T-C2-520 O PERATION ANUAL 2 IMPORTANT SAFETY INSTRUCTION To insure the best from this product, please read this manual carefully. Keep it in a safe place for future reference. To reduce the risk of electric shock, do not remove the cover from the unit.
  • Page 8 1T-C2-511 A 1T-C2-520 O PERATION ANUAL 2.5 Ventilation Slots and openings in the sides of the unit are provided for ventilation. To ensure reliable operation, avoid obstruction of these openings and ensure the unit is installed in a well-ventilated area.
  • Page 9 1T-C2-511 A 1T-C2-520 O PERATION ANUAL IMPORTANT: CONSIGNES DE SECURITE Afin de tirer le meilleur de ce produit, merci de lire attentivement ce manuel. Gardez- le dans un endroit sûr pour pouvoir le consulter à nouveau. Afin de réduire le risque de choc électrique, ne retirez pas l’unité de sa protection.
  • Page 10 1T-C2-511 A 1T-C2-520 O PERATION ANUAL 2.5 Aération Les rainures et les ouvertures sur les cotés de l’unité servent à l’aérer. Pour permettre une utilisation sûre, évitez d’obstruer ces ouvertures et assurez-vous que l’unité est installée dans un endroit bien aéré.

  • Page 11: Instrucciones Importantes De Seguridad

    1T-C2-511 A 1T-C2-520 O PERATION ANUAL INSTRUCCIONES IMPORTANTES DE SEGURIDAD Para sacar el mejor provecho de este producto, léase este manual con detenimiento. Guárdelo en un lugar seguro para poder hacerle referencia en el futuro. Para reducir el riesgo de calambre, no quite la cubierta del aparato.
  • Page 12 1T-C2-511 A 1T-C2-520 O PERATION ANUAL 2.4 Ubicación Este aparato se debe instalar en un lugar seco y fresco, lejos de fuentes de calor excesivas, la vibración, el polvo, la humedad y el frío. 2.5 Ventilación El aparato viene provisto de ranuras y agujeros en los lados para la ventilación.
  • Page 13 1T-C2-511 A 1T-C2-520 O PERATION ANUAL WICHTIGE SICHERHEITSVORSCHRIFTEN Lesen Sie diese Bedienungsanleitung bitte sorgfältig, um Ihr Produkt optimal nützen zu können, und bewahren Sie sie zum späteren Nachschlagen an einem sicheren Ort auf. Entfernen Sie bitte keinesfalls die Abdeckung, um der Gefahr eines Stromschlags vorzubeugen.
  • Page 14 1T-C2-511 A 1T-C2-520 O PERATION ANUAL 2.3 Aufstellung Das Gerät sollte an einem kühlen, trockenen Ort aufgestellt werden, fern von übermäßiger Wärme, Vibrationen, Staub, Feuchtigkeit und Kälte. 2.5 Belüftung Seitliche Schlitze und Öffnungen sorgen für die Belüftung des Geräts. Um die ordnungsgemäße Belüftung zu gewährleisten, dürfen diese Öffnungen nicht verdeckt...
  • Page 15 1T-C2-511 A 1T-C2-520 O PERATION ANUAL BELANGRIJKE VEILIGHEIDSINSTRUCTIES Lees deze handleiding zorgvuldig door om het beste uit uw product te halen. Bewaar het op een veilige plek voor raadpleging in de toekomst. Haal nooit het omhulsel van de eenheid af, dit om de kans op een elektrische schok te verminderen.
  • Page 16 1T-C2-511 A 1T-C2-520 O PERATION ANUAL 2.4 Plaatsing Deze eenheid moet geïnstalleerd worden op een koele droge plaats, uit de buurt van bronnen van extreme hitte, vibraties, stof, vocht en kou. 2.5 Ventilatie De sleuven en openingen aan de zijkant van de eenheid zijn voor ventilatie. Zorg er voor dat de eenheid op een goed geventileerde plek geïnstalleerd wordt zodat deze...

  • Page 17: Device Summary

    525i to 1080p without scaling. The 1T-C2-511 is a SD/HD-SDI to DVI-I format converter and Audio De-Embedder capable of converting from standard and high definition serial digital video simultaneously to DVI digital and analog. Audio can be extracted from any stereo pair selected from any of 8 embedded within the SDI.

  • Page 18: Product Images

    1T-C2-511 A 1T-C2-520 O PERATION ANUAL 4 PRODUCT IMAGES Your unit should look like one of the images below. 1T-C2-511 1T-C2-520...

  • Page 19: C2-511

    PERATION ANUAL 5 1T-C2-511 The 1T-C2-511 is an HD/SD-SDI to DVI-I format converter with reclocked SDI loop thru and audio extraction. Video processing is achieved using proprietary video processing. Audio de-embedding may alter control and user data within the AES output, but will not normally change the video or audio signals.
  • Page 20 1T-C2-511 A 1T-C2-520 O PERATION ANUAL Analog 625-line progressive RGBHV @ 25Hz 625-line SD-SDI @ 25Hz Digital 625-line progressive DVI-D @ 25Hz 720-line progressive RGBHV @ same frame Analog 720p HD-SDI @ 23.98, 24 Hz, rate as input 25Hz, 29.97Hz, 30Hz, 50Hz, 720-line progressive DVI-D @ same frame 59.94Hz, 60Hz...

  • Page 21: C2-520

    1T-C2-511 A 1T-C2-520 O PERATION ANUAL 6 1T-C2-520 This is a DVI-I to HD/SD-SDI format converter without scaling. 6.1 Video inputs and outputs Visible in the images, the units have:  1 YPbPr input on 3 BNC connectors  1 DVI-I input ...
  • Page 22 1T-C2-511 A 1T-C2-520 O PERATION ANUAL Digital 1080-line interlaced DVI-D @ 25Hz, 29.97Hz, 30Hz 29.97Hz, 30Hz...

  • Page 23: Front Panel Controls

    1T-C2-511 A 1T-C2-520 O PERATION ANUAL 7 FRONT PANEL CONTROLS 7.1 Button controls The following buttons are available on the front of the unit include all or some of the following: Button Button Function Menu Activates the on screen display and allows for menu control ...

  • Page 24: The Menu Structure

    1T-C2-511 A 1T-C2-520 O PERATION ANUAL On the 1T-C2-520 repeatedly pressing the INPUT button cycles through the three possible inputs, DVI-D, DVI-A and YPbPr. If the selected input has no connection or the resolution is not one of those supported by the unit, then the error LED will illuminate and the output resolution will revert to 525i with the OSD permanently on.
  • Page 25 1T-C2-511 A 1T-C2-520 O PERATION ANUAL CORIO2 1T-C2-511 Output type [RGBHV] This menu item allows you to select the type of signal output your unit will provide. Types of output vary depending on the resolution selected and include various types of component signals YUV with tri level sync.
  • Page 26 1T-C2-511 A 1T-C2-520 O PERATION ANUAL CORIO2 1T-C2-5xx Firmware updates Indicates the total number of times the firmware has been changed over the life of the unit. It is quite possible for this to be more than 1, as a unit undergoes numerous tests during production.

  • Page 27: Troubleshooting And Technical Support

    Check that the device connected to the output is on and can support the resolution of the input device. 8.3 There is no audio on the output of your 1T-C2-511. If no LEDs are on, then ensure that the AC power adaptor is connected properly and the power switch is on at the AC outlet.

  • Page 28: The Error Led Remains Illuminated On The 1T-C2-520

    ‘drifting.’ In order to lock to the new resolution a power cycle or re- connecting the input may be necessary. 8.9 There is no output from the 1T-C2-511. Check that the input resolution is supported by the unit. The unit is designed to conform to SDI specifications, for a full list of available resolutions look at the 1T-C2- 511 Input-output conversion table.

  • Page 29: Return Procedure

    9.2 To return a unit for repair First contact TV One using the http://www.tvone.com/support website. Support personnel will determine whether a return to the factory is the appropriate solution. If that’s the case, a Return Authorization Number will be issued. You should provide...
  • Page 30 1T-C2-511 A 1T-C2-520 O PERATION ANUAL Please clearly state the return number on the outside packaging and on any accompanying documentation. This will greatly speed up processing. IMPORTANT: DO NOT return a unit for warranty repair without first obtaining a Return Authorization Number.

  • Page 31: Warranty Policy

    Should this product, in TV One’s opinion, prove defective within this warranty period, TV One, at its option, will repair or replace this product without charge. Any defective parts replaced become the property of TV One. This...

  • Page 32: Connector Pinouts

    1T-C2-511 A 1T-C2-520 O PERATION ANUAL 11 CONNECTOR PINOUTS 11.1 DVI-I connector PIN# SIGNAL PIN# SIGNAL T.M.D.S DATA 2- HOT PLUG DETECT T.M.D.S DATA 2+ T.M.D.S DATA 0- T.M.D.S DATA 2/4 SHIELD T.M.D.S DATA 0+ T.M.D.S DATA 4- T.M.D.S DATA 0/5 SHIELD T.M.D.S DATA 4+...

  • Page 33: Specifications

    1T-C2-511 A 1T-C2-520 O PERATION ANUAL 12 SPECIFICATIONS See product front and rear diagrams for details of product I/O. 12.1 1T-C2-511 SD/HD-SDI to DVI-I Converter and Audio De-Embedder Video input SD-SDI: SMPTE 259M-C 270Mbps HD-SDI: SMPTE 292M 1.485/1.4835Gbps Video output SD/HD-SDI: Equalized and re-clocked.

  • Page 34: Warranty

    1T-C2-511 A 1T-C2-520 O PERATION ANUAL Formats: Analog RGB supporting RGBHV, RGBS, RGsB Video output SD-SDI: SMPTE 259M-C 270Mbps HD-SDI: SMPTE 292M 1.485/1.4835Gbps Resolutions: 525-line @ 29.97 625-line @25Hz 720p @ 23.98Hz, 24Hz, 25Hz, 29.97Hz 30Hz, 50Hz, 59.94Hz, 60Hz 1080p @ 23.98Hz, 24Hz, 25Hz, 29.97Hz 30Hz 1035i @ 29.97Hz 30Hz...

  • Page 35: Mechanical

    1T-C2-511 A 1T-C2-520 O PERATION ANUAL 12.9 Mechanical Size (H x W x D): 1.2”x7.9”x3.5” (30x200x89mm) Weight (Net): 1.3 lbs (580g) 12.10 Optional Accessories RM-220: single/dual rack-mount Kit...

  • Page 36: Contact Information

    PERATION ANUAL CONTACT INFORMATION Should you have and questions or require assistance with this product in areas not covered by this manual, please contact TV One at the appropriate location shown below: TV One USA TV One Europe 2791 Circleport Drive...
