- Page 1 99 Washington Street Melrose, MA 02176 Phone 781-665-1400 Toll Free 1-800-517-8431 Visit us at www.TestEquipmentDepot.com Instruction Manual 1T-VS-647 SDI to HDMI Scaler w/Audio...
- Page 3 Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 TestEquipmentDepot.com...
-
Page 4: Table Of Contents
Table of Contents Introduction Specifications Checking Package Contents Connecting The Hardware Operating The Unit Troubleshooting Limited Warranty Regulatory Compliance Contact Information... -
Page 5: Introduction
Switchers, Signal Distribution Amplifiers and Cat.5 Transmission Systems. Liability Statement Every effort has been made to ensure that this product is free of errors. TV One cannot be held liable for the use of this hardware or any direct or indirect consequential damages arising from its use. -
Page 6: Specifications
SPECIFICATIONS Video/Audio Input SDI SD, HD, 3G-SDI Via 2x BNC (1x Input w/Loop-Thru) Video Output Via 1x HDMI Connector HDMI v1.3 Ancillary Audio Outputs De-Embedded Digital Audio Via 1x RCA, 48KHz De-Embedded Analog Audio Via 2x RCA, 48KHz Transmission Bitrates SDI Inputs 2.970Gbit/s &... -
Page 7: Checking Package Contents
1T-VS-647 and then between the 1T-VS-647 and the display. Plug in the provided AC adapter, first to the 1T-VS-647 and then to an active AC power source. Lastly, turn on the SDI source and display device. (The 1T-VS-647 has no power switch and will begin to function as soon as it has the AC adapter connected to it.) -
Page 8: Operating The Unit
OSD display. OPERATING THE UNIT The front panel of the 1T-VS-647 has four LEDs and four push buttons that are used to indicate status or to allow user interaction with the device. From left to right, the Power LED will illuminate anytime the device is receiving power from the included AC adapter. - Page 9 On Screen Display (OSD) Structure The 1T-VS-647 is controlled via an On Screen Display (OSD) menu structure. Much of the operation of the scaler is done automatically (Plug & Play), however there may be an occasion where an adjustment is desired. Numerous parameters can be controlled from the menu including adjustment of output resolutions, type of audio output, etc.
- Page 10 Note: Press the Enter and the – button together to immediately select 720p output timing and press Enter and the + button together to immediately select XGA output timing. These are the two most commonly used scaler parameters. Note 2: After making a resolution change you will have 15 seconds to confirm the newly selected resolution by pressing the “ENTER”...
-
Page 11: Troubleshooting
Input Timing, Output Timing & Version TROUBLESHOOTING Faulty cables are the most common problem associated with the 1T-VS-647. Make certain you are using the highest quality cables available. In the event of trouble with the unit, inspect the cables for damage and make sure they are completely seated in their connectors. -
Page 12: Limited Warranty
TV One assumes no liability to distributors, resellers or end-users or any third parties for any loss of use, revenue or profit.
