- Page 1 Instruction Manual 1T-VGA-DVI VGA to DVI Scaler...
-
Page 3: Table Of Contents
Table of Contents Introduction Specifications Checking Package Contents Connecting the Hardware Operating The Unit Troubleshooting Limited Warranty Regulatory Compliance Contact Information... -
Page 4: Introduction
Thanks for purchasing this VGA to DVI Scaler from TV One. The 1T-VGA-DVI is designed to convert analog signals to DVI. Our professional video conversion products have been serving the industry for over twenty years. TV One offers a full line of high quality Seamless Switchers, Video Scalers, Up/Down/Cross Converters, Analog-Digital... -
Page 5: Specifications
Clock Frequency, Phase Output Signal Brightness, Contrast, RGB Levels, Color, Horiz & Vert Position Mechanical 1T-VGA-DVI (H-W-D) 30x146x76mm (1.2"x5.75"x3") 1T-VGA-DVI Wt (Net) 310 g (0.68 lbs) Warranty Limited Warranty 2 Years Parts and Labor Environmental Operating Temperature 0° to +50° C (+32° to +122° F) - Page 6 2.1 Supported Input Formats and Resolutions The 1T-VGA-DVI accepts a wide variety of input resolutions and formats as detailed in the following table: Resolutions Vert Rate Format Scan Type 640x480 60,72,75,85 Hz RGBHV Progressive SVGA 800x600 60,72,75,85 Hz RGBHV Progressive...
-
Page 7: Checking Package Contents
Note: Please retain the original packing material should the need ever arise to return the unit. If you find any items are missing, contact your reseller or TV One immediately. Have the Model Number, Serial Number and Invoice available for reference when you call. -
Page 8: Operating The Unit
Connecting Power to the Unit The Video Scaler is shipped with an In-Plug Power Adapter to convert 100~240VAC @50-60Hz to 5VDC. Connect the DC Output Cord from the Power Adapter to the back of the unit and then plug the Power Adapter into an AC Receptacle. When the unit’s front panel Power Switch is turned on, the Power LED indicator will illuminate. - Page 9 5.1.3a When DVI-A is selected, you are given the following output choices: PC Resolutions Vert Rate Format Scan Type 640x480 60,72,75,85 Hz RGBHV Progressive VESA85 640X480 85 Hz RGBHV Progressive VGA70 720X400 70 Hz RGBHV Progressive SVGA 800x600 60,72,75,85 Hz RGBHV Progressive 1024x768...
- Page 10 5.1.4 Output Adjustments When in DVI-D Mode: Picture Adjust - When the Picture Adjust Menu is selected, the following adjust parameters will appear on the OSD: Contrast Bright Color Green Blue Reset Exit Use the +and – buttons to choose the desired parameter, press Menu to select and then use + or –...
-
Page 11: Troubleshooting
Should this product, in TV One’s opinion, prove defective within this warranty period, TV One, at its option, will repair or replace this product without charge. Any defective parts replaced become the property of TV One. This warranty does not apply... -
Page 12: 8.0 Regulatory Compliance
TV One assumes no liability to distributors, resellers or end-users or any third parties for any loss of use, revenue or profit. -
Page 13: Contact Information
CONTACT INFORMATION Should you have questions or require assistance with this product in areas not covered by this manual, please contact TV One at the appropriate location shown below: TV One USA TV One Europe 2791 Circleport Drive Continental Approach...
