Summary of Contents for TV One 1T-VGA-DVI
- Page 1 Instruction Manual Video Scaler VGA to DVI Scaler 1T-VGA-DVI...
-
Page 3: Table Of Contents
Table Of Contents Section Page INTRODUCTION ……………………………………………………………….…...4 Features………………...…………………………….…………………………...4 Getting the Best Results…………………………….…………………………...4 SPECIFICATIONS…………………………………….…………………………….5 CHECKING THE PACKAGE CONTENTS………..………………………………5 CONNECTING THE HARDWARE……………….………………………………..6 Connecting the Input……….…………………..………………………………...6 Connecting the Output……………………….…………………………………..6 Connecting Power to the Unit……………….…………………………………..6 CONTROLLING THE SCALER……………….……………….…….…………….7 OSD Menus…………………………………..…………………………………...7 5.1.1 Input Set Up.……………………………..…………………………………..7 5.1.2 Output Set Up………………………….….……………..………………..…8 5.1.3... -
Page 4: Introduction
Analog RGB input (VGA) to either DVI or DVI-I (Digital or Digital with overlaid Analog RGB) output. Our professional video conversion products have been serving the industry for over twelve years. In addition to Video Scalers, TV One offers a full line of high quality Scan Converters, Genlock Adatpers, Standards Converters, DV-to- Analog Converters, Digital Video Recorders, Time Base Correctors, LCD Monitors and Distribution Amplifiers. -
Page 5: Specifications
1080i signal format. CHECKING THE PACKAGE CONTENTS The following items are contained in shipping carton: • 1T-VGA-DVI Scaler • 100-240VAC AC/DC Power Adapter • YPbPr 3 RCA to VGA Adapter Cable •... -
Page 6: Connecting The Hardware
OSD menu. This is the standard configuration for the device. Note that the 1T-VGA-DVI has a DVI-A output mode that could be used to feed an analog monitor however this type of output would be only be used when a frequency and refresh rate conversion is required. -
Page 7: Controlling The Scaler
CONTROLLING THE 1T-VGA-DVI The Scaler is controlled via three buttons with status indicated by OSD. • Menu Button: This Button displays the Menu Options via the On Screen Display on the display device connected to the output. • + and - Buttons: These Buttons allow navigation within the Menu and adjustments of the parameters available. -
Page 8: Output Set Up
Pressing the + button narrows the width of the picture toward the left. Pressing the - button extends the width of the picture toward the right. Phase: Use the + and- buttons to adjust for least amount of noise in the picture. For the balance of the menu items, use the + and –... -
Page 9: Output Adjustments
When DVI-D is selected, you’re given the following output choices: PC Resolutions Vert Rate Format Scan Type 640x480 60,72,75,85 Hz RGBHV Progressive VESA85 640X480 85 Hz RGBHV Progressive VGA70 720X400 70 Hz RGBHV Progressive SVGA 800x600 60,72,75,85 Hz RGBHV Progressive 1024x768 60,70,75,85 Hz RGBHV... -
Page 10: Menu Ranges And Defaults
Menu Ranges and Defaults 5.1.5 The adjustment range and factory preset value as follows: Value Range Default Contrast 0~255 Bright 0~255 Color 0~255 0~255 Green 0~255 Blue 0~255 Note: Select reset to reset all adjustment back to the factory preset value. HV adjust- When selected, the following sub-menu appears. -
Page 11: Troubleshooting
LIMITATIONS - All products sold are "as is" and the above Limited Warranty is in lieu of all other warranties for this product, expressed or implied, and is strictly limited to two years from the date of purchase. TV One assumes no liability to end-users for any loss of use, revenue or profit. - Page 12 We Provide Solutions...
