- Page 1 Instruction Manual 1T-VS-622 Video to HDMI Scaler...
-
Page 3: Table Of Contents
Table of Contents Introduction Specifications Checking Package Contents Connecting The Hardware Operating The Unit Troubleshooting Limited Warranty Regulatory Compliance Contact Information... -
Page 4: Introduction
Routing Switchers, Signal Distribution Amplifiers and Cat.5 Transmission Systems. Liability Statement Every effort has been made to ensure that this product is free of errors. TV One cannot be held liable for the use of this hardware or any direct or indirect consequential damages arising from its use. -
Page 5: Specifications
SPECIFICATIONS Video Input/Output CV or SV Video Input 1x RCA Connector, 1x S-Video Connector HDMI V1.2 Output 1x via Type A Connector Video Performance Standards Compliance HDMI v1.2, HDCP 1.1, DVI 1.0 Output Resolutions up to 1080p PC up to WUXGA, HD 3-D Motion Adaptive, 3-D de-interlacing, 3:2/2:2 Video Processing Pull Down Detection/Recovery. -
Page 6: Checking Package Contents
576i 50Hz Note: By default the 1T-VS-622 automatically detects the resolution of the HDMI display device however you can manually control that selection using the OSD menu structure. Leave the Resolution in the “Native” position on the OSD menu to enable the Automatic Detection capability. -
Page 7: Connecting The Hardware
622 and the display. Plug in the provided AC adapter, first to the 1T-VS-622 and then to an active AC power source. Lastly, turn on the PC source and HDMI display device. (The 1T-VS-622 has no power switch and will begin to function as soon as it has the AC adapter connected to it.) Notes: (1) You may connect either a Composite Video Input or an S-Video input but you cannot connect both inputs at the same time. - Page 8 Once the adjustment has been made, use the Menu button and + and – buttons to navigate to where you can exit the OSD. • XGA Reset: Depressing and holding the Menu button and then the + button returns the settings to factory defaults and sets the output to XGA. •...
-
Page 9: Troubleshooting
Should this product, in TV One’s opinion, prove defective within this warranty period, TV One, at its option, will repair or replace this product without charge. Any defective parts replaced become the property of TV One. This warranty does not apply... -
Page 10: Regulatory Compliance
REGULATORY COMPLIANCE The 1T-VS-622 has been tested for compliance with appropriate FCC and CE rules and regulations. The Power Adaptor/Supply has been tested for compliance with appropriate UL, CUL, CE, PSE, GS Rules, Regulations and/or Guidelines. This Product and Power Adapter is RoHS Compliant.
