Enterasys Matrix N7 7C107 Installation Manual page 39

To install the power supply into the Matrix N7 chassis, refer to
1. Unpack the power supply by removing it from the shipping box and sliding the two foam end
caps off the unit. (Save the shipping box and materials in the event the unit must be reshipped.)
2. Remove the power supply from its protective plastic bag. (Save the shipping box and materials
in the event the unit must be reshipped.)
3. Examine the power supply carefully, checking for damage. If any damage is noted, DO NOT
install the power supply. Contact Enterasys Networks immediately.
4. Slide the power supply into the slot labeled PS1
a. Hold the power supply by placing one hand on the handle
using the other hand to support the power supply.
b. Holding the power supply right side up, align the power supply with the plastic guides
the bottom of the opening.
CAUTION: Forcing a misaligned power supply into place can damage the power supply
and/or the chassis backplane.
c. With the power supply properly inserted into the opening, carefully slide the supply forward
until it is connected to the backplane. The front panel should be flush with the face of the
Matrix N7 chassis. If significant resistance is encountered before the front panel is flush,
remove and reinsert the power supply. Do not force the power supply into place.
d. Secure the power supply to the chassis by using a large flat blade screwdriver to turn the large
➃
screw and lock the power supply in place.
5. If you are installing a second power supply, remove the blank plate
supply slot PS2 (keep the blank plate in the event you need to remove the power supply), and
repeat steps 1– 4.
Setting Up the Matrix N7 Chassis
Figure 3-7
➀
as follows:
➁
located on the front panel and
➄
Matrix N7 Chassis Setup
and proceed as follows:
➂
on
from the second power
3-11
