Setting Up the Matrix N7 Chassis
Figure 3-4 Shelf Installation
3.2.3.2 Installing the Matrix N7 Chassis
CAUTION: Read
all installation guidelines are met.
To install the Matrix N7 chassis, proceed as follows:
WARNING: To help prevent personal injury, at least two people are required to lift the
chassis into the rack.
ADVERTENCIA: Para ayudar a prevenir alguna lesión personal , al menos dos
personas son requeridas para levantar el chasis y meterlo al rack.
WARNHINWEIS: Zum Schutz vor körperlichen Schäden, sollten sie mit min. zwei
Personen das Chassis in das Rack heben.
1. Lift the chassis onto the shelf and slide it all the way into the rack. Refer back to
2. Use 10 screws (5 per side)
starting with the bottom holes and working toward the top of the chassis, as shown in
3-8 Matrix N7 Chassis Setup
A
Chapter 2 before completing the following procedure to ensure that
➀
provided with the equipment rack to secure the chassis to the rack,
B
Figure 3-4, B.
Figure 3-5.
