IP8000 Remote Phone

Configuration Guide

Release 3.5
June 2010

Advertisement

loading
Need help?

Need help?

Do you have a question about the IP8012 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vertical IP8012

Summary of Contents for Vertical IP8012

  • Page 1: Configuration Guide

    IP8000 Remote Phone Configuration Guide Release 3.5 June 2010...
  • Page 2 THIS PAGE INTENTIONALLY LEFT BLANK Release 3.5 June 2010...

  • Page 3: Supported Ip Phones

    Remote Phone Set Up Instructions Remote Phone Set Up Instructions This document provides the following information about the set up of IP8000 on the SBX IP: Supported IP Phones • IP8012 and IP8024 • NomadIP Wireless • Nomad SP Soft Phone This guide is specifically for setting up IP8000 series telephones.
  • Page 4 page - 2 IP Endpoint Licensing Remote Phone Set Up Instructions IP Endpoint Licensing Nomad SP requires a per-seat license. Two seats are automatically included. You do not have to install activation codes for these two seats. • IP8000 series and NomadIP wireless phones require no license. Entering IP address information to the KSU database from a digital phone is performed differently NOTE from programming IP settings in an IP remote phone.
  • Page 5 page - 3 IP Endpoint Licensing Remote Phone Set Up Instructions • You will also need a 24-button SBX digital telephone to set up the system. • For a typical test-bench or demonstration setup, you need four connections to a LAN switch: each via a straight-through CAT5E patch cord as shown above.
  • Page 6 page - 4 Preparation Remote Phone Set Up Instructions Preparation Before starting: 1. Verify that your VOIP card is installed into the system properly and that the card is recognized in the KSU database. KSU DIP switches must be set to enable the system to retain programming NOTE changes.
  • Page 7 page - 5 Configuring the VoIP Card Using PCAdmin Remote Phone Set Up Instructions 2. Right-click on VoIB, then select Logical Assignment. In Logical Assignments: 3. Right-click VoIB and Select (Virtual VoIB) Append to Station. A notation of 99 will be entered in the STA Board field.
  • Page 8 page - 6 Configuring the VoIP Card Using PCAdmin Remote Phone Set Up Instructions In VoIB Gateway: 4. Go to VoIB Gatekeeper Settings, then enter the IP Address, Default Gateway and Subnet Mask that you are assigning to the VOIP card per the worksheet on page 2 this document.
  • Page 9 page - 7 Configuring the VoIP Card Using PCAdmin Remote Phone Set Up Instructions From the VoIB Slot dropdown: 7. Select the card. From the Channel Number dropdown: 8. Select 2 for the number of channels to be used for IP Phones. 9.
  • Page 10 page - 8 Configuring the VoIP Card Using PCAdmin Remote Phone Set Up Instructions 11. Click Update. 12. Reset the KSU. 13. Double-click RSG/IP Programming > IP Phone Attributes. 14. Double-click on bin #1 (row #1), then enter the MAC address (which you will find labeled on the bottom of the IP phone).
  • Page 11 page - 9 Configuring the VoIP Card Using PCAdmin Remote Phone Set Up Instructions 15. Click Update. Result: NOTE • You must enter the colon characters in the MAC address. • You do not need to program the other data values in PGM 386 for IP8000 remote phones.
  • Page 12 page - 10 Configuring IP Phone Settings Remote Phone Set Up Instructions Configuring IP Phone Settings Verifying Connectivity to the VoIP card Ping the VoIP card from where the phone is located. Setting Up the IP Phone Setting up the IP Phone will vary dependent on the network infrastructure, IP Address Schema and location of the System.
  • Page 13 page - 11 Configuring IP Phone Settings Remote Phone Set Up Instructions 3. Press the volume + until DHCP? appears. • If IP Addressing is assigned via DHCP, this should be enabled. • If IP Addressing is Static, this sho •...
  • Page 14 page - 12 Configuring IP Phone Settings Remote Phone Set Up Instructions 7. Press the Volume + until PHONE IP ADDRESS(DOT:*) appears. • This is the station IP Address Field. • If IP Addressing is being dynamically assigned you won’t need to program this field.
  • Page 15 page - 13 Programming VOIP Card Settings from a Digital Keyset Remote Phone Set Up Instructions Programming VOIP Card Settings from a Digital Keyset This is an alternative programming method from the PCAdmin programming shown in the previous section. IMPORTANT! Disregard this section if you have configured the IP phone using PCAdmin.
  • Page 16 page - 14 Program IP Phone Attributes Remote Phone Set Up Instructions Assign VoIB Slot/Port Usage 1. Press PGM. 2. Dial 380 (VoIB Slot Assignment). 3. Press Flex Button (VoIB Slot). 4. Dial 10 (Slot Number to Program). 5. Press Save. 6.
